Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32HT1U
78
INTEGRATED CIRCUIT
IC1913 VHi24LC2BiN9ES J i24LC2BiN AH
TRANSISTORS
Q3051 VS2SA1530AR-1Y J 2SA1530AR AB
Q3052 VS2SC3928AR-1Y J 2SC3928AR AB
DIODE
D3051 VHD1SS355//-1Y J 1SS355 AB
RESISTORS
R3051 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3053 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3054 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3055 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3056 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
MISCELLANEOUS PART
P3801 QPLGNA324WJZZY J Plug, 4pin AC
DUNTKD355WE01
SP(L) Terminal Unit
RESISTORS
FB207 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
FB208 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
MISCELLANEOUS PARTS
J203 QJAKEA071WJZZ J Jack, 2pin AP
LUG204 QLUGHA002WJZZ J Lug AB
P204 QPLGNA056WJZZ J Plug, 2pin AB
DUNTKD356WE01
SP(R) Terminal Unit
RESISTORS
FB205 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
FB206 VRS-TV1JD000JY J 0 1/10W Metal Oxide AA
MISCELLANEOUS PARTS
J202 QJAKEA071WJZZ J Jack, 2pin AP
LUG203 QLUGHA002WJZZ J Lug AB
P203 QPLGNA056WJZZ J Plug, 2pin AB
DUNTKD376FM08
MAIN Unit
INTEGRATED CIRCUIT
IC1004 RH-iXB665WJQZQ J iXB665WJ AN
RESISTOR
R1086 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
DUNTKD352WE21
AV Unit
INTEGRATED CIRCUITS
IC10 VHiA89S8253-1Y J iA89S8253 AW
IC11 VHiVHCT08AT-1Y J iVHCT08AT AD
DIODES AND LED'S
D10 VHD1SS355//-1Y J 1SS355 AB
D11 RH-EX1395CEZZY J Zener Diode, 6.2V AC
D12 RH-EX1395CEZZY J Zener Diode, 6.2V AC
D13 RH-EX1395CEZZY J Zener Diode, 6.2V AC
D14 RH-EX1395CEZZY J Zener Diode, 6.2V AC
D15 VHD1SS355//-1Y J 1SS355 AB
PACKAGED CIRCUIT
X10 RCRSCA124WJZZY J Crystal
CAPACITORS
C10 VCKYCY1AB105KY J 1 10V Ceramic AB
C11 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C12 VCERML1CN106MY J 10 16V AC
C13 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C14 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C15 VCCCCY1HH5R0CY J 5.0p 50V Ceramic AA
C16 VCCCCY1HH5R0CY J 5.0p 50V Ceramic AA
RESISTORS
R10 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R11 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R12 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R13 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R14 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R15 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R16 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R17 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R18 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R19 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R20 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R23 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
J10 QJAKZA031WJPZ J Jack, 6pin AE
LUG10 QLUGHA006WJZZY J Lug AC
LUG11 QLUGHA006WJZZY J Lug AC
P10 QPLGNA328WJZZY J Plug, 8pin AD
P11 QPLGNA324WJZZY J Plug, 4pin AC
P12 QPLGNA323WJZZY J Plug, 3pin AC
DUNTKD537FE01
DIGITAL Sub Unit
