Sharp LC-26DV24U User Manual

ELECTRICAL REPLACEMENT PARTS LIST
CP2803 06GG2C0029 CONNECTOR PCB SIDE A2001WV-12A
CP4301 06GG2E0019 CONNECTOR PCB SIDE A2001WR-14A
CP4303 06G8S21504 CONNECTOR PCB SIDE 1B630020
CP6201 06GG2B0029 CONNECTOR PCB SIDE A2001WV-11A
SH3001 126D000045 TERMINAL PIN YQ-12
SH3002 126D000045 TERMINAL PIN YQ-12
SH3003 126D000045 TERMINAL PIN YQ-12
SH3004 126D000045 TERMINAL PIN YQ-12
SH3005 126D000045 TERMINAL PIN YQ-12
DVD MT PCB ASS'Y
*** PCB ***
PCB130 A50Q01P130 DVD MT PCB ASS'Y DMG097A
*** DIODES ***
D2303 DGERMA1110 DIODE SILICON MA111-(TX)
D2304 DGERMA1110 DIODE SILICON MA111-(TX)
D4002 DGERMA1110 DIODE SILICON MA111-(TX)
D4003 DGERMA1110 DIODE SILICON MA111-(TX)
D4005 DGERMA1110 DIODE SILICON MA111-(TX)
D4008 DGERMA1110 DIODE SILICON MA111-(TX)
D8510 DGERMA1110 DIODE SILICON MA111-(TX)
*** ICS ***
!
IC2301 I03FV65650 5CH MOTOR DRIVER IC LA6565VR-TLM-E
IC4001 ICQK069660 VADDIS9 MPEG/MICON/DSP/RF-AMP ZR36966ELCG-D or
ICQK06966A VADDIS9 MPEG/MICON/DSP/RF-AMP ZR36966ELCG-D-G
IC4005 IF9J0164AG 1M*16*4BANK SDRAM TSOP54 M12L64164A-7TG
IC4007 ICMJ016017 16M FLASH MEMORY PB FREE SST39VF1601-70-4C-EKE
IC8501 I0QF045650 DUAL OPEAMP NJM4565M(TE1)
!
IC8502 I1TF911170 VO=1.5-7V IO=1A TAPING LM1117S-ADJ
*** TRANSISTORS ***
Q2301 TAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P
Q2302 TAAA1544T0 TRANSISTOR SILICON KTA1544T-RTK/P
*** COILS ***
B2304 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B2305 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4001 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4002 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4003 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4005 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4006 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4008 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4010 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4015 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B4016 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B8501 024HC51216 CORE,BEADS HCB1608KF-121T20
B8502 024NC51021 CORE,BEADS EBMS160808A102_RDC45
B8503 024HC51216 CORE,BEADS HCB1608KF-121T20
B8504 024NC51021 CORE,BEADS EBMS160808A102_RDC45
L8501 0216SD2R2J COIL 2.2 UH
L8502 0216SD1R0J COIL 1 UH
L8504 0216SD1R0J COIL 1 UH
*** CONNECTORS ***
CP2301 069KYOT159 CONNECTOR PCB SIDE LD07T2-24ND-03
K3-4
