Sharp LC-32LE140E Service Manual

77
LC-32LE140
MARK * : SPARE
DELIVERY SECTION (G: EPC SHARP GmbH)
REF No.
PARTS DESCRIPTION *
PRICE
CODE
30071793 TFT 32HD50HZ ELED LG LC320EXN-SDA1(PL) PANEL 32" G --
23003246
CHS.ASSY.17MB62-F2L1212H292221121222A MAIN LC32LE140E/EV/RU
G --
23028957 CHS.ASSY.17MB62-F2L1212H292221121222A MAIN LC32LE140EK G --
20565400 MD.ASY.17LD98-7-26880(25/35(SHARP)RED/GR) I/R & LED BOARD G --
20571297 MD.ASY.17TK124F-1-TOUCH PAD BOARD G --
¡ 23028943 MD.ASY.17PW07-32"(MB60 SHARP) RCO_V2 PCB POWER BOARD G --
U1 30069495 IC LDO AP2111H 3.3V/600MA SOT223 ROHS G --
U145 30062776 DIODE SMD ESD AZ1045-04S SOT23-6 ROHS G --
U155 30070769 IC DDR2 64Mx16 K4T1G164QF-BCF8 BGA84 ROH G --
U158 30070314 IC FLASH SPI 8Mb MX25L8006E SO8 ROHS G --
U162 30072037 IC NAND 512Mb NAND512W3A2SN6F TSOP48 ROH G --
U168 30068105 IC AAMP TPA3113 2x6W BTL TSSOP28 ROHS G --
U173 30070995 IC STEP DOWN RT8293A ADJ/3A SO8 RoHS G --
U175 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U176 30066926 IC STEP DOWN MP2012 ADJ/1.5A QFN6 RoHS G --
U178 30057644 IC DOPAMP TL062 SO8 RoHS G --
U2 30069495 IC LDO AP2111H 3.3V/600MA SOT223 ROHS G --
U5 30070454 IC MSD9WB9PT-2-SS BGA380 RoHS G --
U5 40045953 SUPER THIN POWDER (17.5*17.5*2)Rohs G --
U8 30068149 IC POWER SW ADJ FPF2124 SOT23-5 ROHS G --
U9 30017001 IC RESET MAX809LTR Vth=4.63V SOT23 RoHS G --
Q119 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q146 30001458 TR BC858B SMD G --
Q170 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q171 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q173 30001458 TR BC858B SMD G --
Q174 30001458 TR BC858B SMD G --
Q178 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q180 30001458 TR BC858B SMD G --
Q181 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q185 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q186 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q188 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q189 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
LC32LE140E-EV-EK-RU LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
PRINTED WIRING BOARDS
LC-32LE140E-EK-EV-RU MB62
MAIN UNIT
TRANSISTORS
INTEGRATED CIRCUITS
REF No.
PARTS DESCRIPTION *
PRICE
CODE
Q190 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q191 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q192 30010733 TR NMOS 2N7002 0.115A/60V SOT23 ROHS G --
Q193 30001458 TR BC858B SMD G --
Q194 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q195 30001458 TR BC858B SMD G --
Q199 30018060 TR PMOS FDC642P -4A/-20V SSOT6 ROHS G --
Q202 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q203 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q204 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q208 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q209 30069749 TR NMOS BSH105 1.05A/20V SOT23 ROHS G --
Q210 30010733 TR NMOS 2N7002 0.115A/60V SOT23 ROHS G --
D1 30070436 DIODE SMD ARRAY ESD CDA4C16GTH 0508 RoHS G --
D165 30042066 DIODE SMDSCH1N5819 1A/40V/25A SOD123ROHS G --
D171 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D178 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D184 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D185 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D186 30048473 DIODE DUALSMD BAW56 4A/75V/4A SOT23ROHS G --
D189 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D191 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 RoHS G --
D192 30062423 FUSE SAFE SMD 4A/32VDC UF HMELT 1206RoHS G --
D2 30070436 DIODE SMD ARRAY ESD CDA4C16GTH 0508 RoHS G --
D203 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D204 30038502 DIODE SMD ZEN B5.1V SOD123 ROHS G --
D205 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D206 30038479 DIODE SMD ZEN C3V6 SOD123 ROHS G --
D3 30070436 DIODE SMD ARRAY ESD CDA4C16GTH 0508 RoHS G --
D4 30070436 DIODE SMD ARRAY ESD CDA4C16GTH 0508 RoHS G --
D5 30062776 DIODE SMD ESD AZ1045-04S SOT23-6 ROHS G --
X2 30057263 XTAL SMD 24MHz 22pF 30ppm 25OhmHC49S RHS G --
L116 30058702 COIL SMD 10uH 2.5A M 0R4 7x7(SHL)Ro G --
L117 30058702 COIL SMD 10uH 2.5A M 0R4 7x7(SHL)Ro G --
L119 30025158 COIL SMD 4.7uH 0.03A M 1R 805 Ro G --
L120 30025158 COIL SMD 4.7uH 0.03A M 1R 805 Ro G --
L124 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
L125 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
L126 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
L127 30072017 COIL SMD 10uH 2A5 M 0R06 6X6X4.5 (SHL)Ro G --
F179 30063648 FERRIT SMD 120/100MHz 0.09R M1.2A 0402Ro G --
F181 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F187 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F200 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F201 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F202 30066582 FERRIT SMD 1K/100MHz 1R5 M 50mA 603Ro G --
F203 30066582 FERRIT SMD 1K/100MHz 1R5 M 50mA 603Ro G --
F205 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F206 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F248 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F249 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F259 30020530 FERRIT SMD 600R/100MHz 0.5R M 0.2A 603Ro G --
F270 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F271 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F272 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F273 30001734 RES SMD 1/10W 0R 0805 ROHS G --
F274 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F277 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
F281 30019087 FERRIT SMD 60R/100MHz 0.025 M 3A 0805Roh G --
DIODES
PACKAGED CIRCUITS
COILS AND FILTERS
PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identied in this manual.
Electrical components having such features are identied by in the Replacement Parts Listing.
The use of a substitute replacement part which does not have the same safety characteristics
as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock re, or other hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO.
4. DESCRIPTION 5. CODE 6. QUANTITY
!
