Sharp LC-32LE340E - Page 103

LC-32LE340/343
LC-40LE340/343
MARK * : SPARE
DELIVERY SECTION (G: EPC SHARP GmbH)
REF No. PARTS DESCRIPTION *
PRICE
CODE
30071826 TFT 32 FHD50SC ELED LG LC320EUN-SDV1 PL (Panel 32") G --
30070539 TFT 40FHD50HZ ELED SAM LTA400HM13 ( Panel 40") G --
23021312 CHS.ASSY.17MB70-DPB1222P291C12131212A - Main Board LC32LE340/343 G --
23021307 CHS.ASSY.17MB70-DPB1222P291C121312142 - Main Board LC40LE340/343 G --
20468754 MD.ASY.17TK124CY-XX850 (V5.0) Touch Pad Board G --
20565400 MD.ASY.17LD98-7-26880(25/35(SHARP)RED) I/R& Led Board LC32LE340/343 G --
20565404 MD.ASY.17LD98-7-37-42880(25-35(SH)RED) I/R & LED Board LC40LE340/343 G --
23029036 MD.ASY.17PW07-32" (MB61&70_SHARP) Power Board LC32LE340/343 G --
23029063 MD.ASY. 17PW07-42" (MB61&70_SHARP) Power Board LC40LE340/343 G --
U1 30067975 IC BCM3556 FCBGA704 ROHS G --
U1 35027726 Heatsink Elks MB70 T412+MB07UA 45X85X6R G --
U10 30063727 IC 8bit CONTR. uPD78F0503 (SSOP30) ROHS G --
U103 30024054 IC EEPROM 24C64 64Kbx8 SO8 ROHS G --
U104 30010822 IC MUX/DEMUX M74HC4052 SO16 ROHS G --
U105 30064790 IC REG DDR TERMIN. SC2596 (SOIC-8L)ROHS G --
U108 30068149 IC POWER SW ADJ FPF2124 SOT23-5 ROHS G --
U109 30068149 IC POWER SW ADJ FPF2124 SOT23-5 ROHS G --
U11 30066904 IC HDMI SWITCH SIL9287B QFN72 RoHS G --
U111 30033737 IC AND GATE 74V1G08 (SOT 23-5) RoHS G --
U112 30033737 IC AND GATE 74V1G08 (SOT 23-5) RoHS G --
U114 30025116 IC LDO LM1117 ADJ/800MAVIN:15VSOT223ROH G --
U116 30069915 IC HEADPHONE MAX9820 TDFN10 RoHS G --
U13 30036983 IC EEPROM 24LC02 2Kbx8 SO8 RoHS G --
U2 30054012 IC 74LCX245 (TSSOP-20) ROHS G --
U20 30062597 IC STEP DOWN FAN2106 ADJ/6A MLP25 RoHS G --
U21 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U22 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U23 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U24 30060344 IC LDO LM1117 ADJ/1A DPAK ROHS G --
U3 30068049 IC HEADPHONE CXA3813N SSOP24 RoHS G --
U32 30067868 IC QAM DEMOD. MSB1224 QFP48 ROHS G --
U33 30068176 IC LDOLM1117 1.2V/800MAVIN:15V SOT223RHS G --
U35 30072538 IC NAND 1Gb K9F1G08U0D TSOP48 ROHS G --
U36 30053941 IC 74LCX244 (TSSOP-20) ROHS G --
U37 30069495 IC LDO AP2111H 3.3V/600MA SOT223 ROHS G --
LC32LE340/343,LC40LE340/343 LCD PANEL
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY
PRINTED WIRING BOARDS
LC-32LE340 /LC32LE343 - CHASIS MB70
MAIN UNIT
INTEGRATED CIRCUITS
REF No. PARTS DESCRIPTION *
PRICE
CODE
U38 30060346 IC STEP DOWN MP1583 3A VIN=23V SO8 ROHS G --
U39 30066926 IC STEP DOWN MP2012 ADJ/1.5A QFN6 RoHS G --
U4 30062776 DIODE SMD ESD AZ1045-04S SOT23-6 ROHS G --
U41 30070287 IC DDR2 128MX8 K4T1G084QF-BCF8 1066 ROHS G --
U42 30070287 IC DDR2 128MX8 K4T1G084QF-BCF8 1066 ROHS G --
U6 30067906 IC AAMP TPA3110 2x15W BTL TSSOP28 ROHS G --
U8 30070287 IC DDR2 128MX8 K4T1G084QF-BCF8 1066 ROHS G --
U9 30070287 IC DDR2 128MX8 K4T1G084QF-BCF8 1066 ROHS G --
Q10 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q106 30069749 TR NMOS BSH105 1.05A/20V SOT23 ROHS G --
Q107 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q11 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q112 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q113 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q114 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q115 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q118 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q119 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q12 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q120 30001458 TR BC858B SMD G --
Q121 30001458 TR BC858B SMD G --
Q13 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q131 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q132 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q134 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q135 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q15 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q18 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q19 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q24 30001458 TR BC858B SMD G --
Q26 30001458 TR BC858B SMD G --
Q27 30001458 TR BC858B SMD G --
Q29 30018060 TR PMOS FDC642P -4A/-20V SSOT6 ROHS G --
Q3 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q4 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q6 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
Q7 30001457 TR NBJT BC848B 0.1A/30V SOT23 ROHS G --
D11 30053657 DIODE SMD ARRAY ESD NUP4004M5 TSOP-5RoHS G --
D12 30053657 DIODE SMD ARRAY ESD NUP4004M5 TSOP-5RoHS G --
D13 30019996 DIODE SMD BAV70 215mA/75V 4A SOT23 RoHS G --
D14 30019996 DIODE SMD BAV70 215mA/75V 4A SOT23 RoHS G --
D15 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D16 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D17 30053657 DIODE SMD ARRAY ESD NUP4004M5 TSOP-5RoHS G --
D18 30053657 DIODE SMD ARRAY ESD NUP4004M5 TSOP-5RoHS G --
D19 30053657 DIODE SMD ARRAY ESD NUP4004M5 TSOP-5RoHS G --
D2 30018574 DIODE SMD SCH SS33 3A/30V DO214AB ROHS G --
D20 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D21 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D22 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D23 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D26 30038480 DIODE SMD ZEN C5.6V SOD123 ROHS G --
D28 30038478 DIODE SMD ZEN C15V SOD123 ROHS G --
D30 30038507 DIODE SMD 1N4148 0.15A/100V SOD123 ROHS G --
TRANSISTORS
DIODES
PARTS LISTING
REPLACEMENT PARTS
Replacement parts which have special safety characteristics are identied in this manual.
Electrical components having such features are identied by in the Replacement
Parts Listing.
The use of a substitute replacement part which does not have the same safety charac-
teristics as the factory recommended is not permitted.
Replacement parts not shown in this service manual may create shock re, or other
hazards.
HOW TO ORDER REPLACEMENT PARTS
To have your order completed promptly and correctly please supply the fol-
lowing information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO.
4. DESCRIPTION 5. CODE 6. QUANTITY
!
103
LC-32LE340/343
LC-40LE340/343
