2008-03-14
LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
69
62 A12 O 4~16mA PCMCIA address bit 0
48 A13 O 4~16mA PCMCIA address bit 0
50 A14 O 4~16mA PCMCIA address bit 0
59 A15 O 4~16mA PCMCIA address bit 0
57 A16 O 4~16mA PCMCIA address bit 0
45 A17 O 4~16mA PCMCIA address bit 0
47 A18 O 4~16mA PCMCIA address bit 0
49 A19 O 4~16mA PCMCIA address bit 0
51 A20 O 4~16mA PCMCIA address bit 0
54 A21 O 4~16mA PCMCIA address bit 0
56 A22 O 4~16mA PCMCIA address bit 0
58 A23 O 4~16mA PCMCIA address bit 0
61 A24 O 4~16mA PCMCIA address bit 0
63 A25 O 4~16mA PCMCIA address bit 0
67 RESET O 4~16mA PCMCIA reset
35 CE1_ O 4~16mA PCMCIA card enable 1
36 CE2_ O 4~16mA PCMCIA card enable 2
23 CD1_ I N/A PCMCIA card detection 1
88 CD2_ I N/A PCMCIA card detection 2
38 VS1_ I N/A PCMCIA voltage sense 1
65 VS2_ I N/A PCMCIA voltage sense 2
79 BVD1 I N/A PCMCIA battery voltage detection 1
77 BVD2 I N/A PCMCIA battery voltage detection 2
72 INPACK_ I N/A PCMCIA input port acknowledge
70 WAIT_ I N/A PCMCIA wait
40 IORD_ O 4~16mA PCMCIA IO read strobe
42 IOWR_ O 4~16mA PCMCIA IO write strobe
74 REG_ O 4~16mA PCMCIA register selection
79 OE_ O 4~16mA PCMCIA output enable
53 WE_ O 4~16mA PCMCIA write enable
55 READY I N/A PCMCIA ready
89 WP I N/A PCMCIA write protect
Power & Ground
5 VCC33 I N/A I/O power 3.3V
33 VCC33 I N/A I/O power 3.3V
52 VCC33 I N/A I/O power 3.3V
68 VCC33 I N/A I/O power 3.3V
97 VCC33 I N/A I/O power 3.3V
121 VCC33 I N/A I/O power 3.3V
10 GND33 I N/A Ground
43 GND33 I N/A Ground
60 GND33 I N/A Ground
76 GND33 I N/A Ground
104 GND33 I N/A Ground
126 GND33 I N/A Ground
15 VCC18 I N/A Core power 1.8V
82 VCC18 I N/A Core power 1.8V
22 GND18 I N/A Ground
90 GND18 I N/A Ground
108 AVDD33_XTAL I N/A Analog crystal power 3.3V
111 AVSS33_XTAL I N/A Analog crystal ground
112 AVDD18_PLL I N/A Analog PLL power 1.8V
113 AVSS18_PLL I N/A Analog PLL ground
2.11. U390 (MX25L3205DMI-12G SOP-16)
2.11.1 Block Diagram
