ELECTRICAL REPLACEMENT PARTS LIST
*** DIODES ***
D401 D97U03301B DIODE,ZENER MTZJ33B T-77
!
D404 D6CE24110A DIODE VARISTA ENE241D-10A-Q6
!
D405 D4CKN54060 DIODE SILICON 1N5406FL-6737
D406 D28R1QS040 DIODE EC31QS04-TE12L
!
D407 D4CKN54060 DIODE SILICON 1N5406FL-6737
D408 D1VT001330 DIODE,SILICON 1SS133T-77
D410 D1VT001330 DIODE,SILICON 1SS133T-77
D411 D1VT001330 DIODE,SILICON 1SS133T-77
D412 D97U03R91B DIODE,ZENER MTZJ3.9B T-77
D413 D97U03001B DIODE,ZENER MTZJ30B T-77
!
D415 D2WXN40050 DIODE SILICON 1N4005-EIC
!
D416 D28F31DQ06 DIODE,SILICON 31DQ06-FC
D417 D28R1QS040 DIODE EC31QS04-TE12L
D418 D2WXN40050 DIODE SILICON 1N4005-EIC
D421 D28R1QS040 DIODE EC31QS04-TE12L
D424 D97U03R31B DIODE,ZENER MTZJ3.3B T-77
D425 D97U02701B DIODE,ZENER MTZJ27B T-77
D426 D1VT001330 DIODE,SILICON 1SS133T-77
D427 D97U02701B DIODE,ZENER MTZJ27B T-77
D432 D4AT106FE0 DIODE RECTIFIER RL106F-E
D433 D4AT01H3E0 DIODE RECTIFIER 1H3-E
!
D435 D2CFC91020 DIODE SILICON ERC91-02J11SC
D437 D28AH10A20 DIODE SCHOTTKY BARRIER FCH10A20
!
D440 D2CA2C15R0 DIODE SCHOTTKY BARRIER YG862C15R
!
D442 D4AT01H3E0 DIODE RECTIFIER 1H3-E
!
D443 D28F31DQ09 DIODE SCHOTTKY 31DQ09-FC
!
D444 D2LT001F50 DIODE SILICON 1F5-E
D445 D97U01501B DIODE,ZENER MTZJ15B T-77
D4207 DE7RB1202B DIODE ZENER UDZSNP12B TE-17
D4209 DE7RB1202B DIODE ZENER UDZSNP12B TE-17
D4210 DE7RB1202B DIODE ZENER UDZSNP12B TE-17
D4211 DE7RB1202B DIODE ZENER UDZSNP12B TE-17
D4212 DE7RB1202B DIODE ZENER UDZSNP12B TE-17
D4213 DE7RB1202B DIODE ZENER UDZSNP12B TE-17
D4214 D1VT001330 DIODE,SILICON 1SS133T-77
*** ICS ***
!
IC302 I0FSP7808B SOUND AMP STEREO AN17808B
!
IC401 I2GT050380 VDS=500V RDS1=0.77 RDS2=0.38 MP3A5038
!
IC402 I5SD0P2F40 VD=700V RDS(ON)=9.5OHM MIP2F4
!
IC403 I1KJ9A431A VARIABLE SHUNT REGULATOR TAPE KIA431A-AT
!
IC404 I1KJ9A431A VARIABLE SHUNT REGULATOR TAPE KIA431A-AT
!
IC405 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
!
IC406 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
!
IC407 I03T057790 VIN=30V I0=3A LA5779-E
!
IC408 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
IC409 I1KA97809A 9V REGULATOR 1A KIA7809API
!
IC410 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
IC411 I5HJ0170B0 REGULATOR VO=3.3V IO=800MA S-1170B33UC-OTSTFG
IC412 TJ7T35P020 FET RTQ035P02-TR
IC413 I03F957950 1CH STEP DOWN DC-DC CONTROL LV5795-TE-L-E
IC6502 I0QF027500 4INPUT 1OUTPUT AUDIO SW NJM2750M(TE1)
*** TRANSISTORS ***
Q307 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK
Q401 TAAT01281Y TRANSISTOR SILICON KTA1281_Y
Q403 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q404 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK
Q405 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q406 TC5T021204 TRANSISTOR,SILICON 2SC2120Y(TPE2)
!
Q407 TAAT01281Y TRANSISTOR SILICON KTA1281_Y
Q408 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
K3-6
