ELECTRICAL REPLACEMENT PARTS LIST
Q409 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK
Q410 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q411 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q412 TJ5AK302T0 FET SSM3K302T(TE85L,F)
Q416 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK
Q417 TAAT01281Y TRANSISTOR SILICON KTA1281_Y
Q418 T67J017590 TRANSISTOR SILICON 2SA1759_T100
Q420 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q421 TNAAA05001 COMPOUND TRANSISTOR KRC101S-RTK
Q422 TBA0011510 TRANSISTOR SILICON KTB1151
Q423 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q424 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q425 TJ5AK302T0 FET SSM3K302T(TE85L,F)
Q4211 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q4212 TPAAC05002 COMPOUND TRANSISTOR KRA103SRTK
*** COILS ***
B401 024HT03553 CORE,BEADS W5RH3.5X5X1.0
B404 024HT03553 CORE,BEADS W5RH3.5X5X1.0
!
L401 029X000167 COIL,LINE FILTER SS30V-R200132
L402 029X000166 COIL,LINE FILTER SS11V-R22020-CH
L403 021U0L220M COIL 22 UH
L404 02167E220K COIL 22 UH
L408 021U0L470M COIL 47 UH
L411 02167E100K COIL 10 UH
L413 02167E100K COIL 10 UH
*** TRANSFORMERS ***
!
T401 0481400854 TRANSFORMER,SWITCHING 81400854
!
T402 0481190084 TRANSFORMER,SWITCHING 81190084
*** JACKS ***
J401 064A1A0005 SOCKET,AC YKE31-0149N
J4201 060J131019 HEADPHONE JACK MSJ-2000B_AG(O87)
J4202 063Y700014 JACK DIN-409B
J4203 060K411053 RCA JACK AV3-13P2-31S1
J4205 060R431035 RCA JACK RCA-349-00C-02
J4206 060R431035 RCA JACK RCA-349-00C-02
*** CONNECTORS ***
CP401 06977NM020 CONNECTOR PCB SIDE 127301123K2
CP403 069S280639 CONNECTOR PCB SIDE A2001WR2-8P
CP404 069D01001A CONNECTOR PCB SIDE 003P-2100
CP4201 069S250639 CONNECTOR PCB SIDE A2001WR2-5P
CP4203 06977NM020 CONNECTOR PCB SIDE 127301123K2
*** FUSES ***
!
F401 081PC6R305 FUSE 51MS063L
!
F404 0835C02003 MICRO FUSE 20N_2000FS
FH401 06710T0009 HOLDER,FUSE EYF-52BCY
FH402 06710T0009 HOLDER,FUSE EYF-52BCY
*** OTHERS ***
CP302 06GG140019 CONNECTOR PCB SIDE A2502WR-4A
CP406 06GG2E0019 CONNECTOR PCB SIDE A2001WR-14A
EL2401 124116281A EYE LET XRY16X28BD
EL2402 124120301A EYE LET XRY20X30BD
SH402 126D000045 TERMINAL PIN YQ-12
K3-7
