ELECTRICAL REPLACEMENT PARTS LIST
SH404 126D000045 TERMINAL PIN YQ-12
SH406 126D000045 TERMINAL PIN YQ-12
SH407 126D000045 TERMINAL PIN YQ-12
SH410 126D000045 TERMINAL PIN YQ-12
OPERATION PCB ASS'Y
*** PCB ***
PCB270 A50Q01P270 OPERATION PCB ASS'Y CEG358A
*** SWITCHES ***
SW2201 0504101T34 SWITCH,TACT EVQ21505R
SW2202 0504101T34 SWITCH,TACT EVQ21505R
SW2203 0504101T34 SWITCH,TACT EVQ21505R
SW2204 0504101T34 SWITCH,TACT EVQ21505R
SW2205 0504101T34 SWITCH,TACT EVQ21505R
SW2206 0504101T34 SWITCH,TACT EVQ21505R
*** CONNECTORS ***
CP2203 069S230639 CONNECTOR PCB SIDE A2001WR2-3P
CP2204 06CU221603 CORD CONNECTOR CU221603
OPERATION 2 PCB ASS'Y
*** PCB ***
PCB280 A50Q01P280 OPERATION 2 PCB ASS'Y CEG361A
*** SWITCHES ***
SW2251 0504101T34 SWITCH,TACT EVQ21505R
SW2252 0504101T34 SWITCH,TACT EVQ21505R
SW2253 0504101T34 SWITCH,TACT EVQ21505R
SW2254 0504101T34 SWITCH,TACT EVQ21505R
SW2255 0504101T34 SWITCH,TACT EVQ21505R
*** CONNECTORS ***
CP2251 069S220639 CONNECTOR PCB SIDE A2001WR2-2P
AND OTHERS
*** CONNECTORS ***
CD2202 06CU233301 CORD CONNECTOR CU233301
CD2804 06CURU1704 CORD CONNECTOR CURU1704
CD8501 06CU2E2701 CORD CONNECTOR CU2E2701
CD8502 06CU282701 CORD CONNECTOR CU282701
*** AC CORD ***
CD3805 120Q119906 CORD SET AC P201-2739-1
*** OTHERS ***
BT001 141R003018 BATTERY,MANGAN GR6M
BT002 141R003018 BATTERY,MANGAN GR6M
CD301 06E8144301 CORD CONNECTOR E8144301
CD406 06E82E1301 CORD CONNECTOR E82E1301
CD2201 06E8253101 CORD CONNECTOR E8253101
CUS151 800WFAA006 CUSHION A
!
SP301 070Y056007 SPEAKER S0412F06
K3-8
