LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
63
B3 UDM
I SSTL
F3
LDM
I SSTL
Data Mask Upper/Lower Byte
Power Supplies ×16 Organization
J2 V
REF
AI — I/O Reference Voltage
E9, G1, G3, G7, G9 V
DDQ
PWR
—
I/O Driver Power Supply
J1 V
DDL
PWR
—
Power Supply
E1, J9, M9, R1 V
DD
PWR —
Power Supply
E7, F2, F8, H2, H8 V
SSQ
PWR —
I/O Driver Power Supply
J7 V
SSDL
PWR —
Power Supply
A3, 3,J3,N1,P9 V
SS
PWR —
Power Supply
Not Connected ×16 Organization
A2, E2, L1, R3, R7, R8 NC
NC
— Not Connected
Other Pins ×16 Organization
K9 ODT
I
SSTL On-Die Termination Control
2.5. U601 (LM4809MA NOPB SO-8)
2.5.1 Pin Connections and short description
2.6. U600 (TDA8932BTW HTSSOP32)
2.6.1 Block Diagram
