LC-26SA1E/RU, LC-32SA1E/RU
4 – 4
17.Remove the 8 lock screws and the 6 lock screws , detach the LCD Angle.
18.Remove the LCD Panel Unit from Front Cabinet.
18
19
18
18
18
19
18
19
LCD Panel Unit Front Cabinet
LCD Angle
