REF No. PARTS DESCRIPTION * SN CODE EX CODE

PWB-G

LC-26GA5E INVERTER UNIT (1)

(RUNTKA094WJZZ)

DIODES

D7501 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7502 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7503 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7504 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7505 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7506 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7507 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7508 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7509 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7510 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7511 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7512 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7513 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

D7514 VHDDAN217u/-1-

Diode DAN217u 80V/100mA J - -

TRANSFORMERS

T7501 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7502 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7503 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7504 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7505 RTRNZ1273SNEZ

Transformer CLT4123 J - -

T7506 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7507 RTRNZ1273SNEZ

Transformer CLT4123 J - -

T7508 RTRNZ1273SNEZ

Transformer CLT4123 J - -

T7509 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7510 RTRNZ1273SNEZ

Transformer CLT4123 J - -

T7511 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7512 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7513 RTRNZ1274SNEZ

Transformer CLT4123 J - -

T7514 RTRNZ1274SNEZ

Transformer CLT4123 J - -

CAPACITORS

C7501 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7502 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7503 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7504 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

C7505 VCKYCY1HB682K-

Ceramic capacitor 6800pF 50V J - -

C7506 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7507 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7508 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7509 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

C7510 VCKYCY1HB682K-

Ceramic capacitor 6800pF 50V J - -

C7511 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7512 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7513 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7514 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

C7515 VCKYCY1HB682K-

Ceramic capacitor 6800pF 50V J - -

C7516 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7517 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7518 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7519 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

C7520 VCKYCY1HB682K-

Ceramic capacitor 6800pF 50V J - -

C7521 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7522 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7523 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7524 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

C7525 VCKYCY1HB682K-

Ceramic capacitor 6800pF 50V J - -

C7526 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7527 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7528 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7529 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

C7530 VCKYCY1HB682K-

Ceramic capacitor 6800pF 50V J - -

C7531 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7532 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7533 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7534 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

C7535 VCKYCY1HB682K-

Ceramic capacitor 6800pF 50V J - -

C7536 VCKYTV1EB475K-

Ceramic capacitor 4.7uF 25V J - -

C7537 VCKYTQ2AB473K-

Ceramic capacitor 0.047uF 100V J - -

C7538 RC-ECC3H120JY-

Mid-high vol. Ceramic capacitor 12pF 5kV J - -

C7539 VCKYCY1HB153K-

Ceramic capacitor 0.015uF 50V J - -

REF No. PARTS DESCRIPTION * SN CODE EX CODE

R906

No number

J- -

R907

No number

J- -

R908 VRS-TS2AD103J-

RESISTOR 10K 1/10W J - -

R909 VRS-TS2AD152J-

RESISTOR 1.5K 1/10W J - -

R910 VRS-TS2AD561J-

RESISTOR 560 1/10W J - -

R911 VRS-TS2AD561J-

RESISTOR 560 1/10W J - -

R912 VRS-TS2AD223J-

RESISTOR 22K 1/10W J - -

R913 VRS-TS2AD000J-

RESISTOR 0 1/10W J - -

R914 VRS-TS2AD562J-

RESISTOR 5.6K 1/10W J - -

R915 VRS-TS2AD000J-

RESISTOR 0 1/10W J - -

R916 VRS-TS2AD000J-

RESISTOR 0 1/10W J - -

MISCELLANEOUS PARTS

F701 QFS-A1164SNEZT

FUSE 4A/250V TR5(382) J - -

F702 QFS-A1164SNEZT

FUSE 4A/250V TR5(382) J - -

F703 QFS-A1129SNEZT

FUSE 2A/250V TR5(382) J - -

F704 QFS-T1107SNEZ

THERMAL CUTOFFS X25 117ദ 2A P110A J - -

F705 QFS-A1154SNEZ

FUSE DCP10ᄼ1A/DC450V J - -

CN701 07200056-R004

INLET 0721-6-PP J - -

CN702

No number

J- -

CN703 QCNCM1827SNEZ

CONNECTORᄼ 12pin 12PL-FJ J - -

CN704 QCNCM1853SNEZ

CONNECTORᄼ 16pin B16B-PNDZS-1 J - -

CN705 QCNCM1833SNEZ

CONNECTORᄼ 2pin B02B-PASK-1 J - -

CN706 QCNCM1834SNEZ

CONNECTORᄼ 13pin B13B-XASK-1-A J - -

CN707 00700579-R00O

CONNECTORᄼᄼ6pin B06B-PASK-1 J - -

CN708 QCNCM1827SNEZ

CONNECTORᄼ 12pin 12PL-FJ J - -

VHPPC123X2YFZ

OPTICAL ISOLATER PC123X2YFZ J - -

웉VHPPS2581L1-1웊

(OPTICAL ISOLATER) (PS2581L1) J - -

VHPPC123X2YFZ

OPTICAL ISOLATER PC123X2YFZ J - -

웉VHPPS2581L1-1웊

(OPTICAL ISOLATER) (PS2581L1) J - -

VHPPC123X2YFZ

OPTICAL ISOLATER PC123X2YFZ J - -

웉VHPPS2581L1-1웊

(OPTICAL ISOLATER) (PS2581L1) J - -

VHPPC123X2YFZ

OPTICAL ISOLATER PC123X2YFZ J - -

웉VHPPS2581L1-1웊

(OPTICAL ISOLATER) (PS2581L1) J - -

VHPPC123X2YFZ

OPTICAL ISOLATER PC123X2YFZ J - -

웉VHPPS2581L1-1

웊

(OPTICAL ISOLATER) (PS2581L1) J - -

VHPPC123X2YFZ

OPTICAL ISOLATER PC123X2YFZ J - -

웉VHPPS2581L1-1웊

(OPTICAL ISOLATER) (PS2581L1) J - -

VT-ESG1U02200

TUBE GLASS TUBE 22mm for TH701 J - -

VT-ESG1U02200

TUBE GLASS TUBE 22mm for TH701 J - -

VT-IX0065ULV2

TUBE V2ᄼAWG22 10mm for F704 J - -

VT-IX0065ULV2

TUBE V2ᄼAWG22 10mm for F704 J - -

VA701

No number

J- -

VHVTNR10V471KT

VARISTOR TNR10V471K J - -

(VHVNV470D10-C)

(VARISTOR) (NV470D10) J - -

(VHVENC471D10S)

(VARISTOR) (ENC471D10A) J - -

VHVTNR10V471KT

VARISTOR TNR10V471K J - -

(VHVNV470D10-C)

(VARISTOR) (NV470D10) J - -

(VHVENC471D10S)

(VARISTOR) (ENC471D10A) J - -

RRLYD1012SNEZ

RELAY G5RL1A DC5 AC250V 10A TV5 J - -

(RRLYD1011SNEZ)

(RELAY웊 (FTR-H1AA005T) AC250V 10A TV5 J - -

GA701

No number

J- -

07500018-R00A

EARTH TERMINAL JG-10-T J - -

07500018-R00A

EARTH TERMINAL JG-10-T J - -

07500018-R00A

EARTH TERMINAL JG-10-T J - -

07500018-R00A

EARTH TERMINAL JG-10-T J - -

LANGK3001SNEZ

INLET ANGLE LANGK3001SNEZ J - -

LX-BZ1001SNEZ

for INLET ANGLE 3x8ᄼBIS J - -

LX-BZ1001SNEZ

for INLET ANGLE 3x8ᄼBIS J - -

03700481-R003

037-sne-A HEATSINK A AL t=2mm J - -

03700482-R003

037-sne-B HEATSINK B AL t=2mm J - -

XBPSN30P08ES0
