Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
93
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
DUNTKD186FE06(LC-26AF3H/M)
DUNTKD186FE07(LC-26AF3X)
DUNTKD186FE08(LC-32AF3H/M)
DUNTKD186FE10(LC-32AF3X)
DUNTKD186FE04(LC-37AF3H/M)
DUNTKD186FE05(LC-37AF3X)
MAIN Unit (Continued)
IC4602 RH-iXB445WJZZQ J LC4032V-75TN48 AM
TRANSISTORS
Q2001 VSDTA144EE/-1Y J DTA144EE AA
Q2002 VSDTA144EE/-1Y J DTA144EE AA
Q2003 VSDTA144EE/-1Y J DTA144EE AA
Q2004 VSDTA144EE/-1Y J DTA144EE AA
Q2008 VSUMG2N++++-1Y J UMG2N AB
Q2009 VSDTA144EE/-1Y J DTA144EE AA
Q3700 VS2SA1530AR-1Y J 2SA1530AR AB
Q3701 VS2SA1530AR-1Y J 2SA1530AR AB
Q3702 VS2SA1530AR-1Y J 2SA1530AR AB
Q3703 VS2SC3928AR-1Y J 2SC3928AR AB
Q3704 VS2SC3928AR-1Y J 2SC3928AR AB
Q3705 VS2SC3928AR-1Y J 2SC3928AR AB
Q3706 VS2SC3928AR-1Y J 2SC3928AR AB
Q3707 VS2SA1530AR-1Y J 2SA1530AR AB
Q3708 VS2SC3928AR-1Y J 2SC3928AR AB
Q3709 VS2SA1530AR-1Y J 2SA1530AR AB
Q4105 VSTP0610T++-1Y J TP0610T AD
Q4106 VS2SC3928AR-1Y J 2SC3928AR AB
Q4108 VS2SK1826++-1Y J 2SK1826 AC
Q4109 VS2SK1826++-1Y J 2SK1826 AC
Q4113 VS2SK1826++-1Y J 2SK1826 AC
Q4114 VS2SK1826++-1Y J 2SK1826 AC
Q4115 VSDTC144EE/-1Y J DTC144EE AA
Q4116 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D1801 VHDHSU119//-1Y J HSU119 AB
D1802 VHDHSU119//-1Y J HSU119 AB
D1803 VHDHSU119//-1Y J HSU119 AB
D1804 VHDHSU119//-1Y J HSU119 AB
D1806 VHDHSU119//-1Y J HSU119 AB
D1807 RH-DXA024WJZZY J Diode AE
D2001 RH-PXA018WJZZY J GM1HD55200A AC
D2002 VHDRB521S30-1Y J RB521S30 AC
D4101 VHDLi114+++-1Y J Li114 AC
D4102 VHDLi114+++-1Y J Li114 AC
D4103 VHDLi124+++-1Y J Li124 AC
D4104 VHDLi114+++-1Y J Li114 AC
D4105 VHDLi124+++-1Y J Li124 AC
D4106 RH-EX1274CEZZY J Zener Diode, 13V AB
D4107 VHDHSU119//-1Y J HSU119 AB
PACKAGED CIRCUITS
TH2001 VHHM1103J03-1Y J Thermistor AC
X2001 RCRSCA117WJZZY J Crystal 10MHz AG
X3301 RCRSC0170TAZZY J Crystal AG
X4501 RCRUAA055WJZZY J 40MHz
COILS AND FILTERS
FL4651 RFiLNA002WJZZY J Filter AD
FL4652 RFiLNA002WJZZY J Filter AD
FL4653 RFiLNA002WJZZY J Filter AD
FL4654 RFiLNA002WJZZY J Filter AD
L3700 VPD9M220J2R7NY J Peaking 22µH 5% AC
L3701 VPD9M220J2R7NY J Peaking 22µH 5% AC
L4101 RCiLPA296WJZZY J Coil AG
L4102 RCiLP0343TAZZY J Coil AD
L4103 RCiLP0343TAZZY J Coil AD
L4104 RCiLP0271TAZZY J Coil AE
L4105 VPD9M4R7J1R4NY J Peaking 4.7µH 5% AB
L4106 RCiLP0343TAZZY J Coil AD
L4107 RCiLP0343TAZZY J Coil AD
L4110 VPD9M4R7J1R4NY J Peaking 4.7µH 5% AB
CAPACITORS
C1804 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1805 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1806 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1807 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1808 VCERMZ1CN226MY J 22 16V AC
C1809 VCERMZ1CN107MY J 100 16V AD
C1810 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1811 VCERMZ1CN226MY J 22 16V AC
C1812 VCERMZ1CN107MY J 100 16V AD
C1813 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1814 VCERMZ1CN226MY J 22 16V AC
C1815 VCERMZ1CN107MY J 100 16V AD
C1816 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1817 VCERMZ1CN226MY J 22 16V AC
C1818 VCERMZ1CN107MY J 100 16V AD
C1819 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1820 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1821 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1822 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1824 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1825 VCERML0JN226MY J 22 6.3V AC
C1827 VCERMZ1CN226MY J 22 16V AC
C1828 VCERMZ1CN107MY J 100 16V AD
C1829 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2001 VCERML1CN476MY J 47 16V AC
C2002 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2003 VCCCCY1HH100DY J 10p 50V Ceramic AA
C2004 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2005 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2006 VCCCCY1HH100DY J 10p 50V Ceramic AA
C2007 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2008 VCCCCY1HH470JY J 47p 50V Ceramic AA
C2009 VCCCCY1HH470JY J 47p 50V Ceramic AA
C2010 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2011 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2012 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2013 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2014 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2015 RC-KZA073WJZZY J 10 16V Ceramic AD
C2016 VCKYCY1HB152KY J 1500p 50V Ceramic AA
C2017 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2018 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2019 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2020 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2021 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2022 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2023 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2024 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2025 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2026 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2027 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2028 RC-KZA073WJZZY J 10 16V Ceramic AD
C2029 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2030 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3301 VCERML0JN476MY J 47 6.3V AC
C3302 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3303 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3304 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3305 RC-KZA073WJZZY J 10 16V Ceramic AD
C3306 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3307 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3309 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3310 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3311 RC-KZA073WJZZY J 10 16V Ceramic AD
C3313 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3314 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C3315 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C3316 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C3317 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C3318 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C3320 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3322 VCKYCY1EB104KY J 0.1 25V Ceramic AB
