Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
127
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
CABINET AND MECHANICAL PARTS
(LC-37AF3M/H/X)
1 CCABAB079WJ01 J Front Cabinet Ass'y
(LC-37AF3H/M)
1 CCABAB202WJ01 J Front Cabinet Ass'y
(LC-37AF3X)
1-1 Not Available - Front Cabinet —
1-2 GCOVAB240WJSA J R/C, LED Decoration Cover
1-3 HBDGB3142CESB J Badge, "SHARP"
1-4 PSPAHA412WJZZ J Mask Spacer (Side), x2
1-5 PSPAHA416WJZZ J Mask Spacer
(Top/Bottom), x2
2 CCABBA639WJ02 J Rear Cabinet Ass'y
(LC-37AF3H/M)
2 CCABBA699WJ01 J Rear Cabinet Ass'y
(LC-37AF3X)
2-1 Not Available - Rear Cabinet —
2-2 GCOVAB233WJKA J Terminal Cover
2-3 LHLDWA055WJKZ J Wire Holder (AC Cord) AC
2-4 PSPAHA413WJZZ J CCABBA699WJ01 AB
3 CCOVAB340WJ01 J Top Control Cover Ass'y
3-1 Not Available - Top Control Cover —
3-2 JBTN-A459WJKA J Power Button
3-3 JBTN-A460WJKA J Operation Button
3-4 MSPRCA049WJFW J Spring for Power Button AC
4 CDAi-A183WJ01 J Stand Base Ass'y BK
4-1 Not Available - Stand Base AZ
4-2 LANGKA437WJSA J Stand Base Angle BC
4-3 PSPAHA544WJZZ J Spacer AB
4-4 PSPAZA761WJZZ J LEG-Cushion, x2 AD
4-5 PSPAZA762WJZZ J LEG-Cushion-B, x2 AD
4-6 PSPAZA763WJZZ J LEG-Cushion-C, x4 AD
4-7 XEBS940P12000 J Screw, x10 AB
5 CHNG-A103WJN1 J Stand Hinge Ass'y
5-1 Not Available - Stand Hinge —
5-2 GDAi-A184WJSA J Stand Support
5-3 GDAi-A200WJF7 J Swivel Base
5-4 LX-NZA013WJFN J Nut AE
5-5 PSPAZA714WJZZ J Spacer, x2
5-6 XCSS750P30000 J Screw, x5 (BASE)
6 Not Available - 37"LCD Panel Unit Ass'y —
6-1 RLCDTA081WJZZ J 37"LCD Panel Unit
6-2 CANGKA540WJ01 J Panel Fixing Center Angle
Ass'y (Top)
6-2-1 Not Available - Panel Fixing Center Angle —
(Top)
6-2-2 PSHEZA035WJZZ J Insulation Sheet, x2 (Long)
6-2-3 PSHEZA036WJZZ J Insulation Sheet, x4 (Short)
6-2-4 PTPEZA007WJZZ J Tape, x2
6-2-5 QEARZA088WJFW J Earth Spacer, x4 AD
6-2-6 XBPS730P06WS0 J Screw, x4 AA
6-3 CCHSMA220WJN1 J Back Light Chassis Ass'y
6-3-1 Not Available - Back Light Chassis —
6-3-2 LANGFA172WJFW J Fixing Angle (Top) AK
6-3-3 LANGKA538WJFW J Top Angle R
6-3-4 LANGKA539WJFW J Top Angle L
6-3-5 LANGKA541WJFW J Bottom Angle L
6-3-6 LANGKA542WJFW J Bottom Angle R
6-3-7 LHLDZA532WJKZ J Clip, x6 AD
6-3-8 LHLDZA576WJKZ J Lamp Clip, x10 AC
6-3-9 PGUMMA008WJKA J Lamp Rubber, x20
6-3-10 PMiR-A078WJZZ J Mirror Sheet AY
6-3-11 PSPAZA713WJZZ J Tape, x2 AB
6-3-12 TCAUZA031WJZZ J Caution Label AB
6-3-13 XBPS730P06WS0 J Screw, x17 (M3x6) AA
6-4 Not Available - 37" Lamp Ass'y —
6-4-1 KLMP-A075WJZZ J Lamp, x10
