Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
118
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
RDENCA131WJZZ(LC-26/32/37AF3H/X)
POWER Unit
IC
Z701 9JG0034037760 J IC, MC33262D
Z702 9JG0034031975 J IC, STR-A6159M
Z901 9JG0034037736 J IC, Sp9001
Z1701 9JG0034043876 J IC, TA76432S
Z1702 9JG0034020736 J IC, AN1431T
Z1703 9JG0034016518 J IC, Si-8050JF
Z1704 9JG0034016496 J IC, Si-8033S
Z1705 9JG0034016496 J IC, Si-8033S
TRANSISTORS
Q701 9JG0034008523 J DTA143EKA
Q702 9JG0034003351 J 2SC2655
Q703 9JG0034000697 J 2SA1020
Q704 9JG0034095167 J RDX100N60
Q705 9JG0034095167 J RDX100N60
Q706 9JG0034039690 J 2SK3502
Q707 9JG0034039690 J 2SK3502
Q708 9JG0034027978 J 2SK2731
Q709 9JG0034008523 J DTA143EKA
Q710 9JG0034027978 J 2SK2731
Q711 9JG0034004072 J 2SC2412K
Q712 9JG0034027978 J 2SK2731
Q713 9JG0034004072 J 2SC2412K
Q714 9JG0034027455 J 2SA1037AK
Q716 9JG0034004072 J 2SC2412K
Q717 9JG0034008523 J DTA143EKA
Q718 9JG0034004072 J 2SC2412K
Q719 9JG0034004072 J 2SC2412K
Q1701 9JG0034003351 J 2SC2655
Q1702 9JG0034004072 J 2SC2412K
Q1703 9JG0034065152 J DTC114EKA
Q1704 9JG0034065152 J DTC114EKA
Q1705 9JG0034065152 J DTC114EKA
Q1706 9JG0034004072 J 2SC2412K
Q1707 9JG0034004072 J 2SC2412K
Q1708 9JG0034012458 J 2SD2114K
Q1709 9JG0034004072 J 2SC2412K
Q1710 9JG0034108358 J DTA114EKA
Q1712 9JG0034004072 J 2SC2412K
Q1713 9JG0034004072 J 2SC2412K
Q1714 9JG0034007411 J DTC143EKA
Q1715 9JG0034004072 J 2SC2412K
Q1716 9JG0034004072 J 2SC2412K
Q1717 9JG0034065152 J DTC114EKA
Q1718 9JG0034000050 J 2SA1020
Q1719 9JG0034027455 J 2SA1037AK
Q1720 9JG0034027455 J 2SA1037AK
DIODES
D701 9JG0034003289 J S5688J
D702 9JG0034003289 J S5688J
D704 9JG0034004668 J 1SS133
D705 9JG0034038392 J RM3A
D706 9JG0034062706 J RM2C
D707 9JG0034094225 J 20KDA60
D708 9JG0034003289 J S5688J
D709 9JG0034036810 J EG01C
D710 9JG0034003165 J 1GU42
D711 9JG0034003165 J 1GU42
D712 9JG0034003289 J S5688J
D713 9JG0034004668 J 1SS133
D714 9JG0034004056 J DAN202K
D715 9JG0034004056 J DAN202K
D716 9JG0034004668 J 1SS133
D717 9JG0034004056 J DAN202K
D718 9JG0034004668 J 1SS133
D720 9JG0034004056 J DAN202K
D721 9JG0034004668 J 1SS133
D901 9JG0034038341 J EC8FS6
D1701 9JG0034017476 J 11EQS06
D1702 9JG0034002967 J 1SS226
D1703 9JG0034016550 J RK14
D1704 9JG0034004056 J DAN202K
D1705 9JG0034004064 J DAP202K
D1706 9JG0034004056 J DAN202K
D1707 9JG0034004064 J DAP202K
D1708 9JG0034004668 J 1SS133
D1709 9JG0034004056 J DAN202K
D1710 9JG0034004056 J DAN202K
D1711 9JG0034004668 J 1SS133
