Sharp LC-26SB25S Service Manual

LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
68
109 XTALO O N/A Crystal output
110 XTALI I N/A Crystal input
Transport stream (TS)
6 T0CLK I N/A Transport stream 1 input clock
7 T0SYNC I N/A Transport stream 1 input sync.
8 T0VALID I N/A Transport stream 1 input valid
9 T0DATA0 I N/A Transport stream 1 input data bit 0
11 T0DATA1 I N/A
Transport stream 1 input data bit 1
Transport stream 2 input clock
2
12 T0DATA2 I N/A
Transport stream 1 input data bit 2
Transport stream 2 input sync
2
13 T0DATA3 I N/A
Transport stream 1 input data bit 3
Transport stream 2 input valid
2
14 T0DATA4 I N/A
Transport stream 1 input data bit 4
Transport stream 2 input data
2
16 T0DATA5 I N/A Transport stream 1 input data bit 5
17 T0DATA6 I N/A Transport stream 1 input data bit 6
18 T0DATA7 I N/A Transport stream 1 input data bit 7
123 TS_CKO O 4~16mA Transport stream output clock
125 TS_SYNCO O 4~16mA Transport stream output sync.
122 TS_VALIDO O 4~16mA Transport stream output valid
124 TS_DATAO O 4~16mA Transport stream output data
General Purpose Input and Output (GPIO)
1 GPIO0 I/O 4~16mA General purpose I/O bit 0
2 GPIO1 I/O 4~16mA General purpose I/O bit 1
3 GPIO2 I/O 4~16mA General purpose I/O bit 2
4 GPIO3 I/O 4~16mA General purpose I/O bit 3
19 GPIO4 I/O 4~16mA General purpose I/O bit 4
20 GPIO5 I/O 4~16mA General purpose I/O bit 5
21 GPIO6 I/O 4~16mA General purpose I/O bit 6
91 GPIO7 I/O 4~16mA General purpose I/O bit 7
92 GPIO8 I/O 4~16mA General purpose I/O bit 8
93 GPIO9 I/O 4~16mA General purpose I/O bit 9
118 GPIO10 I/O 4~16mA General purpose I/O bit 10
119 GPIO11 I/O 4~16mA General purpose I/O bit 11
120 GPIO12 I/O 4~16mA General purpose I/O bit 12
127 GPIO13 I/O 4~16mA General purpose I/O bit 13
128 GPIO14 I/O 4~16mA General purpose I/O bit 14
PCMCIA/CI
83 D0 I/O 4~16mA PCMCIA data bit 0
85 D1 I/O 4~16mA PCMCIA data bit 1
87 D2 I/O 4~16mA PCMCIA data bit 2
24 D3 I/O 4~16mA PCMCIA data bit 3
26 D4 I/O 4~16mA PCMCIA data bit 4
28 D5 I/O 4~16mA PCMCIA data bit 5
30 D6 I/O 4~16mA PCMCIA data bit 6
32 D7 I/O 4~16mA PCMCIA data bit 7
81 D8 I/O 4~16mA PCMCIA data bit 8
84 D9 I/O 4~16mA PCMCIA data bit 9
86 D10 I/O 4~16mA PCMCIA data bit 10
25 D11 I/O 4~16mA PCMCIA data bit 11
27 D12 I/O 4~16mA PCMCIA data bit 12
29 D13 I/O 4~16mA PCMCIA data bit 13
31 D14 I/O 4~16mA PCMCIA data bit 14
34 D15 I/O 4~16mA PCMCIA data bit 15
80 A0 O 4~16mA PCMCIA address bit 0
78 A1 O 4~16mA PCMCIA address bit 0
75 A2 O 4~16mA PCMCIA address bit 0
73 A3 O 4~16mA PCMCIA address bit 0
71 A4 O 4~16mA PCMCIA address bit 0
69 A5 O 4~16mA PCMCIA address bit 0
66 A6 O 4~16mA PCMCIA address bit 0
64 A7 O 4~16mA PCMCIA address bit 0
46 A8 O 4~16mA PCMCIA address bit 0
44 A9 O 4~16mA PCMCIA address bit 0
37 A10 O 4~16mA PCMCIA address bit 0
41 A11 O 4~16mA PCMCIA address bit 0
