Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
106
LC-26AF3 M/H/X
LC-32AF3 M/H/X
LC-37AF3 M/H/X
RUNTKA151WJZZ(LC-26AF3M)
RUNTKA205WJZZ(LC-26AF3H/X)
INVERTER Unit
IC
Z7501 9JG00034070407 J IC, STR-H2013
TRANSISTORS
Q7501 9JG00034094624 J 2SK3561
Q7502 9JG00034094624 J 2SK3561
Q7503 9JG00034004072 J 2SC2412K
Q7504 9JG00034079528 J 2SC3325
Q7505 9JG00034041601 J 2SA1313
Q7506 9JG00034079528 J 2SC3325
Q7507 9JG00034041601 J 2SA1313
Q7511 9JG00034113971 J 2SK3065
Q7515 9JG00034113971 J 2SK3065
Q7519 9JG00034004072 J 2SC2412K
Q7520 9JG00034004072 J 2SC2412K
Q7521 9JG00034004072 J 2SC2412K
Q7522 9JG00034004072 J 2SC2412K
Q7523 9JG00034004072 J 2SC2412K
Q7524 9JG00034004072 J 2SC2412K
Q7525 9JG00034004072 J 2SC2412K
Q7526 9JG00034004072 J 2SC2412K
Q7527 9JG00034004072 J 2SC2412K
Q7529 9JG00034004072 J 2SC2412K
Q7530 9JG00034004072 J 2SC2412K
Q7535 9JG00034027455 J 2SA1037AK
Q7551 9JG00034027455 J 2SA1037AK
Q7552 9JG00034004072 J 2SC2412K
Q7553 9JG00034004072 J 2SC2412K
Q7554 9JG00034004072 J 2SC2412K
Q7555 9JG00034004072 J 2SC2412K
DIODES
D7501 9JG00034001782 J 1SS184
D7502 9JG00034001782 J 1SS184
D7503 9JG00034074631 J RL3A
D7504 9JG00034074631 J RL3A
D7505 9JG00034074623 J RD2A
D7506 9JG00034074623 J RD2A
D7507 9JG00034002967 J 1SS226
D7508 9JG00034002967 J 1SS226
D7509 9JG00034001782 J 1SS184
D7510 9JG00034001782 J 1SS184
D7515 9JG00034001782 J 1SS184
D7516 9JG00034001782 J 1SS184
D7517 9JG00034002967 J 1SS226
D7518 9JG00034001782 J 1SS184
D7519 9JG00034001782 J 1SS184
D7520 9JG00034001782 J 1SS184
D7523 9JG00034001782 J 1SS184
D7524 9JG00034001782 J 1SS184
D7525 9JG00034001782 J 1SS184
DZ7501 9JG00034060223 J Zener Diode, MAZ40270
DZ7502 9JG00034060223 J Zener Diode, MAZ40270
DZ7503 9JG00034060223 J Zener Diode, MAZ40270
DZ7504 9JG00034060223 J Zener Diode, MAZ40270
DZ7505 9JG00034060223 J Zener Diode, MAZ40270
DZ7506 9JG00034060223 J Zener Diode, MAZ40270
DZ7507 9JG00034060223 J Zener Diode, MAZ40270
DZ7508 9JG00034060223 J Zener Diode, MAZ40270
DZ7509 9JG00034060223 J Zener Diode, MAZ40270
DZ7510 9JG00034060223 J Zener Diode, MAZ40270
DZ7511 9JG00034060223 J Zener Diode, MAZ40270
DZ7512 9JG00034060223 J Zener Diode, MAZ40270
DZ7513 9JG00034060223 J Zener Diode, MAZ40270
DZ7514 9JG00034060223 J Zener Diode, MAZ40270
DZ7515 9JG00034060223 J Zener Diode, MAZ40270
DZ7516 9JG00034060223 J Zener Diode, MAZ40270
PHOTOCOUPLERS
PC7501 9JG00034017964 J Photocoupler, PS2571L1-1
PC7502 9JG00034017964 J Photocoupler, PS2571L1-1
PC7503 9JG00034017964 J Photocoupler, PS2571L1-1
PC7504 9JG00034017964 J Photocoupler, PS2571L1-1
PC7505 9JG00034017964 J Photocoupler, PS2571L1-1
PC7506 9JG00034017964 J Photocoupler, PS2571L1-1
