Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
7 – 5
40 R0XC+ I TMDS input clock pair. HDMI Port 0
39 R0XC- I TMDS input clock pair. HDMI Port 0
44 R0X0+ I TMDS input data pair. HDMI Port 0
43 R0X0- I TMDS input data pair. HDMI Port 0
48 R0X1+ I TMDS input data pair. HDMI Port 0
47 R0X1- I TMDS input data pair. HDMI Port 0
52 R0X2+ I TMDS input data pair. HDMI Port 0
51 R0X2- I TMDS input data pair. HDMI Port 0
59 R1XC+ I TMDS input clock pair. HDMI Port 1
58 R1XC- I TMDS input clock pair. HDMI Port 1
63 R1X0+ I TMDS input data pair. HDMI Port 1
62 R1X0- I TMDS input data pair. HDMI Port 1
67 R1X1+ I TMDS input data pair. HDMI Port 1
66 R1X1- I TMDS input data pair. HDMI Port 1
71 R1X2+ I TMDS input data pair. HDMI Port 1
70 R1X2- I TMDS input data pair. HDMI Port 1
23,79,92,
105,114,
128,139
CVCC18 – Digital Logic VCC.
24,80,91,
106,115,
127,138
CGND – Digital Logic GND.
5,26,76,89,
109,122,
134
IOVCC – Input/Output Pin VCC.
4,25,75,
90,108,
120,135
IOGND – Input/Output Pin GND.
38,42,46,
50,57,61,
65,69
AVCC – TMDS Analog VCC.
41,45,49,
53,60,64,
68,72
AGND – TMDS Analog GND.
37 PVCC0 – TMDS Port 0 PLL VCC.
55 PVCC1 – TMDS Port 1 PLL VCC.
54 TMDSPGND – TMDS PLL GND.
13 DACVCCR – DAC Red VDD.
12 DACGNDR – DAC Red GND.
16 DACVCCG – DAC Green VDD.
15 DACGNDG – DAC Green GND.
19 DACVCCB – DAC Blue VDD.
18 DACGNDB – DAC Blue GND.
6 DACOVCC – DAC Output VCC.
7 DACAVCC – DAC Analog VCC.
8 DACAGND – DAC Analog GND.
22 DACVCC18 – DAC Digital VCC.
21 DACGND – DAC Digital GND.
94 AUDPVCC18 – ACR PLL VCC.
95 AUDPGND – ACR PLL GND.
35,74 DVCC18 – ACR PLL Digital VCC.
36,73 DGND – ACR PLL GND.
98 XTALVCC – ACR PLL Crystal Input VCC.
99 REGVCC – ACR PLL Regulator VCC.
Pin No. Pin Name Type Description
