ELECTRICAL REPLACEMENT PARTS LIST
CP2302 069EV5T060 CONNECTOR PCB SIDE 04_6232_105_015_800+
CP2303 069EV6T060 CONNECTOR PCB SIDE 04_6232_106_015_800+
CP8502 069S280629 CONNECTOR PCB SIDE A2001WV2-8P
*** CRYSTAL & CERAMIC OSCILLATORS ***
X4001 100GT02727 CRYSTAL SMD-49 C27000J029
*** OTHERS ***
CP8501 06GG2E0019 CONNECTOR PCB SIDE A2001WR-14A
SH8501 126D000045 TERMINAL PIN YQ-12
SH8502 126D000045 TERMINAL PIN YQ-12
SH8503 126D000045 TERMINAL PIN YQ-12
SH8504 126D000045 TERMINAL PIN YQ-12
POWER PCB ASS'Y
*** PCB ***
PCB240 A50Q01P240 POWER PCB ASS'Y CEG353A
*** RESISTORS ***
!
R404 RC31X1125J RC 1.2M OHM 1W
!
R406 R3K681S47J R,METAL OXIDE 0.047 OHM 1W
!
R412 R63881R22J R,FUSE 0.22 OHM 1W
!
R416 R65584100J R,FUSE 10 OHM 1/4W
!
R432 R3K781220J R,METAL OXIDE 22 OHM 1W
!
R434 R5X2CE1R2J R,CEMENT 1.2 OHM 7W
!
R445 R002T4101J RC 100 OHM 1/4W
!
R447 R65584150J R,FUSE 15 OHM 1/4W
R473 R3K78A102J R,METAL OXIDE 1K OHM 2W
R481 R3K78A102J R,METAL OXIDE 1K OHM 2W
!
R497 R63881010J R,FUSE 1 OHM 1W
*** CAPACITORS ***
C346 E7EYF4471M CE 470 UF 35V
C349 E7ESF3102M CE 1000 UF 25V
C350 E7ESF3102M CE 1000 UF 25V
C401 C0PLRR7E3K CC 0.0015 UF 2KV R
!
C402 P2122B224M CMP 0.22 UF 275V ECQUL
!
C403 E71JFC391D CE 390 UF 200V
!
C404 E71JFC391D CE 390 UF 200V
!
C406 CD39E0MH3M CC 0.0022UF 250V
!
C423 P4NBE5823H CMPP 0.082 UF 630
C430 C0PLRR7H3K CC 0.0022 UF 2KV R
!
C433 E7EYF4102M CE 1000 UF 35V
C434 E7EYF4122M CE 1200 UF 35V
!
C435 E7EYF3102M CE 1000 UF 25V
!
C438 E7EYF4122M CE 1200 UF 35V
C440 E7EYF0222M CE 2200 UF 6.3V
!
C441 E8E2U52R2D CE 2.2 UF 50V
!
C442 E7ESU5470M CE 47 UF 50V
!
C444 E7EPT0222M CE 2200 UF 6.3V
!
C448 P2122B224M CMP 0.22 UF 275V ECQUL
!
C453 E7EYF2102M CE 1000 UF 16V
!
C455 E8E6FC470M CE 47 UF 200V
!
C462 E7EYF2102M CE 1000 UF 16V
!
C464 CD39E0MH3M CC 0.0022UF 250V
!
C500 E7EPU3101M CE 100 UF 25V
!
C502 E7EPU2101M CE 100 UF 16V
K3-5
