149

LC-26GA5E

LC-32GA5E

LC-26GA5E

LC-32GA5E

REF No. PARTS DESCRIPTION * SN CODE EX CODE

R7672 VRS-CY1JD751J-

Resistor 750 1/10W

J- -

R7674 VRS-CY1JD751J-

Resistor 750 1/10W

J- -

R7676 VRS-CY1JD751J-

Resistor 750 1/10W

J- -

R7678 VRS-CY1JD751J-

Resistor 750 1/10W

J- -

R7680 VRS-CY1JD751J-

Resistor 750 1/10W

J- -

R7682 VRS-CY1JD751J-

Resistor 750 1/10W

J- -

R7684 VRS-CY1JD751J-

Resistor 750 1/10W

J- -

MISCELLANEOUS PARTS

JP7601 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7602 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7603 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7606 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7607 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7608 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7609 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7610 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7611 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7612 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7613 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7614 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7615 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7616 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7617 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7618 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7619 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7620 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7621 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7622 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7623 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

JP7624 VRS-TP2BD000J-

Resistor 0 (3216) 1/4W

J- -

CN7601 QCNCM1848SNEZ-

Connectorᄼᄼ4pin BM04B-PASS 3A/250V

J- -

CN7602 QCNCM1821SNEZ-

Connector 1717823-1 1A/1800V

J- -

CN7603 QCNCM1821SNEZ-

Connector 1717823-1 1A/1800V

J- -

CN7604 QCNCM1821SNEZ-

Connector 1717823-1 1A/1800V

J- -

CN7605 QCNCM1821SNEZ-

Connector 1717823-1 1A/1800V

J- -

CN7606 QCNCM1821SNEZ-

Connector 1717823-1 1A/1800V

J- -

CN7607 QCNCM1821SNEZ-

Connector 1717823-1 1A/1800V

J- -

CN7608 QCNCM1821SNEZ-

Connector 1717823-1 1A/1800V

J- -

TH7606 VHH18XH103J03-

Thermistor

J- -

LUG7602 QTAND1019SNEZ-

GND lug terminal SD01138-21

J- -

LUG7603 QTAND1019SNEZ-

GND lug terminal SD01138-21

J- -

PWB-H

LC-32GA5E INVERTER UNIT (2)

(RUNTKA097WJZZ)

DIODES

웥웘웕웑웒 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑웓 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑월 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑웕 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑웖 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑웗 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑웘 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑웙 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웑웚 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웒웑 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웒웒 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웒웓 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웒월 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웒웕 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웒웖 VHD1SS270A/-FA Diode 1SS270A J - -

웥웘웕웒웗 VHD1SS270A/-FA Diode 1SS270A J - -

TRANSFORMERS

웵웘웕웑웒 RTRNZ1277SNEZ Transformer TLCP4123 J - -

웵웘웕웑웓 RTRNZ1277SNEZ Transformer TLCP4123 J - -

웵웘웕웑월 RTRNZ1277SNEZ Transformer TLCP4123 J - -

웵웘웕웑웕 RTRNZ1277SNEZ Transformer TLCP4123 J - -

웵웘웕웑웖 RTRNZ1278SNEZ Transformer TLCP4123 J - -

웵웘웕웑웗 RTRNZ1278SNEZ Transformer TLCP4123 J - -

웵웘웕웑웘 RTRNZ1278SNEZ Transformer TLCP4123 J - -

웵웘웕웑웙 RTRNZ1278SNEZ Transformer TLCP4123 J - -

CAPACITORS

웤웘웕웑웒 RCFK201E475KNT Ceramic capacitor 4.7uF 25V J - -

REF No. PARTS DESCRIPTION * SN CODE EX CODE

Q7609 VSUM6K1N///-1-

MOS FET UM6K1N 30V/100mA J- -

Q7610 VSUM6K1N///-1-

MOS FET UM6K1N 30V/100mA J- -

Q7611 VSUM6K1N///-1-

MOS FET UM6K1N 30V/100mA J- -

Q7612 VSUM6K1N///-1-

MOS FET UM6K1N 30V/100mA J- -

Q7613 VSUM6K1N///-1-

MOS FET UM6K1N 30V/100mA J- -

Q7614 VSUM6K1N///-1-

MOS FET UM6K1N 30V/100mA J- -

DIODES

D7601 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7602 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7603 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7604 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7605 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7606 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7608 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7609 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7610 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7611 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7612 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7613 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7614 VHD1SS355//-1-

Diode 1SS355 90V/100mA J- -

D7621 VHDDAN217u/-1-

Diode DAN217U 80V/100mA J- -

CAPACITORS

C7601 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7602 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7603 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7604 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7605 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7606 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7608 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7609 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7610 VCKYCY1CB224K-

Ceramic capacitor 0.22uF J- -

C7611 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7612 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7613 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

C7614 VCKYCY1CB224K-

Ceramic capacitor 0.22uF 16V J- -

RESISTORS

R7601 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7603 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7605 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7607 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7609 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7611 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7613 VRS-CY1JD332F-

Resistor 3.3k(F) 1/10W J- -

R7614 VRS-CY1JD242F-

Resistor 2.4k(F) 1/10W J- -

R7615 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7617 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7619 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7621 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7623 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7625 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7627 VRS-CY1JD155J-

Resistor 1.5M 1/10W J- -

R7630 VRS-TP2BD104J-