PC7507 9JG00034017964 J Photocoupler, PS2571L1-1
PC7508 9JG00034017964 J Photocoupler, PS2571L1-1
PC7509 9JG00034017964 J Photocoupler, PS2571L1-1
PC7510 9JG00034017964 J Photocoupler, PS2571L1-1
PC7511 9JG00034017964 J Photocoupler, PS2571L1-1
PC7512 9JG00034017964 J Photocoupler, PS2571L1-1
PC7513 9JG00034017964 J Photocoupler, PS2571L1-1
PC7514 9JG00034017964 J Photocoupler, PS2571L1-1
PC7515 9JG00034017964 J Photocoupler, PS2571L1-1
PC7516 9JG00034017964 J Photocoupler, PS2571L1-1
TRANSFORMERS
T7501 9JG00034113955 J ST-C0007B
T7502 9JG00037128929 J EXT43141-301
T7503 9JG00034092397 J LU-8-V204
T7504 9JG00034092397 J LU-8-V204
T7505 9JG00034092397 J LU-8-V204
T7506 9JG00034092397 J LU-8-V204
T7507 9JG00034092397 J LU-8-V204
T7508 9JG00034092397 J LU-8-V204
T7509 9JG00034092397 J LU-8-V204
T7510 9JG00034092397 J LU-8-V204
T7511 9JG00034092397 J LU-8-V204
T7512 9JG00034092397 J LU-8-V204
T7513 9JG00034092397 J LU-8-V204
T7514 9JG00034092397 J LU-8-V204
T7515 9JG00034092397 J LU-8-V204
T7516 9JG00034092397 J LU-8-V204
T7517 9JG00034092397 J LU-8-V204
T7518 9JG00034092397 J LU-8-V204
T7519 9JG00034092397 J LU-8-V204
CAPACITORS
C7502 9JG00034003378 J 0.047 630V Film
C7503 9JG00034090181 J 0.22 630V Film
C7504 9JG00034017174 J 0.1 50V Ceramic(CHIP)
C7505 9JG00034017174 J 0.1 50V Ceramic(CHIP)
C7506 9JG00034008434 J 1 25V Ceramic(CHIP)
C7507 9JG00034008434 J 1 25V Ceramic(CHIP)
C7508 9JG00034008434 J 1 25V Ceramic(CHIP)
C7509 9JG00034008434 J 1 25V Ceramic(CHIP)
C7510 9JG00034111758 J 18p 6.3kV Ceramic
C7511 9JG00034017190 J 4700p 50V Ceramic(CHIP)
C7512 9JG00034017166 J 10000p 50V Ceramic(CHIP)
C7515 9JG00034017174 J 0.1 50V Ceramic(CHIP)
C7516 9JG00034005834 J 100p 200V Ceramic(CHIP)
C7517 9JG00034009104 J 0.47 25V Ceramic(CHIP)
C7518 9JG00034009104 J 0.47 25V Ceramic(CHIP)
C7519 9JG00034017093 J 220p 50V Ceramic(CHIP)
C7520 9JG00034017093 J 220p 50V Ceramic(CHIP)
C7521 9JG00034090165 J 22p 6.3kV Ceramic
C7522 9JG00034090165 J 22p 6.3kV Ceramic
C7523 9JG00034090165 J 22p 6.3kV Ceramic
C7524 9JG00034090165 J 22p 6.3kV Ceramic
C7525 9JG00034090165 J 22p 6.3kV Ceramic
C7526 9JG00034090165 J 22p 6.3kV Ceramic
C7527 9JG00034090165 J 22p 6.3kV Ceramic
C7528 9JG00034090165 J 22p 6.3kV Ceramic
C7529 9JG00034090165 J 22p 6.3kV Ceramic
C7530 9JG00034090165 J 22p 6.3kV Ceramic
C7531 9JG00034090165 J 22p 6.3kV Ceramic
C7532 9JG00034090165 J 22p 6.3kV Ceramic
C7533 9JG00034090165 J 22p 6.3kV Ceramic
C7534 9JG00034090173 J 27p 6.3kV Ceramic
C7535 9JG00034090165 J 22p 6.3kV Ceramic
C7536 9JG00034090173 J 27p 6.3kV Ceramic
C7541 9JG00034033099 J 100p 1kV Ceramic
C7542 9JG00034033099 J 100p 1kV Ceramic
C7543 9JG00034033099 J 100p 1kV Ceramic
