132
LC-26GA5E
LC-32GA5E
LC-26GA5E
LC-32GA5E
REF No. PARTS DESCRIPTION * SN CODE EX CODE
Q4112 VS2SB1132Q/-1Y 2SB1132Q J AC AC
Q7701 VSDTC114EE/-1Y DTC114EE J AB AB
DIODES
D2004 VHDMA157A//-1Y MA157A J AC AC
D2005 VHD1SS355//-1Y 1SS355 J AB AB
D4101 VHDHSU119//-1Y HSU119 J AB AB
D4102 VHDLi124+++-1Y Li124+++ J AC AC
D4103 VHDHSU119//-1Y HSU119 J AB AB
D4104 VHDHSU119//-1Y HSU119 J AB AB
D4105 VHDLi114+++-1Y Li114+++ J AC AC
D4106 RH-EX1274CEZZY Zener Diode, 13V J AB AB
D4107 VHDHSU119//-1Y HSU119 J AB AB
D4108 VHDLi114+++-1Y Li114+++ J AC AC
D4109 VHDLi124+++-1Y Li124+++ J AC AC
D4110 VHDDA221///-1Y DA221 J AB AB
D4501 VHDDAN222//-1Y DAN222 J AA AA
D7705 VHDHSU119//-1Y HSU119 J AB AB
D7707 VHDHSU119//-1Y HSU119 J AB AB
D7712 VHDSC8024//-1Y SC8024 J AC AC
D7713 VHDSC8024//-1Y SC8024 J AC AC
D7714 VHDLi114+++-1Y Li114+++ J AC AC
D7715 VHDDAN222//-1Y DAN222 J AA AA
D7718 VHD1SS355//-1Y 1SS355 J AB AB
D7719 VHD1SS355//-1Y 1SS355 J AB AB
D7720 VHD1SS355//-1Y 1SS355 J AB AB
PACKAGED CIRCUIT
X2001 RCRSC0032TAZZY Crystal, 32.768MHz J AG AG
X4601 RCRUAA048WJZZY Crystal, 83.565MHz J
FILTERS AND COILS
FL2001 RFiLZ0169TAZZY Filter J AD AD
FL4103 RFiLNA002WJZZY Filter J AD AD
FL4651 RFiLNA002WJZZY Filter J AD AD
FL4652 RFiLNA002WJZZY Filter J AD AD
FL4653 RFiLNA002WJZZY Filter J AD AD
FL4654 RFiLNA002WJZZY Filter J AD AD
L4101 RCiLP0343TAZZY Coil 10uH J AD AD
L4102 RCiLCA039WJZZY Coil 68uH J AF AF
L4103 RCiLP0355TAZZY Coil 4.7uH J AD AD
L4104 RCiLP0343TAZZY Coil 10uH J AD AD
L4105 VPD9M4R7J1R4NY Peaking 4.7uH J AB AB
L4106 RCiLPA001WJZZY Coil 10uH J AF AF
L4107 VPBWM220K1R2NY Peaking 22uH J AC AC
L4108 VPBWM220K1R2NY Peaking 22uH J AC AC
L4109 RCiLP0343TAZZY Coil 10uH J AD AD
L4110 VPD9M4R7J1R4NY Peaking 4.7uH J AB AB
L7701 RCiLP0343TAZZY Coil 10uH J AD AD
L7712 RCiLCA095WJZZY Coil 470uH J AD AD
L7713 RCiLP0343TAZZY Coil 10uH J AD AD
CAPACITORS
C2001 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2002 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2003 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2004 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2006 VCCCCY1HH220JY
22p 50V Ceramic
JAA AA
C2007 VCCCCY1HH220JY
22p 50V Ceramic
JAA AA
C2008 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2009 VCKYCY1HB102KY
1000p 50V Ceramic
JAA AA
C2010 VCKYCY1HB103KY
0,01 50V Ceramic
JAA AA
C2012 VCKYCY1HB102KY
1000p 50V Ceramic
JAA AA
C2013 VCKYCY1HB102KY
1000p 50V Ceramic
JAA AA
C2014 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2015 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2016 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2017 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2020 VCKYCY1HB103KY
0,01 50V Ceramic
JAA AA
C2021 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
REF No. PARTS DESCRIPTION * SN CODE EX CODE
C2022 VCEASY1CN107MY
100 16V Electrolytic
JAC AC
C2023 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2024 VCCCCY1HH102JY
1000p 50V Ceramic
JAB AB
C2025 VCKYCY1HB103KY
0,01 50V Ceramic
JAA AA
