22. LC-32LE140 OVERALL WIRING DIAGRAM
PL306 CN706 CN137 CN709
1
24V
1 GND 1 GND 1
2
24V
2 GND 2 GND 2
3
24V
3 STBY_ON_OFF 3 OP_PIN8 3
4
24V
4 GND 4 OP_PIN9 4
5
24V
5 BACKLIGHT_ON_OFF 5 GND 5
6
GND
6 GND 6 TX_A_3_P 6
7
GND
7 DIMMING 7 TX_A_3_N
8
GND
8 GND 8 GND
9
GND
9 5V_STBY 9 TX_A_CLK_P
10
A/D_DIM_SEL
10 12V_VCC 10 TX_A_CLK_N
11
DIM_PWM_ANALOG
11 5V_VCC 11 GND
12 BL_ON/OFF_1 12 5V_VCC 12 TX_A_2_P
13 12V_STBY 13 TX_A_2_N
14 12V_STBY 14 GND
PL205
15 3V3_VCC 15 TX_A_1_P
1
GND
16 5V_VCC 16 TX_A_1_N
2
GND
17 3V3_VCC 17 GND
3
SW_SWITCH
18 5V_VCC 18 TX_A_0_P
4
GND
19 3V3_VCC 19 TX_A_0_N
5
ST_BY
20 5V_VCC 20 GND
6
GND
21 OP_PIN27
7
BL_ON/OFF
22 OP_PIN42
8
GND
23 OP_PIN43
9
DIM_PWM_ANALOG
24 GND
10
GN
D
25 GND
11
12V_1
26 GND
12
12V_1
27 PANEL_VCC
13
5VSTBY
28 PANEL_VCC
14
24V_1
29 PANEL_VCC
15
4V25_STBY
30 PANEL_VCC
16
4V25_STBY
17
VCC_3V3_ON
18
5V
19
VCC_3V3_ON
20
5V
21
VCC_3V3_ON
22
5V
23
GND
24
GND
25
VCC_AUDIO
26
ST_BY2
27
A/
D_DIM_SEL
CN710
28
A/D_DIM_SEL
1 GND
CN703
2 R_AUDIO_P 1 GND
3 L_AUDIO_P 2 LED 2
4 L_AUDIO_P 3 LED 1
5 L_AUDIO_N 4 IR_IN
6 GND 5 5V_STBY
1 GND
2 LED 2
3 LED 1
4 IR_I N
5 5V_STBY
MB62 / PW07 OVERALL WIRING DIAGRAM
SPEAKER RIGHT
MB62 MAIN BOARD
SPEAKER LEFT
PW07 POWER SUPPLY BOARD
PANEL INVERTER BOARD
LED IR BOARD
PANEL T-CON BOARD
PL
101PL100
MODEL
MAIN BOARD
POWER SUPPLY
LC32LE140E & LC32LE140EV
LC32LE140EK & LC32LE140RU
MB62
PW07
TOUCH_PAD_OPTION
KEYBOARD_ONBOARD
GND
3V3_STBY
SCL_SYS
SDA_SYS
TOUCH PAD
AC
POWER
PLUG
LED/IR CABLE
SPEAKER CABLE
LVDS CABLE
INVERTER CABLE
ROCKER
SWITCH
POWER CABLE
TOUCH PAD CABLE
PARTS CODE 30072577
PARTS CODE 30072557
PARTS CODE 20570371
PARTS CODE 30069976
INCLUDED IN LED BOARD
