Sharp LC-26GA5F - Page 139

139
LC-26GA5E
LC-32GA5E
LC-26GA5E
LC-32GA5E
REF No. PARTS DESCRIPTION * SN CODE EX CODE
RCILC1273SNEZT
CHOK COIL TSL0709 (470u)
J
--
(97000359-R00W)
(CHOK COIL) (SL7568CL471KT)
J
--
L705 97000360-R00P
CHOK COIL TSL1618(220u)
J
--
L706
No number
J
--
RCILC1279SNEZT
CHOK COIL TSL1112(33u)
J
--
(97000358-R00W)
(CHOK COIL) (SL1011CL330KT)
J
--
L708 RCILC1262SNEZT
CHOK COIL TSL1112(1u)
J
--
L709 RCILC1280SNEZ
CHOK COIL A7503HY-471M
J
--
RCILC1279SNEZT
CHOK COIL TSL1112(33u)
J
--
(97000358-R00W)
(CHOK COIL) (SL1011CL330KT)
J
--
L711
No number
J
--
L712
No number
J
--
RCILC1279SNEZT
CHOK COIL TSL1112(33u)
J
--
(97000358-R00W)
(CHOK COIL) (SL1011CL330KT)
J
--
L714 97000360-R00P
CHOK COIL TSL1618(220u)
J
--
RCILC1279SNEZT
CHOK COIL TSL1112(33u)
J
--
(97000358-R00W)
(CHOK COIL) (SL1011CL330KT)
J
--
L716 91320142-R001
LINEFILTER HF2836-353Y1R0-T01 35mH 1.0A
J
--
TRANSFORMERS
T701 RTRNP1266SNEZ
TRANSFORMER P1266
J
--
RTRNP1261SNEZ
TRANSFORMER UF1717V-282Y0R5-01
J
--
(91320136-R00L)
(TRANSFORMER) (0.42A302U9)
J
--
T703 RTRNP1277SNEZ
TRANSFORMER P1267
J
--
T704 RTRNP1268SNEZ
TRANSFORMER P1268
J
--
T705 RTRNP1268SNEZ
TRANSFORMER P1268
J
--
T706 RTRNP1272SNEZ
TRANSFORMER P1272
J
--
CAPACITORS
RCM2E224LEMSC
FILM CAPACITOR 0.22u LE-M 275V
J
--
웉RC-M2E224RESC웊 (FILM CAPACITOR) (0.22u RE) (275V)
J
--
RCM2E224LEMSC
FILM CAPACITOR 0.22u LE-M 275V
J
--
웉RC-M2E224RESC웊 (FILM CAPACITOR) (0.22u RE) (275V)
J
--
C703 01013020-R002
CERAMIC CAPACITOR 2200p CS(KH) 250V
J
--
C704 01013020-R002
CERAMIC CAPACITOR 2200p CS(KH) 250V
J
--
C705 01013020-R002
CERAMIC CAPACITOR 2200p CS(KH) 250V
J
--
C706 RC-M2G824MDSC
FILM CAPACITOR 0.82u MMC(MDS) 400V
J
--
C707 RC-M2G824MDSC
FILM CAPACITOR 0.82u MMC(MDS) 400V
J
--
C708 RCK45R3D221KVT
CERAMIC CAPACITOR 220p RR(HR) 2KV
J
--
RC-E2W826KXGZ
ELECTROLYTIC CAPACITOR 82u KXG 450V
J
--
(RC-E2W826KMGZ)
(ELECTROLYTIC CAPACITOR) (82u KMG) (450V)
J
--
RC-E2W826KXGZ
ELECTROLYTIC CAPACITOR 82u KXG 450V
J
--
(RC-E2W826KMGZ)
(ELECTROLYTIC CAPACITOR) (82u KMG) (450V)
J
--
C711 VCKYCY1HB103K-
CERAMIC CAPACITOR 0.01u 50V
J
--
C712 RC-E1H226SNKYT
ELECTROLYTIC CAPACITOR 22u KY 50V
J
--
C713 VCKYCY1HB103K-
CERAMIC CAPACITOR 0.01u 50V
J
--
C714 VCKYTV1EB224K-
CERAMIC CAPACITOR 0.22u 25V
J
--
C715 VCKYCY1HB103K-
CERAMIC CAPACITOR 0.01u 50V
J
--
C716 VCKYCY1HB103K-
CERAMIC CAPACITOR 0.01u 50V
J
--
C717 VCKYCY1HB473K-
CERAMIC CAPACITOR 0.047u 50V
J
--
C718 VCKYTQ1VB105K-
CERAMIC CAPACITOR 1u 35V
J
--
C719 VCKYCY1HB222K-
CERAMIC CAPACITOR 2200p 50V
J
--
C720 VCKYCY1HB102K-
CERAMIC CAPACITOR 1000p 50V
J
--
C721 VCKYCY1EB104K-
CERAMIC CAPACITOR 0.1u 25V
J
--
C722 VCKYCY1HB102K-
CERAMIC CAPACITOR 1000p 50V
J
--
C723 RCM2W334HCE-S
FILM CAPACITOR 0.33u HCE-S 450V
J
--
C724 VCKYTV1EB224K-
CERAMIC CAPACITOR 0.22u 25V
J
--
C725 VCKYCY1HB102K-
CERAMIC CAPACITOR 1000p 50V
J
--
C726 VCKYCY1EB104K-
CERAMIC CAPACITOR 0.1u 25V
J
--
C727 VCKYCY1HB103K-
CERAMIC CAPACITOR 0.01u 50V
J
--
C728 VCKYCY1HB102K-
CERAMIC CAPACITOR 1000p 50V
J
--
C729 RC-CSE2GA332M
CERAMIC CAPACITOR 3300p CS(KH) 250V
J
--
C730 RC-CSE2GA332M
CERAMIC CAPACITOR 3300p CS(KH) 250V
J
--
C731 VCKYCY1EB104K-
CERAMIC CAPACITOR 0.1u 25V
J
--
C732 RC-E1H226SNKYT
ELECTROLYTIC CAPACITOR 22u KY 50V
J
--
C733 RCK45R3D471KVT
CERAMIC CAPACITOR 470p RR(HR) 2KV
J
--
RC-E2W336KXGZ
ELECTROLYTIC CAPACITOR 33u KXG 450V
J
--
(RC-E2W336KMGZ)
(ELECTROLYTIC CAPACITOR) (33u KMG) (450V)
J
--
C735 VCKYCY1EB104K-
CERAMIC CAPACITOR 0.1u 25V
J
--
C736 VCKYCY1HB102K-
CERAMIC CAPACITOR 1000p 50V
J
--
C737
No number
J
--
C738
No number
J
--
C739 RCM2W224HCE-S
FILM CAPACITOR 0.22 HCE-S 450V
J
--
C740 VCKYCY1EB104K-