C2032 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2035 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C2036 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4101 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4102 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4103 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4106 RC-KZ0070TAZZY
4,7 16V Ceramic
JAD AD
C4108 RC-KZ0070TAZZY
4,7 16V Ceramic
JAD AD
C4109 VCCCCY1HH680JY
68p 50V Ceramic
JAA AA
C4110 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4112 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4114 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4115 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4116 RC-KZA047WJZZY
1 50V Ceramic
JAC AC
C4117 VCEASY1CN477MY
470 16V Electrolytic
JAD AD
C4119 VCAAPF1DJ226MY
22 20V Electrolytic
JAF AF
C4120 VCCCCY1HH5R0CY
5p 50V Ceramic
JAA AA
C4121 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4124 VCCCCY1HH680JY
68p 50V Ceramic
JAA AA
C4125 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4127 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4129 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4135 VCKYTV1CB105KY
1 16V Ceramic
JAC AC
C4136 VCAAPF1DJ226MY
22 20V Electrolytic
JAF AF
C4137 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4138 VCEASY1EN227MY
220 25V Electrolytic
JAD AD
C4139 VCKYTV1CB105KY
1 16V Ceramic
JAC AC
C4141 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4142 VCKYCY1HB102KY
1000p 50V Ceramic
JAA AA
C4145 RC-KZ0070TAZZY
4,7 16V Ceramic
JAD AD
C4146 VCAAPF1CJ396MY
39 16V Electrolytic
JAF AF
C4147 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4153 RC-KZA097WJZZY
1 16V Ceramic
JAD AD
C4155 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4156 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4159 VCEASY1EN476MY
47 25V Electrolytic
JAC AC
C4160 VCEASY1HN106MY
10 50V Electrolytic
JAC AC
C4161 RC-KZ0070TAZZY
4,7 16V Ceramic
JAD AD
C4162 VCCCCY1HH391JY
390p 50V Ceramic
JAB AB
C4163 RC-KZA047WJZZY
1 50V Ceramic
JAC AC
C4164 VCKYCY1CF224ZY
0,22 16V Ceramic
JAB AB
C4165 VCCCCY1HH101JY
100p 50V Ceramic
JAA AA
C4166 VCCCCY1HH221JY
220p 50V Ceramic
JAA AA
C4168 RC-KZ0053TAZZY
10 10V Ceramic
JAD AD
C4169 VCAAPF1DJ396MY
39 20V Electrolytic
JAF AF
C4170 VCCCCY1HH101JY
100p 50V Ceramic
JAA AA
C4174 RC-KZ0053TAZZY
10 10V Ceramic
JAD AD
C4176 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4177 VCAAPF1DJ226MY
22 20V Electrolytic
JAF AF
C4179 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4180 VCEASY1EN227MY
220 25V Electrolytic
JAD AD
C4181 RC-KZ0070TAZZY
4,7 16V Ceramic
JAD AD
C4192 VCKYCY1HB152KY
1500p 50V Ceramic
JAA AA
C4195 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4196 VCEASX1VN226MY
22 35V Electrolytic
JAC AC
C4197 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4501 VCEASY0JN476MY
47 6.3V Electrolytic
JAC AC
C4502 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4503 VCKYCY1HB102KY
1000p 50V Ceramic
JAA AA
C4504 VCEASY0JN476MY
47 6.3V Electrolytic
JAC AC
C4505 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4506 VCKYCY1HB102KY
1000p 50V Ceramic
JAA AA
C4507 VCEASY0JN476MY
47 6.3V Electrolytic
JAC AC
C4508 VCKYCY1EF104ZY
0,1 25V Ceramic
JAA AA
C4509 VCKYCY1HB102KY
1000p 50V Ceramic
JAA AA