6-4-2 QCNW-D685WJQZ J Connector, x9 AD
6-4-3 QCNW-D688WJQZ J Connector AE
6-5 LHLDZA623WJKZ J Lamp Holder, x2 AL
6-6 LX-BZA051WJFN J Screw, x4 AB
6-7 LX-BZA114WJFN J Screw, x4 AA
6-8 PCOVUA060WJZZ J Diffusion Panel BF
6-9 PSHEPA355WJZZ J Diffusion Sheet, x2
6-10 XBPS730P06WS0 J Screw, x5 AA
6-11 XBPS730P08WS0 J Screw, x6 AH
6-12 XBPSN30P10000 J Screw, x13 AA
7 DUNTKD186FE04 - MAIN Unit(LC-37AF3H/M) —
7 DUNTKD186FE05 - MAIN Unit(LC-37AF3X) —
8 DUNTKD304DE04 - AV Unit(LC-37AF3M) —
8 DUNTKD304DE05 - AV Unit(LC-37AF3H) —
8 DUNTKD304DE06 - AV Unit(LC-37AF3X) —
9 DUNTKD305DE04 - KEY Unit(LC-37AF3M) —
9 DUNTKD305DE05 - KEY Unit(LC-37AF3H) —
9 DUNTKD305DE06 - KEY Unit(LC-37AF3X) —
10 DUNTKD306DE04 - R/C, LED Unit(LC-37AF3M) —
10 DUNTKD306DE05 - R/C, LED Unit(LC-37AF3H) —
10 DUNTKD306DE06 - R/C, LED Unit(LC-37AF3X) —
11 RUNTKA154WJZZ - INVERTER Unit —
(LC-37AF3M)
11 RUNTKA207WJZZ - INVERTER Unit —
(LC-37AF3H/X)
12 RDENCA128WJZZ - POWER UNIT(LC-37AF3M) —
12 RDENCA131WJZZ - POWER UNIT —
(LC-37AF3H/X)
13 GCOVAB243WJKA J Hinge Cover
14 GCOVAB166WJKA J ID Cover AQ
15 HiNDPB374WJSA J Model Label (LC-37AF3X)
15 HiNDPB375WJSA J Model Label (LC-37AF3H)
15 HiNDPB376WJSA J Model Label (LC-37AF3M)
16 LANGTA201WJFW J Center Angle
17 LCHSMA227WJKA J Chassis Frame
18 LHLDW1046CEZZ J Wire Holder (OMEGA) AA
19 LHLDW1173CEZZ J Wire Holder (BACKSHLD) AD
20 LHLDWA023WJKZ J Wire Holder AC
21 PSLDMA708WJFW J Main Shield
22 PSLDMA709WJFW J Main Shield
23 PSLDMA712WJN1 J INV-SLD-A
24 PSLDMA769WJFW J Tuner Shield
25 PSLDMA831WJKZ J Shield
26 PSPAGA243WJZZ J Inverter Cushion, x3 AC
27 PSPAZA844WJKZ J Cooling Sheet (For IC3300)
28 PSPAZA845WJKZ J Cooling Sheet (For IC4101)
29 PSPAZA846WJKZ J Cooling Sheet (For IC4503)
30 PSPAZA890WJKZ J Spacer, x2
31 PRDARA263WJFW J Heat Sink C
32 PSHEPA400WJZZ J Spacer, x4 (Side B)
33 PSLDMA212WJFW J Shield
34 PSLDMA710WJFW J HDMI Shield (Top)
35 PSLDMA711WJFW J HDMI Shield (Bottom)
36 PSPAZA848WJKZ J Cooling Sheet (For IC1203)
37 QCNW-D849WJQZ J Connecting Cord, AM
AV-POWER
38 QCNW-D846WJQZ J Connecting Cord, AV-KEY AF
39 QCNW-D847WJQZ J Connecting Cord, AV-R/C AK
40 QCNCMA201WJZZ J Connecting Cord, AH
MAIN-AV BTOB
41 QCNW-D850WJQZ J Connecting Cord, AP
MAIN-POWER(PB)
42 QCNW-D851WJQZ J Connecting Cord, AF
MAIN-POWER(PC)
43 QCNW-D852WJQZ J Connecting Cord, AE
INV_GND-GND
44 QCNW-D854WJPZ J Connecting Cord, AK
POW-INV(PD)
45 QCNW-D855WJPZ J Connecting Cord, AL
POW-INV(PF)
46 QCNW-E063WJQZ J Connecting Cord,AV-SP
