143
LC-26GA5E
LC-32GA5E
LC-26GA5E
LC-32GA5E
REF No. PARTS DESCRIPTION * SN CODE EX CODE
Q729 VS2SA1213-/-1-
TRANSISTOR 2SA1213 -50V 2A J - -
Q730 VS2SC2873/Y-1-
TRANSISTOR 2SC2873 50V 2A J - -
Q731 VS2SA1213-/-1-
TRANSISTOR 2SA1213 J - -
Q732 VS2SC2873/Y-1-
TRANSISTOR 2SC2873 J - -
Q733 VS2SD1781KQ-1-
TRANSISTOR 2SD1781 J - -
Q734 VS2SK3236//-1
MOS FET 2SK3236 J - -
Q735 VS2SA1036KQRC-
TRANSISTOR 2SA1036 J - -
Q736 VS2SC2411KR-1-
TRANSISTOR 2SC2411KR J - -
Q737
No number
J- -
Q738 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q739
No number
J- -
Q740 VS2SD1782K/-1-
TRANSISTOR 2SD1782 J - -
Q741 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q742 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q743 VS2SC2411KR-1-
TRANSISTOR 2SC2411KR J - -
Q744 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q745 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q746 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q747 VSDTA124EK/-1-
TRANSISTOR DTA124EKA J - -
Q748 VSDTA114EK/-1-
TRANSISTOR DTA114EKA J - -
Q749 VS2SC2411KR-1-
TRANSISTOR 2SC2411KR J - -
Q750 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q751 VS2SK3236//-1
MOS FET 2SK3236 J - -
Q753
No number
J- -
Q754
No number
J- -
Q755 VSDTA114EK/-1-
TRANSISTOR DTA114EKA J - -
Q756 VSDTC124EK/-1-
TRANSISTOR DTC124EKA J - -
Q758 VSDTC114EK/-1-
TRANSISTOR DTC114EKA J - -
Q759 VSDTC114EK/-1-
TRANSISTOR DTC114EKA J - -
08080310-R005
MOS FET 2SJ317 12V 2A J - -
(080080323-R005)
(MOS FET) (2SJ224) (12V 2A) J - -
Q761 VSDTC124EK/-1-
TRANSISTOR DTC124EKA 50V 30mA J - -
Q762 VSDTC124EK/-1-
TRANSISTOR DTC124EKA 50V 30mA J - -
DIODES
D701 VHDD3SB60//-1
DIODE GBJ4J(D3SB60) J - -
D702 VHERLZ39B//-1-
DIODE(ZENER) HZK36(RLZ39B) J - -
D703 VHERLZ39B//-1-
DIODE(ZENER) HZK36(RLZ39B) J - -
D704 VHDDAN202K/-1-
DIODE BAV70(DAN202K) J - -
VHDFFPF10U60S
DIODE FFPF10U60STU J - -
-
(DIODE) (YG972S6R) J - -
D706 VHDDAN202K/-1-
DIODE BAV70(DAN202K) J - -
D707 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D708 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D709 VHDDAN202K/-1-
DIODE BAV70(DAN202K) J - -
D710 VHERLZ27B//-1-
DIODE(ZENER) HZK27(RLZ27B) J - -
D711 VHDDAN202K/-1-
DIODE BAV70(DAN202K) J - -
D712 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D713 VHDDAN202K/-1-
DIODE BAV70(DAN202K) J - -
D714 VHEHZU15B2/-1-
DIODE(ZENER) HZU15B2 J - -
D715 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D716 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D717 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D718 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D719 VHDSFPL52V/-1-
DIODE ES1D(SFPL52) J - -
DIODE ES1J J - -
(DIODE) (RS1J) J - -
DIODE ES1J J - -
(DIODE) (RS1J) J - -
D722 VHERLZ8.2A/-1-
DIODE(ZENER) HZK9A(RLZ8.2A) J - -
D723 VHDRLS245//-1-
DIODE HSK83(RLS245) J - -
D724 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D725 VHDRLS245//-1-
DIODE HSK83(RLS245) J - -
D726 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D727 VHDRLS245//-1-
DIODE HSK83(RLS245) J - -
D728 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D729 VHDRLS245//-1-
DIODE HSK83(RLS245) J - -
D730 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D731 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D732 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D733 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D734 VHDRLS245//-1-
DIODE HSK83(RLS245) J - -
