Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C735 RC-EZA489WJZZ+ AC J Capacitor, 47 35V Electrolytic
C736 RC-EZA489WJZZ+ AC J Capacitor, 47 35V Electrolytic
C739 VCCCCY1HH102JY AB J Capacitor, 1000p 50V Ceramic
!
C740 RC-KZ0105GEZZ AD J Capacitor, 2200p 250V Ceramic
!
C741 RC-KZ0105GEZZ AD J Capacitor, 2200p 250V Ceramic
!
C742 RC-KZ0105GEZZ AD J Capacitor, 2200p 250V Ceramic
C743 RC-EZA513WJZZ AH N J Capacitor, 470 50V Electrolytic
C744 RC-EZA499WJZZ AH N J Capacitor, 1200 35V Electrolytic
C745 VCKYCY1HB472KY AA J Capacitor, 4700p 50V Ceramic
C749 VCKYTV1HB683KY AB J Capacitor, 0.068 50V Ceramic
C751 RC-EZA499WJZZ AH N J Capacitor, 1200 35V Electrolytic
C752 RC-EZA452WJZZ AG N J Capacitor, 2200 10V Electrolytic
C753 VCKYTV1HB683KY AB J Capacitor, 0.068 50V Ceramic
C754 RC-EZA510WJZZ AF N J Capacitor, 220 50V Electrolytic
C755 RC-EZA499WJZZ AH N J Capacitor, 1200 35V Electrolytic
C756 RC-EZA452WJZZ AG N J Capacitor, 2200 10V Electrolytic
C757 RC-EZA480WJZZ AD J Capacitor, 680 25V Electrolytic
C758 RC-EZA490WJZZ+ AD J Capacitor, 100 35V Electrolytic
C762 RC-EZA513WJZZ AH N J Capacitor, 470 50V Electrolytic
C763 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C764 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C765 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C767 RC-EZA510WJZZ AF N J Capacitor, 220 50V Electrolytic
C768 RC-EZA452WJZZ AG N J Capacitor, 2200 10V Electrolytic
C771 VCKYCY1HB272KY AA J Capacitor, 2700p 50V Ceramic
C772 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C774 VCKYCY1CB104KY AB J Capacitor, 0.1 16V Ceramic
C776 RC-KZA213WJZZY AC J Capacitor, 4.7 25V Ceramic
!
C777 RC-KZ0105GEZZ AD J Capacitor, 2200p 250V Ceramic
!
C778 RC-KZ0105GEZZ AD J Capacitor, 2200p 250V Ceramic
C781 VCFYAA2JA103K+ AC J Capacitor, 0.01 630V
C782 VCFYAA2JA103K+ AC J Capacitor, 0.01 630V
C783 RC-KZA213WJZZY AC J Capacitor, 4.7 25V Ceramic
C789 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C790 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C792 VCKYCY1AB105KY AB J Capacitor, 1 10V Ceramic
C793 VCKYCY1CB104KY AB J Capacitor, 0.1 16V Ceramic
C794 RC-KZA388WJZZY AC J Capacitor, 10 6.3V Ceramic
C795 VCKYCY1AB105KY AB J Capacitor, 1 10V Ceramic
C796 VCKYCY1AB105KY AB J Capacitor, 1 10V Ceramic
C798 VCKYCY1CB104KY AB J Capacitor, 0.1 16V Ceramic
C799 VCKYCY1CB104KY AB J Capacitor, 0.1 16V Ceramic
C800 VCKYCY1CB104KY AB J Capacitor, 0.1 16V Ceramic
C801 VCKYCY1CB104KY AB J Capacitor, 0.1 16V Ceramic
C804 VCKYCY1CB104KY AB J Capacitor, 0.1 16V Ceramic
!
D701 RH-DX0477CEZZ AF J Diode, D5SB60
D707 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D714 RH-EX1396CEZZY AB J Zener Diode, UDZSTE-176.8B (LC-26SA1E/F/I/K/RU)
D714 RH-EX1398CEZZY AB J Zener Diode, UDZSTE-178.2B (LC-32SA1E/F/I/K/RU)
D715 VHDD1FL20U/-1Y AC J Diode, D1FL20U
D716 VHDU05NU44+-1Y AE N J Diode, U05NU44(TE12L,Q)
D717 VHDD1FL20U/-1Y AC J Diode, D1FL20U
D718 RH-EXA091WJZZY AB J Zener Diode, UDZSTE-1711B
D720 VHDU05NU44+-1Y AE N J Diode, U05NU44(TE12L,Q)
D721 RH-EXA096WJZZY AB J Zener Diode, UDZSTE-1718B
D722 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D724 VHDD1FL20U/-1Y AC J Diode, D1FL20U
D725 VHDD1FL20U/-1Y AC J Diode, D1FL20U
D726 VHDD1FL20U/-1Y AC J Diode, D1FL20U
D728 VHEST03D170-1 AG N J Zener Diode, HEST03D170
D729 VHEST03D170-1 AG N J Zener Diode, HEST03D170
!
D730 RH-FXA003WJZZ AD J Photo Coupler, PC123Y82
!
D731 RH-FXA003WJZZ AD J Photo Coupler, PC123Y82
!
D732 RH-FXA003WJZZ AD J Photo Coupler, PC123Y82
!
D733 RH-FXA003WJZZ AD J Photo Coupler, PC123Y82
!
D734 RH-FXA003WJZZ AD J Photo Coupler, PC123Y82
D735 VHDSF6L20U+-1 AG J Diode, SF6L20U
D736 RH-DXA080WJZZ AK J Diode, SF20JC10-7100
D737 RH-DXA081WJZZ AH J Diode, D15SCA4M-7000
D738 RH-DXA088WJZZY AD N J Diode, D1FL40-5063
D739 RH-DXA085WJZZ AK N J Diode, D5S9M-7000
D741 RH-EX1398CEZZY AB J Zener Diode, UDZSTE-178.2B
D742 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D746 RH-EXA102WJZZY AB N J Zener Diode, UDZSTE-1733B
D747 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D748 RH-EXA094WJZZY AB J Zener Diode, UDZSTE-1715B
D749 RH-EX1400CEZZY AB J Zener Diode, UDZSTE-1710B
D751 RH-EX1398CEZZY AB J Zener Diode, UDZSTE-178.2B
D752 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D753 RH-EXA094WJZZY AB J Zener Diode, UDZSTE-1715B
D754 RH-EXA101WJZZY AB J Zener Diode, UDZSTE-1730B
D755 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D756 RH-EXA101WJZZY AB J Zener Diode, UDZSTE-1730B
D757 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
[4] DUNTKD605FM10/FM11 (POWER Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
