Sharp LC-26AF3 M/H/X User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
102
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
DUNTKD304DE07/08/10(LC-26AF3M/H/X)
DUNTKD304DE01/02/03(LC-32AF3M/H/X)
DUNTKD304DE04/05/06(LC-37AF3M/H/X)
AV Unit (Continued)
C2566 VCERMZ1CN337MY J 330 16V AD
C2567 VCERMZ1CN476MY J 47 16V AC
C2568 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C2569 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2570 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2571 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2572 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2573 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3900 VCERMZ1EN337MY J 330 25V AE
C3901 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
C3902 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
C3903 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3904 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3905 VCERML1VN474MY J 0.47 35V AC
C3906 VCERML1VN474MY J 0.47 35V AC
C3907 VCKYTV1HF104ZY J 0.1 50V Ceramic AB
C3908 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3909 VCKYTV1HF104ZY J 0.1 50V Ceramic AB
C3910 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3911 VCERMZ1EN477MY J 470 25V AE
C3912 VCERMZ1EN477MY J 470 25V AE
C3913 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3914 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3915 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C3916 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C3917 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3918 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3919 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3920 VCCCCY1HH101JY J 100p 50V Ceramic AA
C3921 VCKYCY1HB561KY J 560p 50V Ceramic AA
C3922 VCKYCY1HB561KY J 560p 50V Ceramic AA
C3923 VCERMZ1EN477MY J 470 25V AE
C3924 VCERMZ1EN477MY J 470 25V AE
C3925 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3926 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3927 VCFYFA1HA474J+ J 0.47 50V AC
C3928 VCFYFA1HA474J+ J 0.47 50V AC
C3929 VCERML1VN105MY J 1 35V AC
C5700 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5701 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5702 VCERMZ1CN107MY J 100 16V AD
C5703 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5704 VCERMZ1EN107MY J 100 25V AC
C5705 VCERMZ1CN107MY J 100 16V AD
C5706 VCERMZ1EN107MY J 100 25V AC
C5707 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5708 VCERMZ1EN107MY J 100 25V AC
C5709 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5710 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5711 VCERMZ1EN107MY J 100 25V AC
C5712 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5713 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C5714 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5715 VCERMZ1CN107MY J 100 16V AD
C5716 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5717 VCERMZ1CN107MY J 100 16V AD
C5718 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5719 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5720 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5721 VCERMZ1CN107MY J 100 16V AD
C5722 VCERMZ1CN107MY J 100 16V AD
C5723 VCERMZ1CN107MY J 100 16V AD
C5724 VCERMZ1CN107MY J 100 16V AD
C5725 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5726 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C5727 VCERMZ1CN107MY J 100 16V AD
C5728 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
RESISTORS
R1100 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1101 VRS-CY1JF681JY J 680 1/16W Metal Oxide AA
R1102 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R1103 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1104 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R1105 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R1106 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R1107 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R1108 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R1109 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R1110 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R1111 VRS-TW2ED561JY J 560 1/4W Metal Oxide AA
R1112 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R1113 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1114 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1115 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R1116 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R1117 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R1118 VRS-CY1JF821JY J 820 1/16W Metal Oxide AA
R1119 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1120 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R1121 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R1122 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R1123 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1124 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R1125 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R1126 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R1127 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R1128 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1129 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1130 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1131 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1132 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1133 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R1134 VRS-TQ2BD330JY J 33 1/8W Metal Oxide AA
R1135 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R1136 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R1137 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R1138 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1139 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1140 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R1141 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1142 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1143 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R1144 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1145 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1147 VRS-CY1JF821JY J 820 1/16W Metal Oxide AA
R1148 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1149 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R1150 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R1194 VRS-CY1JF561JY J 560 1/16W Metal Oxide AA
R1201 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1202 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1203 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1204 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1205 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1206 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1207 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1208 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1209 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1210 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1211 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R1212 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R1213 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1214 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1215 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1216 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1217 VRS-TW2ED4R7JY J 4.7 1/4W Metal Oxide AB
R1218 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1219 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R1220 VRS-TW2ED4R7JY J 4.7 1/4W Metal Oxide AB
R1221 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R1222 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R1223 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R1224 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA

Sharp LC-26AF3 M/H/X Specifications

General

Brand	Sharp
Model	LC-26AF3 M/H/X
Category	LCD TV
Language	English
