LC-32HT1U
Ref.No Description LC-32D4U LC-32HT1U Note
PWB ASSEMBLIES
DIGITAL Unit DUNTKD331FE13 DUNTKD331FE20 Some parts changed
AV Unit DUNTKD352DE18 DUNTKD352WE21 Some parts changed
KEY Unit DUNTKD353DE18 DUNTKD353WE01 No parts changed
R/C, LED Unit DUNTKD354DE18 DUNTKD354WE02 No parts changed
SP(L) Terminal Unit DUNTKD355WE01 Add
SP(R) Terminal Unit DUNTKD356WE01 Add
MAIN Unit DUNTKD376FE05 DUNTKD376FM08 Some parts changed
POWER Unit RDENCA139WJQZ RDENCA140WJQZ No parts changed
DIGITAL Sub Unit DUNTKD537FE01 Add
Ë LCD PANEL
32"WIDE LCD PANEL MODULE Unit RLCUCA025WJZZ
Ë DIGITAL Unit
Plese refer to the parts list.
Ë AV Unit
IC1913 Integrated Circuit VHi24LC2BiN-1Y VHi24LC2BiN9ES Change
Q3051 Transistor VS2SA1530AR-1Y Add
Q3052 Transistor VS2SC3928AR-1Y Add
D3051 Diode VHD1SS355//-1Y Add
R3051 Metal Oxide VRS-CY1JF472JY Add
R3053 Metal Oxide VRS-CY1JF103JY Add
R3054 Metal Oxide VRS-CY1JF103JY Add
R3055 Metal Oxide VRS-CY1JF472JY Add
R3056 Metal Oxide VRS-CY1JF220JY Add
P3801 Plug QPLGNA324WJZZY Add
These parts is delete from "LC-32D4U". Delete
Q1110, L1103, C1110, C1113, C2709, C2714, R1114, R1118, R2713, P3102
Ë SP(L) Terminal Unit
Please refer to the parts list.
Ë SP(R) Terminal Unit
Please refer to the parts list.
Ë MAIN Unit
IC1004 Integrated Circuit RH-iXB515WJQZQ RH-iXB665WJQZQ Change
R1086 Metal Oxide VRS-CY1JF472JY Add
These parts is delete from "LC-32D4U". Delete
R1022, P1001,P1003, SC1001
Ë DIGITAL Sub Unit
Please refer to the parts list.
Ë CABINET AND MECHANICAL PARTS, SUPPLIED ACCESSORIES, PACKING PARTS, SERVICE JIGS
Please refer to the parts list.
LIST OF CHANGED PARTS
LC-32D4U ➔ LC-32HT1U