CERAMIC CAPACITOR 0.1u 25V
J
--
C741 VCKYCY1HB103K-
CERAMIC CAPACITOR 0.01u 50웷
J
--
C710
C734
T702
C701
C702
C709
L707
L710
L713
L715
L704
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
REF No. PARTS DESCRIPTION * SN CODE EX CODE
D725 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D726 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D727 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D728 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D729 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D730 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D731 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D732 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D733 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D734 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D735 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D736 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D737 VHEHZU16B2/-1-
DIODE(ZENER) HZU16B2
J
--
D738
No number
J
--
D739
No number
J
--
D740
No number
J
--
D741 VHDSFPB74//-1-
DIODE(SBD) SR24(SFPB74)
J
--
D742 VHEHZU5.1B2-1-
DIODE(ZENER) HZU5.1B2
J
--
D743 VHDDAN217//-1-
DIODE BVA99(DAN217)
J
--
D744 VHDDAN217//-1-
DIODE BVA99(DAN217)
J
--
D745 VHDDAN217//-1-
DIODE BVA99(DAN217)
J
--
D746 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D747 VHEHZU16B2/-1-
DIODE(ZENER) HZU16B2
J
--
D748 VHEHZU16B2/-1-
DIODE(ZENER) HZU16B2
J
--
D749 VHERLZ36B//-1-
DIODE(ZENER) HZK36(RLZ36B)
J
--
D750
No number
J
--
D751
No number
J
--
D752
No number
J
--
D753
No number
J
--
D754 VHEHZU6.8B2-1-
DIODE(ZENER) HZU6.8B2
J
--
D755
No number
J
--
D756 VHDSFPB74//-1-
DIODE(SBD) SR24(SFPB74)
J
--
D757 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D758 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D759
No number
J
--
D760 VHERLZ8.2A/-1-
DIODE(ZENER) HZK9A(RLZ8.2A)
J
--
D761 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D763 VHDS1WBA60B-1
DIODE(BRD) DI106(S1WBA60B)
J
--
D764 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D765 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D766 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D767 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D768 VHDSFPL52V/-1-
DIODE ES1D(SFPL52)
J
--
D769 VHDSFPB74//-1-
DIODE(SBD) SR24(SFPB74)
J
--
D770 VHERLZ5.6B/-1-
DIODE(ZENER) RLZ5.6B
J
--
D771 VHDRLS245//-1-
DIODE HSK83(RLS245)
J
--
D772
No number
J
--
D773
No number
J
--
D774 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D775 VHDSFPB74//-1-
DIODE(SBD) SR24(SFPB74)
J
--
D776
No number
J
--
D777 VHDSFPB74//-1-
DIODE(SBD) SR24(SFPB74)
J
--
D778 VHDSFPB74//-1-
DIODE(SBD) SR24(SFPB74)
J
--
D779 VHDSFPB74//-1-
DIODE(SBD) SR24(SFPB74)
J
--
D780 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D781 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D782 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D783 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D784 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D785 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D786 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D787 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D788
No number
J
--
D789 VRS-TP2BD000J-
RESISTOR 0 1/8W
J
--
D790 VHD1SS355//-1-
DIODE 1N4148WS(1SS355)
J
--
D791
No number
J
--
D792
No number
J
--
D793
No number
J
--
D794 VHEHZU8.2B2-1-
DIODE(ZENER) HZU8.2B2
J
--
D795 02021136-R001
DIODE BAW56
J
--
COILS
L701 91320142-R001
LINEFILTER HF2836-353Y1R0-T01 35mH 1.0A
J
--
L702 91320142-R001
LINEFILTER HF2836-353Y1R0-T01 35mH 1.0A
J
--
L703 RCILC1289SNEZ
PFC CHOK COIL C1289
J
--
!
!
!
