Sharp LC-26AF3 M/H/X User Manual

92
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts
Lists and Schematic Diagrams. The use of a substitute replacement
part which dose no have the same safety characteristic as the fac-
tory recommended replacement parts shown in this service manual
may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
LCD PANEL
(LC-26AF3M/H/X)
DUNTKD186FE06 – MAIN Unit(LC-26AF3H/M) —
DUNTKD186FE07 – MAIN Unit(LC-26AF3X) —
DUNTKD304DE07 – AV Unit(LC-26AF3M) —
DUNTKD304DE08 – AV Unit(LC-26AF3H) —
DUNTKD304DE10 – AV Unit(LC-26AF3X) —
DUNTKD305DE07 – KEY Unit(LC-26AF3M) —
DUNTKD305DE08 – KEY Unit(LC-26AF3H) —
DUNTKD305DE10 – KEY Unit(LC-26AF3X) —
DUNTKD306DE07 – R/C, LED Unit(LC-26AF3M) —
DUNTKD306DE08 – R/C, LED Unit(LC-26AF3H) —
DUNTKD306DE10 – R/C, LED Unit(LC-26AF3X) —
RUNTKA151WJZZ – INVERTER Unit (LC-26AF3M) —
RUNTKA205WJZZ – INVERTER Unit (LC-26AF3H/X) —
RDENCA128WJZZ – POWER UNIT(LC-26AF3M) —
RDENCA131WJZZ – POWER UNIT (LC-26AF3H/X) —
(LC-32AF3M/H/X)
DUNTKD186FE08 – MAIN Unit(LC-32AF3H/M) —
DUNTKD186FE10 – MAIN Unit(LC-32AF3X) —
DUNTKD304DE01 – AV Unit(LC-32AF3M) —
DUNTKD304DE02 – AV Unit(LC-32AF3H) —
DUNTKD304DE03 – AV Unit(LC-32AF3X) —
DUNTKD305DE01 – KEY Unit(LC-32AF3M) —
DUNTKD305DE02 – KEY Unit(LC-32AF3H) —
DUNTKD305DE03 – KEY Unit(LC-32AF3X) —
DUNTKD306DE01 – R/C, LED Unit(LC-32AF3M) —
DUNTKD306DE02 – R/C, LED Unit(LC-32AF3H) —
DUNTKD306DE03 – R/C, LED Unit(LC-32AF3X) —
RUNTKA152WJZZ – INVERTER Unit (LC-32AF3M) —
RUNTKA206WJZZ – INVERTER Unit (LC-32AF3H/X) —
RDENCA128WJZZ – POWER UNIT(LC-32AF3M) —
RDENCA131WJZZ – POWER UNIT (LC-32AF3H/X) —
(LC-37AF3M/H/X)
DUNTKD186FE04 – MAIN Unit(LC-37AF3H/M) —
DUNTKD186FE05 – MAIN Unit(LC-37AF3X) —
DUNTKD304DE04 – AV Unit(LC-37AF3M) —
DUNTKD304DE05 – AV Unit(LC-37AF3H) —
DUNTKD304DE06 – AV Unit(LC-37AF3X) —
DUNTKD305DE04 – KEY Unit(LC-37AF3M) —
DUNTKD305DE05 – KEY Unit(LC-37AF3H) —
DUNTKD305DE06 – KEY Unit(LC-37AF3X) —
DUNTKD306DE04 – R/C, LED Unit(LC-37AF3M) —
DUNTKD306DE05 – R/C, LED Unit(LC-37AF3H) —
DUNTKD306DE06 – R/C, LED Unit(LC-37AF3X) —
RUNTKA154WJZZ – INVERTER Unit
(LC-37AF3M) —
RUNTKA207WJZZ – INVERTER Unit (LC-37AF3H/X) —
RDENCA128WJZZ – POWER UNIT(LC-37AF3M) —
RDENCA131WJZZ – POWER UNIT (LC-37AF3H/X) —
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT EPENDENTLY.
RLCDTA067WJZZ J 26 Wide LCD Panel Unit
(LC-26AF3H/M/X)
RLCDTA080WJZZ J 32 Wide LCD Panel Unit
(LC-32AF3H/M/X)
RLCDTA081WJZZ J 37 Wide LCD Panel Unit
(LC-37AF3H/M/X)
KLMP-A073WJZZ J Lamp(LC-26AF3H/M/X)
KLMP-A074WJZZ J Lamp(LC-32AF3M)
KLMP-A075WJZZ J Lamp(LC-37AF3M)
Ref. No. Part No. ★ Description Code
LAMP
INTEGRATED CIRCUITS
IC1802 VHiBD4729G+-1Y J BD4729G-TR AD
IC1803 RH-iXA167WJZZY J PQ025EZ01ZZ AL
IC1804 VHiPQ033EZ1-1Y J PQ033EZ01ZP AF
IC1805 VHiPQ070XH2-1Y J PQ070XH02ZP AG
IC1806 VHiPQ05DZ1U-1Y J PQ05DZ1U AG
IC1807 VHiPQ033EZ1-1Y J PQ033EZ01ZP AF
IC2001 RH-iXB427WJZZQ J M30626MHP258GP AX
IC2002 VHiBR24L64F-1Y J BR24L64F-WE2 AK
IC2003 RH-iXB600WJZZQ J SST39VF1682-70 AP
IC2006 VHiBD5224G+-1Y J BD5224G-TR AD
IC2007 RH-iXB495WJZZQ J LC4128V-75TN10 AR
IC3300 RH-iXB405WJZZQ J SVP-EX59 BK
IC3301 RH-iXB375WJZZQ J K4D263238G-VC3 BA
IC4101 VHiBD8133FV-1Y J BD8133FV-E2 AS
IC4103 RH-iXA167WJZZY J PQ025EZ01ZZ AL
IC4104 RH-iXB332WJZZY J LT1943EFE#TRPB AW
IC4107 VHiLP2951CM-1Y J LP2951CMX AL
IC4108 VHiTC7S08U/-1Y J TC7S08FU AE
IC4501 RH-iXB438WJZZY J 24LC32A-I/SN AL
(LC-26AF3H/M/X/32AF3H/M/X)
IC4501 RH-iXB439WJZZY J 24LC32A-I/SN AL
(LC-37AF3H/M/X)
IC4502 RH-iXB326WJZZQ J IXB326 BC
IC4503 RH-iXB029WJZZQ J MT48LC2M32B2P6 AX
IC4601 VHiDS90C386-1Y J DS90CF386MTDX AP
DUNTKD186FE06(LC-26AF3H/M)
DUNTKD186FE07(LC-26AF3X)
DUNTKD186FE08(LC-32AF3H/M)
DUNTKD186FE10(LC-32AF3X)
DUNTKD186FE04(LC-37AF3H/M)
DUNTKD186FE05(LC-37AF3X)
MAIN Unit