D735 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D736 VHD1SS355//-1-
DIODE 1N4148WS(1SS355) J - -
D737 VHEHZU16B2/-1-
DIODE(ZENER) HZU16B2 J - -
D705
D720
D721
Q760
REF No. PARTS DESCRIPTION * SN CODE EX CODE
LX-BZ1001SNEZ
for INLET ANGLE 3x8ᄼBIS
J
--
LX-BZ1001SNEZ
for INLET ANGLE 3x8ᄼBIS
J
--
03700481-R003
037-sne-A HEATSINK A AL t=2mm
J
--
03700482-R003
037-sne-B HEATSINK B AL t=2mm
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
XBPSN30P08ES0
for HEAT DISSIPATION BOARD M3X8ES0ᄼNickel
J
--
VT-ESG1U02200
TUBE GLASS TUBE 22mm for TH701
J
--
VT-ESG1U02200
TUBE GLASS TUBE 22mm for TH701
J
--
VT-IX0065ULV2
TUBE V2ᄼAWG22 10mm for F704
J
--
VT-IX0065ULV2
TUBE V2ᄼAWG22 10mm for F704
J
--
PWB-F
LC-32GA5E POWER SUPPLY UNIT
(RDENCA102WJZZ)
INTEGRATED CIRCUITS
IC701 VHIMC33262D-1-
PFC IC MC33262D J - -
05000005-R007
SHUNT REGULATOR KIA431A(1%) J - -
(VHITA76431S-1T)
(SHUNT REGULATOR) (TA76431S (1.5%)) J - -
(05000005-R008)
(SHUNT REGULATOR) (HA17431HP(1%)) J - -
IC703 VHITNY266P/-1
IC TNY266P J - -
IC704 VHINJM2125F-1-
Operational Amplifiers NJM2125F J - -
IC705 VHIOZ961ISN-1-
IC OZ961ISN J - -
05000005-R007
SHUNT REGULATOR KIA431A(1%) J- -
(VHITA76431S-1T)
(SHUNT REGULATOR) (TA76431S (1.5%)) J- -
(05000005-R008)
(SHUNT REGULATOR) (HA17431HP(1%)) J- -
IC707
No numbe
J- -
IC708 VHIMP1583P/-1
STEP dwon DC/DC MP1583 (DIP) J - -
IC709 VHIMP1580P/-1
STEP dwon DC/DC MP1580 (DIP) J - -
IC710
No numbe
J- -
05000005-R007
SHUNT REGULATOR KIA431A(1%) J - -
(VHITA76431S-1T)
(SHUNT REGULATOR) (TA76431S (1.5%)) J - -
(05000005-R008)
(SHUNT REGULATOR) (HA17431HP(1%)) J - -
IC713 VHIXC6202PC02-
Voltage REG LDO XC6202PC02PR J - -
IC715 VHIMP1583P/-1
STEP dwon DC/DC MP1583 (DIP) J - -
TRANSISTORS
Q701 VSFQPF12N60C1
MOS FET FQPF12N60C 600V 12A J - -
Q702 VSFQPF12N60C1
MOS FET FQPF12N60C 600V 12A J - -
Q703 VS2SA1213-/-1-
TRANSISTOR 2SA1213 -50V 2A J - -
Q704 VS2SA1213-/-1-
TRANSISTOR 2SA1213 -50V 2A J - -
Q705 VS2SC2873/Y-1-
TRANSISTOR 2SC2873 50V 2A J - -
Q706 VSDTA124EK/-1-
TRANSISTOR DTA124EKA -50V 30mA J - -
Q707 VSDTA124EK/-1-
TRANSISTOR DTA124EKA -50V 30mA J - -
Q708 VSDTA124EK/-1-
TRANSISTOR DTA124EKA -50V 30mA J - -
Q709 VSDTD114EK/-1-
TRANSISTOR DTD114EKA 50V 500mA J - -
Q710 VS2SK3520-01M
MOS FET 2SK3520-01MR 500V 9A J - -
Q711 VS2SK3520-01M
MOS FET 2SK3520-01MR 500V 9A J - -
Q712 VS2SD1781KQ-1-
TRANSISTOR 2SD1781 32V 0.8A J - -
Q713 VSDTA143EK/-1-
TRANSISTOR DTA143EKA -50V -100mA J - -
Q714 VS2SC2411KR-1-
TRANSISTOR 2SC2411KR 32V 0.5A J - -
Q715 VS2SB1198K/-1-
TRANSISTOR 2SB1198 -80V -500mA J - -
Q716 VS2SC2412K/-1-
TRANSISTOR 2SC2412K 50V 0.15A J - -
08010253-R002
MOS FET FQPF9N50C 500V 9A J - -
(VS2SK3520-01M)
(MOS FET) (2SK3520-01MR) 500V 9A J - -
Q718 VS2SC2873/Y-1-
TRANSISTOR 2SC2873 50V 2A J - -
08010253-R002
MOS FET FQPF9N50C 500V 9A J - -
(VS2SK3520-01M)
(MOS FET) (2SK3520-01MR) 500V 9A J - -
Q720 VS2SC2873/Y-1-
TRANSISTOR 2SC2873 50V 2A J - -
08010253-R002
MOS FET FQPF9N50C 500V 9A J - -
(VS2SK3520-01M)
(MOS FET) (2SK3520-01MR) 500V 9A J - -
Q722 VS2SC2873/Y-1-
TRANSISTOR 2SC2873 50V 2A J - -
08010253-R002
MOS FET FQPF9N50C 500V 9A J - -
(VS2SK3520-01M)
(MOS FET) (2SK3520-01MR) 500V 9A J - -
Q724 VS2SC2873/Y-1-
TRANSISTOR 2SC2873 50V 2A J - -
Q725 VS2SC2412K/-1-
TRANSISTOR 2SC2412K 50V 0.15A J - -
Q726 VS3LN01C-//-1-
MOS FET 3LN01C 30V 0.15A J - -
Q727 VS3LN01C-//-1-
MOS FET 3LN01C 30V 0.15A J - -
Q728 VS2SA1037AK-1-
TRANSISTOR 2SA1037 -50V -0.15A J - -
Q719
Q721
Q723
IC702
IC706
IC712
Q717
