ELECTRICAL REPLACEMENT PARTS LIST
B4313 024HC51023 CORE,BEADS FCM1608KF-102T02
B4314 024HC51023 CORE,BEADS FCM1608KF-102T02
B4315 024HC51023 CORE,BEADS FCM1608KF-102T02
B5802 024HC51023 CORE,BEADS FCM1608KF-102T02
B5804 024HC51513 CORE,BEADS FCM1608KF-151T06
B5808 024HC51023 CORE,BEADS FCM1608KF-102T02
B5809 024HC51023 CORE,BEADS FCM1608KF-102T02
B6551 024HC51216 CORE,BEADS HCB1608KF-121T20
B6552 024HC51023 CORE,BEADS FCM1608KF-102T02
B6553 024HC51023 CORE,BEADS FCM1608KF-102T02
B6556 024HC51816 CORE,BEADS HCB1608KF-181T20
L3001 02167E220K COIL 22 UH
L3002 02167E100K COIL 10 UH
L3003 0216S8331K COIL 330 UH
L3004 0216MG220M COIL 22 UH
L3005 02167E220K COIL 22 UH
L3401 0216S8331K COIL 330 UH
L3601 02D1000119 COIL CHOKE EXC28CG900U
L3602 02D1000119 COIL CHOKE EXC28CG900U
L4301 0216S8220K COIL 22 UH
L5801 0216SD220J COIL 22 UH
L5805 021AS9224J COIL 0.22 UH
L6551 0216S8220K COIL 22 UH
*** JACKS ***
J4301 060K411055 RCA JACK AV3-13P2-60S1
*** CONNECTORS ***
CP2804 069S2U005A CONNECTOR PCB SIDE A2006WR0-2X15P-HK
CP3001 06CK7N0301 CORD CONNECTOR TWG-P23P-A1
CP3601 0694YJ3038 CONNECTOR PCB SIDE 5-1903015-4
CP4302 06CK7N0301 CORD CONNECTOR TWG-P23P-A1
CP6202 069S230639 CONNECTOR PCB SIDE A2001WR2-3P
*** CRYSTAL & CERAMIC OSCILLATORS ***
X2801 100GT02728 CRYSTAL SMD-49 C27000B030
X2802 100GT02509 CRYSTAL SMD-49 C25000H025
X3601 100GT01807 CRYSTAL SMD-49 C18432B022
X6201 100GT01615 CRYSTAL B16000E007
X6551 100DT01217 CRYSTAL DS0321SRAB
*** TUNER ***
!
TU5801 0164100026 DIGITAL TUNER ENG36E19KF
*** NETWORKS ***
NR2801 11074100M7 R,NETWORK CRA108100JV
NR2802 11074100M7 R,NETWORK CRA108100JV
NR2803 11074100M7 R,NETWORK CRA108100JV
NR2804 11074100M7 R,NETWORK CRA108100JV
NR2805 11074270M7 R,NETWORK CRA108270JV
NR2806 11074270M7 R,NETWORK CRA108270JV
NR2807 11074270M7 R,NETWORK CRA108270JV
NR2808 11074270M7 R,NETWORK CRA108270JV
NR2809 11074270M7 R,NETWORK CRA108270JV
NR2810 11074220M7 R,NETWORK CRA108220JV
NR2811 11074220M7 R,NETWORK CRA108220JV
NR6551 11074470M7 R,NETWORK CRA108470JV
*** OTHERS ***
CP2801 06GG290029 CONNECTOR PCB SIDE A2001WV-9A
K3-3
