Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
D759 RH-EXA101WJZZY AB J Zener Diode, UDZSTE-1730B
D761 VHDD1FL20U/-1Y AC J Diode, D1FL20U
D762 VHEST03D170-1 AG N J Zener Diode, HEST03D170
D763 RH-EX1394CEZZY AB J Zener Diode, UDZSTE-175.6B
D765 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D767 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D771 VHEST03D-82-1 AG N J Zener Diode, HEST03D-82
D772 RH-EXA102WJZZY AB N J Zener Diode, UDZSTE-1733B
D773 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D774 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D775 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D776 RH-EX1234CEZZY AE J Zener Diode, HZU3.6B2TRF
D777 VHDU05NU44+-1Y AE N J Diode, U05NU44(TE12L,Q)
D778 VHDU05NU44+-1Y AE N J Diode, U05NU44(TE12L,Q)
D779 VHD1SS355//-1Y AB N J Diode, 1SS355TE-17
D780 RH-EX1015GEZZY AD J Zener Diode, PTZTE2516B
D781 RH-EX1015GEZZY AD J Zener Diode, PTZTE2516B
D782 RH-EXA359WJZZY AE N J Zener Diode, PTZTE2533B
D783 RH-EXA359WJZZY AE N J Zener Diode, PTZTE2533B
E701 LANGQA027WJFW AE N J Inlet Angle
!
F701 QFS-ZA007WJZZ AC J Fuse, T4AL/250V
IC704 VHIMR4020++-1 AQ J IC, MR4020-7101 (LC-26SA1E/F/I/K/RU)
IC704 VHIMR4030++-1 AR J IC, MR4030-7101 (LC-32SA1E/F/I/K/RU)
IC705 VHIMR4020++-1 AQ J IC, MR4020-7101
IC706 VHITA76431R-1Y AE N J IC, TA76431FR(TE12L,F)
IC707 VHITA76431R-1Y AE N J IC, TA76431FR(TE12L,F)
IC708 VHINJM2904M-1Y AE J IC, NJM2904M-TE1
IC709 VHINJM2903M-1Y AE N J IC, NJM2903M-TE1
!
L701 RCILFA209WJZZ AH J Coil (LC-26SA1E/F/I/K/RU)
!
L701 RCILFA211WJZZ AG N J Coil (LC-32SA1E/F/I/K/RU)
!
L702 RCILFA036WJZZ AG J Coil (LC-26SA1E/F/I/K/RU)
!
L702 RCILF0024PEZZ AN J Coil (LC-32SA1E/F/I/K/RU)
L753 RCILPA642WJZZ AE N J Coil
LUG701 QLUGHA002WJZZ AB J Lug
LUG702 QLUGHA002WJZZ AB J Lug
LUG703 QLUGHA002WJZZ AB J Lug
LUG704 QLUGHA002WJZZ AB J Lug
P701 QCNCMA250WJZZ AE J Connector, 23Pin
P702 QCNCMA247WJZZ AD J Connector, 9Pin
P703 QPLGZ0738CEZZ AC J Plug, 7Pin
P704 QPLGNA053WJZZ AF N J Plug, 14Pin(LA)
Q702 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q704 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q708 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q710 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q712 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q713 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q721 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q723 RH-TXA037WJZZY AE N J Transistor, PBLS6003D,115
Q724 RH-TXA037WJZZY AE N J Transistor, PBLS6003D,115
Q726 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q729 VS2SD2185R+-1Y AF N J Transistor, 2SD21850RL
Q730 RH-TXA026WJZZY AD J Transistor, PBLS2001D,115
Q731 RH-TXA026WJZZY AD J Transistor, PBLS2001D,115
!
R701 RR-HZ0008GEZZY AE N J Resistor
!
R702 RR-HZ0008GEZZY AE N J Resistor
R727 VRS-TV1JD563JY AA J Resistor, 56k 1/16W Metal Oxide
R730 VRS-TQ2EF124FY AA N J Resistor, 120k 1/4W Metal Oxide
R731 VRS-TQ2EF124FY AA N J Resistor, 120k 1/4W Metal Oxide
R732 VRS-TQ2EF124FY AA N J Resistor, 120k 1/4W Metal Oxide
R740 VRS-TV1JD564JY AA J Resistor, 560k 1/16W Metal Oxide
R741 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R742 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R743 VRS-CY1JF224JY AA J Resistor, 220k 1/16W Metal Oxide
R745 VRS-TV1JD912JY AA J Resistor, 9.1k 1/16W Metal Oxide
R746 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R747 VRS-TV1JD682FY J Resistor, 6.8k 1/16W Metal Oxide (LC-26SA1E/F/I
R747 VRS-TV1JD103FY AA J Resistor, 10k 1/16W Metal Oxide (LC-32SA1E/F/I/
R748 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R751 VRN-VV3DBR15J AB J Resistor, 0.15 2W Metal Film (LC-26SA1E/F/I/K/R
R751 VRN-VV3DBR10J AB J Resistor, 0.1 2W Metal Film (LC-32SA1E/F/I/K/RU
R752 VRS-TV1JD000JY AA J Resistor, 0 1/16W Metal Oxide
R753 VRS-TV1JD133JY AA J Resistor, 13k 1/16W Metal Oxide
R755 VRS-TV1JD203FY AA J Resistor, 20k 1/16W Metal Oxide
R756 VRS-TV1JD183FY AA J Resistor, 18k 1/16W Metal Oxide
R757 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R758 VRS-TV1JD564JY AA J Resistor, 560k 1/16W Metal Oxide
R759 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R760 VRN-VV3DBR15J AB J Resistor, 0.15 2W Metal Film
R761 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R764 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R765 VRS-TV1JD104JY AA J Resistor, 100k 1/16W Metal Oxide
R766 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R767 VRS-TQ2EF391JY AA J Resistor, 390 1/4W Metal Oxide
R770 VRS-TQ2BD000JY AA J Resistor, 0 1/8W Metal Oxide
[4] DUNTKD605FM10/FM11 (POWER Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
