Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
104
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
DUNTKD304DE07/08/10(LC-26AF3M/H/X)
DUNTKD304DE01/02/03(LC-32AF3M/H/X)
DUNTKD304DE04/05/06(LC-37AF3M/H/X)
AV Unit (Continued)
R2503 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2504 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2505 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2506 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2507 VRS-CJ1JF470JY J 47 1/16W Metal Oxide AA
R2508 VRS-CJ1JF470JY J 47 1/16W Metal Oxide AA
R2509 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2510 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2511 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2512 VRS-CJ1JF470JY J 47 1/16W Metal Oxide AA
R2513 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2514 VRS-CJ1JF470JY J 47 1/16W Metal Oxide AA
R2515 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2516 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R2517 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R2518 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R2520 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R2521 VRS-CY1JF151JY J 150 1/16W Metal Oxide AA
R2522 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2523 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R2524 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2525 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2526 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2527 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R2528 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2529 VRS-CY1JF102FY J 1k 1/16W Metal Oxide AA
R2530 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2531 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2532 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2533 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2546 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2547 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2548 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R2549 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2550 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2551 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R2552 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2553 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2554 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2555 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R3900 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3901 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3902 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3903 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R3904 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R3905 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3906 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3907 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R3908 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3909 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R3910 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R3911 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R3912 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R3913 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R3914 VRS-CY1JF151JY J 150 1/16W Metal Oxide AA
R3915 VRS-CY1JF151JY J 150 1/16W Metal Oxide AA
R3916 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3917 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3918 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3919 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3920 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3921 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3922 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R5701 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R5703 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5705 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R5706 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5709 VRS-CY1JF202FY J 2k 1/16W Metal Oxide AA
R5710 VRS-CY1JF101FY J 100 1/16W Metal Oxide AA
R5711 VRS-CY1JF472FY J 4.7k 1/16W Metal Oxide AA
R5712 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5713 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R5714 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB1100 RBLN-0210TAZZY J Ferrite Beads AB
FB1101 RBLN-0065CEZZY J Ferrite Beads AC
FB1200 RBLN-0051TAZZY J Ferrite Beads AC
FB1201 RBLN-0051TAZZY J Ferrite Beads AC
FB1202 RBLN-0051TAZZY J Ferrite Beads AC
FB1203 RBLN-0051TAZZY J Ferrite Beads AC
FB1204 RBLN-0051TAZZY J Ferrite Beads AC
FB1205 RBLN-0062TAZZY J Ferrite Beads AB
FB1206 RBLN-0051TAZZY J Ferrite Beads AC
FB1207 RBLN-0062TAZZY J Ferrite Beads AB
FB1212 RBLN-0210TAZZY J Ferrite Beads AB
FB1218 RBLN-0061TAZZY J Ferrite Beads AD
FB1219 RBLN-0254TAZZY J Ferrite Beads AB
FB1900 RBLN-0060TAZZY J Ferrite Beads AB
FB1903 RBLN-0060TAZZY J Ferrite Beads AB
FB1904 RBLN-0060TAZZY J Ferrite Beads AB
FB1906 RBLN-0062TAZZY J Ferrite Beads AB
FB1907 RBLN-0062TAZZY J Ferrite Beads AB
FB2500 RBLN-0061TAZZY J Ferrite Beads AD
FB2501 RBLN-0065CEZZY J Ferrite Beads AC
FB2502 RBLN-0062TAZZY J Ferrite Beads AB
FB2503 RBLN-0062TAZZY J Ferrite Beads AB
FB2504 RBLN-0210TAZZY J Ferrite Beads AB
FB2505 RBLN-0210TAZZY J Ferrite Beads AB
FB3901 RBLN-0210TAZZY J Ferrite Beads AB
FB3902 RBLN-0210TAZZY J Ferrite Beads AB
FB3903 RBLN-0210TAZZY J Ferrite Beads AB
FB3904 RBLN-0210TAZZY J Ferrite Beads AB
FB5701 RBLN-0210TAZZY J Ferrite Beads AB
J1200 QSOCD0456CEZZ J Socket, 10Pin AE
J1201 QJAKLA018WJZZ J Jack, 11Pin AF
J1202 QJAKLA018WJZZ J Jack, 11Pin AF
J1203 QTANJA074WJZZ J Terminal, 11Pin AG
J1900 QJAKFA033WJZZ J Jack, 3Pin AD
J2500 QJAKJA007WJZZ J Jack, 8Pin AD
P1200 QPLGNA339WJZZY J Plug, 5Pin(TO KEY (KM)) AD
P1201 QPLGNA344WJZZY J Plug, 10Pin AD
(TO R/C, LED (RA))
P3900 QPLGNA173WJZZY J Plug, 4Pin(SP) AD
P5700 QCNCMA259WJZZ J Connector, 16Pin
(TO POWER (PA))
S1200 QSW-KA028WJZZ J Switch, 7Pin AD
SC1202 QCNCWA284WJZZY J Connector, 52Pin(B to B) AH
SC1900 QSOCZA072WJZZQ J Socket, 23Pin AH
SLD1100 PSLDMA212WJFW J Shield AE
LUG5700 QLUGHA006WJZZY J Lug AC
LUG5701 QLUGHA006WJZZY J Lug AC
LUG5702 QLUGHA006WJZZY J Lug AC
LUG5704 QLUGHA006WJZZY J Lug AC
PRDARA263WJFW J Heat Sink
PSLDMA710WJFW J Shield
PSLDMA711WJFW J Shield
PSLDMA851WJZZ J Shield(LC-26AF3X)
QCNW-D579WJQZ J Connecting Cord AM
(LC-32AF3M)
QCNW-D842WJQZ J Connecting Cord AL
(LC-26AF3H/M/X)
QCNW-D849WJQZ J Connecting Cord AM
(LC-37AF3M)
PSHEPA400WJZZ J Sheet
PSPAZA848WJKZ J Spacer
XBPS730P06WS0 J Screw AA
