Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
124
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
6-4 Not Available - 32" Lamp Ass'y -
6-4-1 KLMP-A074WJZZ J Lamp, x9
6-4-2 QCNW-D684WJQZ J Connector, x8 AD
6-4-3 QCNW-D687WJQZ J Connector (GND Wire) AE
6-5 LHLDZA589WJKZ J Lamp Holder, x2 AK
6-6 LX-BZA051WJFN J Screw, x4 (M4*10) AB
6-7 LX-BZA114WJFN J Screw, x4 (PWB) AA
6-8 PCOVUA059WJZZ J Diffusion Panel BD
6-9 PSHEPA354WJZZ J Diffusion Sheet, x2
6-10 XBPS730P06WS0 J Screw, x9 (Lamp Holder) AA
6-11 XBPSN30P10000 J Screw, x6 (M3X10 B/L CHS) AA
6-12 XEPS930P10000 J Screw, x4 (M3*10 Panel HLD) AA
7 DUNTKD186FE08 - MAIN Unit(LC-32AF3H/M) —
7 DUNTKD186FE10 - MAIN Unit(LC-32AF3X) —
8 DUNTKD304DE01 - AV Unit(LC-32AF3M) —
8 DUNTKD304DE02 - AV Unit(LC-32AF3H) —
8 DUNTKD304DE03 - AV Unit(LC-32AF3X) —
9 DUNTKD305DE01 - KEY Unit(LC-32AF3M) —
9 DUNTKD305DE02 - KEY Unit(LC-32AF3H) —
9 DUNTKD305DE03 - KEY Unit(LC-32AF3X) —
10 DUNTKD306DE01 - R/C, LED Unit(LC-32AF3M) —
10 DUNTKD306DE02 - R/C, LED Unit(LC-32AF3H) —
10 DUNTKD306DE03 - R/C, LED Unit(LC-32AF3X) —
11 RUNTKA152WJZZ - INVERTER Unit —
(LC-32AF3M)
11 RUNTKA206WJZZ - INVERTER Unit —
(LC-32AF3H/X)
12 RDENCA128WJZZ - POWER UNIT(LC-32AF3M) —
12 RDENCA131WJZZ - POWER UNIT —
(LC-32AF3H/X)
13 GCOVAB166WJKA J Hinge Cover AQ
14 GCOVAB243WJKA J ID Cover
15 HiNDPB365WJSA J Model Label (LC-32AF3X)
15 HiNDPB366WJSA J Model Label (LC-32AF3H)
15 HiNDPB367WJSA J Model Label (LC-32AF3M)
16 LANGTA202WJFW J Center Angle
17 LCHSMA227WJKA J Chassis Frame
18 LHLDW1009CEZZ J Wire Holder (OMEGA Lock) AA
19 LHLDW1046CEZZ J Wire Holder (OMEGA Lock) AA
20 LHLDW1173CEZZ J Wire Holder (BACKSHLD) AD
21 LHLDWA023WJKZ J Wire Holder AC
22 PSLDMA708WJFW J Main Shield
23 PSLDMA709WJFW J Main Shield
24 PSLDMA712WJN1 J Inverter Shield A
25 PSLDMA769WJFW J Tuner Shield
26 PSLDMA831WJKZ J Shield
27 PSPAGA243WJZZ J Inverter Cushion, x3 AC
28 PSPAZA844WJKZ J Cooling Sheet (For IC3300)
29 PSPAZA845WJKZ J Cooling Sheet (For IC4101)
30 PSPAZA846WJKZ J Cooling Sheet (For IC4503)
31 PSPAZA890WJKZ J Spacer, x2
32 PRDARA263WJFW J Heat Sink C
33 PSHEPA400WJZZ J Spacer, x4(Side B)
34 PSLDMA212WJFW J Shield
35 PSLDMA710WJFW J HDMI Shield (Top)
36 PSLDMA711WJFW J HDMI Shield (Bottom)
37 PSPAZA848WJKZ J Cooling Sheet(For IC1203)
38 QCNW-D579WJQZ J Connecting Cord, AM
AV-POWER
39 QCNW-D576WJQZ J Connecting Cord, AV-KEY AF
40 QCNW-D577WJQZ J Connecting Cord, AV-R/C AK
41 QCNCMA201WJZZ J Connecting Cord, AH
MAIN-AV BTOB
42 QCNW-D580WJQZ J Connecting Cord, AP
MAIN-POWER(PB)