D1712 9JG0034004668 J 1SS133
D1713 9JG0034002967 J 1SS226
D1714 9JG0034002967 J 1SS226
D1715 9JG0034002967 J 1SS226
D1716 9JG0034002967 J 1SS226
DZ701 9JG0034004889 J Zener Diode, MTZ J5.6
DZ702 9JG0034007268 J Zener Diode, MTZ J30
DZ703 9JG0034007268 J Zener Diode, MTZ J30
DZ704 9JG0034021902 J Zener Diode, MTZ J10
DZ705 9JG0034007284 J Zener Diode, MTZ J18B
DZ706 9JG0034008922 J Zener Diode, MTZ J6.8
DZ707 9JG0034008922 J Zener Diode, MTZ J6.8
DZ709 9JG0034008922 J Zener Diode, MTZ J6.8
DZ710 9JG0034008922 J Zener Diode, MTZ J6.8
DZ1701 9JG0034008914 J Zener Diode, MTZ J39
DZ1703 9JG0034007284 J Zener Diode, MTZ J18B
DZ1704 9JG0034021902 J Zener Diode, MTZ J10
DZ1706 9JG0034021910 J Zener Diode, MTZ J2.0
DZ1707 9JG0034007284 J Zener Diode, MTZ J18B
DZ1708 9JG0034008922 J Zener Diode, MTZ J6.8
COILS
L701 9JG0034016194 J Reactor, DRB25-03A-133NP
L702 9JG0034016194 J Reactor, DRB25-03A-133NP
L703 9JG0034091331 J Reactor, HKBS-12D090-2910Z
L704 9JG0037131776 J Reactor, EXZ40790-163
L705 9JG0034027358 J Reactor, LAV354VB 220K
L1701 9JG0031999995 J Reactor, CX40357-006
L1702 9JG0034017204 J Reactor, HK-05S050-8000A
L1703 9JG0034014833 J Reactor, HK-08S080-7000Z
L1704 9JG0034014833 J Reactor, HK-08S080-7000Z
TRANSFORMERS
T701 9JG0037127329 J EXT45641-292
T702 9JG0034100683 J EXT43341-274
PHOTOCOUPLERS
PC701 9JG0034017964 J Photocoupler, PS2571L1-1
PC702 9JG0034017964 J Photocoupler, PS2571L1-1
PC703 9JG0034017964 J Photocoupler, PS2571L1-1
PC704 9JG0034017964 J Photocoupler, PS2571L1-1
PC705 9JG0034017964 J Photocoupler, PS2571L1-1
CAPACITORS
C701 9JG0034012369 J 0.47 AC275V Film
C702 9JG0034019282 J 0.22 AC275V Film
C703 9JG0034018278 J 0.1 AC275V Film
C704 9JG0034012261 J 470p AC250V Ceramic
C705 9JG0034012261 J 470p AC250V Ceramic
C706 9JG0034091900 J 1.5 450V Film
C708 9JG0034006601 J 0.47 50V Film
C709 9JG0034017174 J 0.1 50V Ceramic(CHIP)
C710 9JG0034017158 J 1000p 50V Ceramic(CHIP)
C711 9JG0034017123 J 470p 50V Ceramic(CHIP)
C712 9JG0034017174 J 0.1 50V Ceramic(CHIP)
C713 9JG0034002177 J 47000p 50V Ceramic(CHIP)
C714 9JG0034009104 J 0.47 50V Ceramic(CHIP)
C715 9JG0034002126 J 100p 50V Ceramic(CHIP)
C716 9JG0034002126 J 100p 50V Ceramic(CHIP)
C717 9JG0034019452 J 1000p 1kV Ceramic
C719 9JG0034094233 J 150 450V Electrolytic
C720 9JG0034094233 J 150 450V Electrolytic
C721 9JG0034006601 J 0.47 50V Film
C722 9JG0034017174 J 0.1 50V Ceramic(CHIP)
C723 9JG0034058199 J 2.2 50V Electrolytic
C724 9JG0034033099 J 100p 1kV Ceramic
