Sharp LC-32LE140E Service Manual

18
LC-32LE140
0.2 MB62 Placement of Blocks
0.2. MB62 Placement of Blocks
Main IC
(U5)
Tuner(T3
)
Nand Flash (U162)
SPI Flash
DDR2 RAM (U155)
LVDS
Connectors
DVD Connector External Keyboard Touchboard
Power Connector
Satellite Tuner
Keypad
YPbPr SAV HP
USB
HDMI Connectors
VGA
SCART Connec tor
SPDIF Out
Adapter DC Input
Speaker Con. Led Con Inv. Con
Sat Demod
CI Connector