43 QCNW-D581WJQZ J Connecting Cord, AF
MAIN-POWER(DP)
44 QCNW-D582WJQZ J Connecting Cord, AE
INV_GND-GND
45 QCNW-D707WJPZ J Connecting Cord AH
46 QCNW-D708WJPZ J Connecting Cord AK
47 QCNW-E062WJQZ J Connecting Cord, AV-SP
48 QPWBMD143WJPZ J FPC, x2 AM
CABINET AND MECHANICAL PARTS
(LC-32AF3M/H/X)
1 CCABAB073WJ01 J Front Cabinet Ass'y
(LC-32AF3H/M)
1 CCABAB201WJ01 J Front Cabinet Ass'y
(LC-32AF3X)
1-1 Not Available - Front Cabinet —
1-2 GCOVAB240WJSA J R/C, LED Decoration Cover
1-3 HBDGBA015WJSA J Badge, "SHARP" AH
1-4 PSPAHA607WJZZ J Mask Spacer (Side), x2
1-5 PSPAHA608WJZZ J Mask Spacer
(Top/Bottom), x2
2 CCABBA636WJ02 J Rear Cabinet Ass'y
(LC-32AF3H/M)
2 CCABBA698WJ01 J Rear Cabinet Ass'y
(LC-32AF3X)
2-1 Not Available - Rear Cabinet —
2-2 GCOVAB225WJKA J Terminal Cover
2-3 LHLDWA055WJKZ J Wire Holder (AC Cord) AC
2-4 PSPAHA413WJZZ J Mask Spacer, x2 AB
3 CCOVAB340WJ01 J Top Control Cover Ass'y
3-1 Not Available - Top Control Cover —
3-2 JBTN-A459WJKA J Power Button
3-3 JBTN-A460WJKA J Operation Button
3-4 MSPRCA049WJFW J Spring for Power Button AC
4 CDAi-A185WJ01 J Stand Base Ass'y BK
4-1 Not Available - Stand Base —
4-2 LANGKA438WJSA J Stand Base Angle BC
4-3 PSPAHA544WJZZ J Spacer AB
4-4 PSPAZA761WJZZ J LEG-Cushion, x2 AD
4-5 PSPAZA762WJZZ J LEG-Cushion-B, x2 AD
4-6 PSPAZA763WJZZ J LEG-Cushion-C, x4 AD
4-7 XEBS940P12000 J Screw, x10 AB
5 CHNG-A104WJN1 J Stand Hinge Ass'y
5-1 Not Available - Stand Hinge —
5-2 GDAi-A184WJSA J Stand Support
5-3 GDAi-A200WJF7 J Swivel Base
5-4 LX-NZA013WJFN J Nut AE
5-5 PSPAZA714WJZZ J Spacer, x2
5-6 XCSS750P30000 J Screw, x5 (BASE)
6 Not Available - 32"LCD Panel Unit Ass'y —
6-1 RLCDTA080WJZZ J 32"LCD Panel Unit
6-2 CANGKA501WJ01 J Panel Fixing Center Angle
Ass'y (Top)
6-2-1 Not Available - Panel Fixing Center Angle —
(Top)
6-2-2 PSHEPA408WJZZ J Sheet (Middle)
6-2-3 PSHEZA030WJZZ J Insulation Sheet, x2 (Long) AB
6-2-4 PSHEZA031WJZZ J Insulation Sheet, x2 (Short) AB
6-2-5 PSPAKA116WJZZ J Angle Sheet, x3
6-2-6 QEARZA088WJFW J Earth Spacer, x4 AD
6-2-7 XBPS730P06WS0 J Screw, x4 AA
6-3 CCHSMA206WJN1 J Back Light Chassis Ass'y
6-3-1 Not Available - Back Light Chassis —
6-3-2 LANGFA172WJFW J Fixing Angle (Top) AK
6-3-3 LANGKA459WJFW J Fixing Angle (Bottom) AV
6-3-4 LANGKA500WJFW J Top Angle L
6-3-5 LANGKA536WJFW J Top Angle R
6-3-6 LHLDZA588WJKZ J Lamp Clip, x6 AB
6-3-7 PGUMMA009WJKA J Lamp Rubber, x18
6-3-8 PMiR-A077WJZZ J Mirror Sheet AV
6-3-9 PSPAZA713WJZZ J Tape, x2 AB
6-3-10 TCAUZA031WJZZ J Caution Label AB
6-3-11 XBPS730P06WS0 J Screw, x16 (M3x6) AA
