LC-26SA1E/RU, LC-32SA1E/RU
7 – 8
31 SIFIN+ I Differential Sound IF Input SIF
32 SIFIN- I Differential Sound IF Input –
33 VSUP5.0 – Supply Voltage Analog, 5.0 V +5V
34 GNDA – Ground Analog, Platform Ground GND
35 GND3.3DIG – Ground Digital Interfaces GND
36 VSUP3.3DIG – Supply Voltage Digital Interfaces, 3.3 V 3.3V
37 SPDIF_OUT O SPDIF Output open
38 I2S_DA_IN I Audio Bus Data Input I2S_D1
39 I2S_CL I Audio Bus Clock Input A2S-CL
40 I2S_WS I Audio Bus Word Strobe Input I2S_WS
41 I2S_DEL_OUT I/O Audio Delay Line Bus Data Output/Input open
42 I2S_DEL_IN I/O Audio Delay Line Bus Data Input/Output open
43 I2S_DEL_CL I/O Audio Delay Line Bus Clock Output/Input open
44 I2S_DEL_WS I/O Audio Delay Line Word Strobe Output/Input open
45 VSUP3.3RAM – Supply Voltage Ram, 3.3 V 3.3V
46 GND3.3RAM – Ground Ram GND
47 DVS I Digital or Analog Video VSYNC HD Input DVSYNC
48 DEN I Digital or Analog Video VSYNC HD Input DINEN
49 DCLK I Digital Video Clock Input DINCK
50 DRI7 I Digital Video Red 7 Input DINR [7]
51 DRI6 I Digital Video Red 6 Input DINR [6]
52 DRI5 I Digital Video Red 5 Input DINR [5]
53 DRI4 I Digital Video Red 4 Input DINR [4]
54 DRI3 I Digital Video Red 3 Input DINR [3]
55 DRI2 I Digital Video Red 2 Input DINR [2]
56 DRI1 I Digital Video Red 1 Input DINR [1]
57 DRI0 I Digital Video Red 0 Input (LSB) DINR [0]
58 DGI7 I Digital Video Green 7 Input DING [7]
59 DGI6 I Digital Video Green 6 Input DING [6]
60 DGI5 I Digital Video Green 5 Input DING [5]
61 DGI4 I Digital Video Green 4 Input DING [4]
62 DGI3 I Digital Video Green 3 Input DING [3]
63 DGI2 I Digital Video Green 2 Input DING [2]
64 DGI1 I Digital Video Green 1 Input DING [1]
65 DGI0 I Digital Video Green 0 Input (LSB) DING [0]
66 DBI7 I Digital Video Blue 7 Input DINB [7]
67 DBI6 I Digital Video Blue 6 Input DINB [6]
68 DBI5 I Digital Video Blue 5 Input DINB [5]
69 DBI4 I Digital Video Blue 4 Input DINB [4]
70 DBI3 I Digital Video Blue 3 Input DINB [3]
71 DBI2 I Digital Video Blue 2 Input DINB [2]
72 DBI1 I Digital Video Blue 1 Input DINB [1]
73 DBI0 I Digital Video Blue 0 Input (LSB) DINB [0]
74 GND3.3DRI – Ground Digital Ram Interface GND
75 VSUP3.3DRI – Supply Voltage Digital Ram Interface, 3.3 V 3.3V
76 GND3.3COM – Ground Common GND
77 VSUP3.3COM – Supply Voltage Common, 3.3V 3.3V
78 XTALIN I Analog Crystal Input X_IN
79 XTALOUT O Analog Crystal Output X_OUT
80 CLKOUT O Digital 20MHz Clock Output open
81 VSO O Vertical Sync Output, Frontend open
82 HSO O Horizontal Sync Output, Frontend open
83 SCL I/O I2C Bus Clock Input/Output BU_SCL3
84 SDA I/O I2C Bus Data Input/Output BU_SDA3
85 GND3.3FL – Ground Flash GND
86 VSUP3.3FL – Supply Voltage Flash, 3.3 V 3.3V
87 P2_0 I/O Port 2, Bit 0 Input/Output AVLK1
88 P2_1 I/O Port 2, Bit 1 Input/Output AVLK2
89 P2_2 I/O Port 2, Bit 2 Input/Output IRIN
90 P2_3 I/O Port 2, Bit 3 Input/Output KEY-PSW
91 P2_4 I/O Port 2, Bit 4 Input/Output TXD
92 P2_5 I/O Port 2, Bit 5 Input/Output RXD
93 OSDV I/O Graphic Vertical Sync Input/Output open
94 OSDH I/O Graphic Horizontal Sync Input/Output open
Pin No. Pin Name I/O Pin Function Sheet Name
