Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
9
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R773 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R774 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R775 VRS-TV1JD153FY AA J Resistor, 15k 1/16W Metal Oxide
R776 VRS-TV1JD102JY AA J Resistor, 1k 1/16W Metal Oxide
R777 VRS-TV1JD242FY AA J Resistor, 2.4k 1/16W Metal Oxide
R778 VRS-TV1JD242FY AA J Resistor, 2.4k 1/16W Metal Oxide
R779 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R780 VRS-TV1JD682JY AA J Resistor, 6.8k 1/16W Metal Oxide
R781 VRS-TV1JD242FY AA J Resistor, 2.4k 1/16W Metal Oxide
R782 VRS-TV1JD102JY AA J Resistor, 1k 1/16W Metal Oxide
R783 VRS-TV1JD223JY AA J Resistor, 22k 1/16W Metal Oxide
R784 VRS-TV1JD242JY AA J Resistor, 2.4k 1/16W Metal Oxide
R785 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R787 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R788 VRS-TV1JD202FY AA J Resistor, 2.0k 1/16W Metal Oxide
R789 VRS-TV1JD681FY AA J Resistor, 680 1/16W Metal Oxide
R791 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R792 VRS-TV1JD272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R793 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R794 VRS-TV1JD821FY AA J Resistor, 820 1/16W Metal Oxide
R795 VRS-TV1JD203FY AA J Resistor, 20k 1/16W Metal Oxide
R796 VRS-TV1JD272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R797 VRS-TV1JD104FY AA J Resistor, 100k 1/16W Metal Oxide
R801 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R805 VRS-TV1JD224JY AA J Resistor, 220k 1/16W Metal Oxide
R809 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R812 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R817 VRS-TQ2EF122JY AA J Resistor, 1.2k 1/4W Metal Oxide
R820 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R823 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R824 VRS-TQ2EF332JY AA J Resistor, 3.3k 1/4W Metal Oxide
R825 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R828 VRS-TQ2EF220JY AA J Resistor, 22 1/4W Metal Oxide
R831 VRS-TV1JD103JY AA J
Resistor, 10k 1/16W Metal Oxide
R833 V
RS-TQ2EF223FY AA N J Resistor, 22k 1/4W Metal Oxide
R834 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R835 VRS-TQ2BD000JY AA J Resistor, 0 1/8W Metal Oxide
R836 VRS-TV1JD103JY AA J Resistor, 10k 1/16W Metal Oxide
R851 VRS-TQ2EF221JY AA J Resistor, 220 1/4W Metal Oxide
R852 VRS-TQ2EF221JY AA J Resistor, 220 1/4W Metal Oxide
R854 VRS-VV3DB102J AA J Resistor, 1k 2W Metal Oxide
R857 VRS-TQ2BD000JY AA J Resistor, 0 1/8W Metal Oxide
R858 VRS-TV1JD272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R859 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R860 VRS-CY1JF472JY AA J Resistor, 4.7k 1/16W Metal Oxide
R861 VRS-CY1JF272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R862 VRS-CY1JF272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R863 VRS-CY1JF472JY AA J Resistor, 4.7k 1/16W Metal Oxide
R864 VRS-CY1JF333JY AA J Resistor, 33k 1/16W Metal Oxide
R865 VRS-CY1JF333JY AA J Resistor, 33k 1/16W Metal Oxide
R866 VRS-CY1JF473JY AA J Resistor, 47k 1/16W Metal Oxide
R867 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R868 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R869 VRS-CY1JF332JY AA J Resistor, 3.3k 1/16W Metal Oxide
R870 VRS-CY1JF222JY AA J Resistor, 2.2k 1/16W Metal Oxide
R871 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R872 VRS-CY1JF472JY AA J Resistor, 4.7k 1/16W Metal Oxide
R873 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R877 VRS-TQ2EF124FY AA N J Resistor, 120k 1/4W Metal Oxide
R878 VRS-TQ2EF124FY AA N J Resistor, 120k 1/4W Metal Oxide
!
RDA701 PRDARA323WJFW AG N J Heat Sink (for D701)
RDA702 PRDARA306WJFW AG N J Heat Sink (for IC705)
RDA703 PRDARA307WJFW AK N J Heat Sink (for IC704)
RDA704 PRDARA308WJFW AH N J Heat Sink (for SUB-C)
RDA705 PRDARA309WJFW AH N J Heat Sink (for INV-C)
RJ1 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RJ2 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RJ3 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RJ4 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
!
RY701 RRLYDA008WJZZ AG J Relay
SC701 QSOCAA008WJZZ AE J Socket, 2Pin(AC Inlet)
!
T701 RTRNWA230WJZZ AP J Transformer
!
T702 RTRNWA232WJZZ AP J Transformer, (LC-26SA1E/F/I/K/RU)
!
T702 RTRNWA231WJZZ AR N J Transformer, (LC-32SA1E/F/I/K/RU)
!
T703 RTRNCA021WJZZ AW J Choke Transformer, (LC-26SA1E/F/I/K/RU)
!
T703 RTRNCA022WJZZ AW N J Choke Transformer, (LC-32SA1E/F/I/K/RU)
!
TH701 RH-HXA033WJZZ AG N J Thermistor, 16D2-13LCS
!
VA701 RH-VXA071WJQZ AD N J Varista, ERZV10D471CS
!
VA702 RH-VXA071WJQZ AD N J Varista, ERZV10D471CS
N LX-BZ3049GEF7 AA J Screw
N LX-BZ3049GEF7 AA J Screw
N LX-BZ3049GEF7 AA J Screw
N LX-BZ3049GEF7 AA J Screw, x3
N LX-BZ3049GEF7 AA J Screw
[4] DUNTKD605FM10/FM11 (POWER Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
