WAVEFORMS
FRONT END
2ms 2ms 1ms
0.5V 200mV 200mV
1815
AV SWITCH/JACK MICON
2ms 2ms 50ns
0.5V 200mV 500mV
2916
SOUND VIDEO AD CONVERTER
10µs 0.5ms 10µs
0.5V 1.0V 100mV
31017
2ms 50µs 10µs
0.5V 1.0V 200mV
41118
2ms 2ms 10µs
0.5V 50mV 100mV
51219
FRONT END
2ms 2ms 20µs
200mV 50mV 500mV
61320
2ms 1ms 20µs
200mV 200mV 500mV
71421
The following waveforms were measured
at the point of the corresponding balloon
number in the schematic dia
g
ram
NOTE:
I-1
