LC-32LE340/343
LC-40LE340/343
CABINET AND MECHANICAL PARTS LISTING
REF Nº
PARTS DESCRIPTION
*
PRICE
CODE
20565061 FRONT 32942 LED(BS&SHARP/S) (Front Cabinet ) G --
20565095 BC.32942LE 61&ROWO/KL&CH&SAM&AU ( Back Cover ) G --
40044553 COVER GROMMET 30x30 (I(V0 (on Back cover ) G --
40046849 LENS COSMETIC 32942 LED SILV.BRUS HST( Decoration plate on Front Cabinet ) G --
40043424 LED IR LENS TFT XX856 (%3 MILKY) VER6. G --
30069612 CNAS 8P-6/500 CY W/DC UL1571AWG28 RoHS (Touch pad cable) G --
35028277 METAL_PLATE_MB70_LED_LCD32_2011 G --
35028347 METAL FOOT SUPPORT LED LCD32_SHARP_2011 G --
20569417 ROC.SW.AS.(MB60_22942_SHARP) Rocker Switch & Cable G --
20562171 FOOT ASSY 32942(GLOSSY-BLACK_SHARP(PKG ( Stand Foot) G --
45010585 DETACHABLE SHARP ST. BLACK LCD32 LED PKG G --
20565102 SPK.AS.32930 LED(MB70(30X107X20(BL)SHARP (Speakers ) G --
40046688 BRACKET IO MB61S 2011 VER5(I)ABS(V0_SHA G --
30071176 CNAS 28P/450 SIS W/DC MB61UL1007 #24SHAR (DC voltage cable ) G --
20570885 CN.A.FFC 51P/300P=05mmLVDS(32"LEDMB70 ( Cable LVDS FFC) G --
30070913 CNAS 12P+14P/190SIS W/DC UL1007AWG24SHAR ( Panel Inverter Cable) G --
30070136 PWR CORD SAFE EU 1800-70 W/GR+H 3P ROHS ( Power Cord EU) G --
23007323 R/C 5112 SHARP &5112 ( GRAY/S)BLACK/P)(X) ( Remote control ) G --
23004667 SHARP LC-32LE340E ( Owner Manual & Accesories (Batteries, YPBPr Cables,) G --
23006063 SHARP LC32LE340RU ( Owner Manual & Accesories (Batteries, YPBPr Cables, ) G --
23006053 SHARP LC32LE340EV ( Owner Manual & Accesories (Batteries, YPBPr Cables, ) G --
23008419 SHARP LC32LE343E ( Owner Manual & Accesories (Batteries, YPBPr Cables, ) G --
20556710 SNOW BOX ASSY (T/B) 32930 LED (Top bottom strafors ) G --
20548318 SNOW BOX MIDDLE 200x130x170 ( middle strafor) G --
50201050 CARTON BOX SHARP LC32LE340E G --
50201419 CARTON BOX SHARP LC32LE340RU G --
50201413 CARTON BOXD SHARP LC-32LE340EV G --
50202318 CARTON BOX SHARP LC-32LE343E G --
CABINET AND MECHANICAL
PARTS LISTING LC32LE340E /EV/RU LC32LE343E
ACCESSORIES PARTS LISTING
PACKING PARTS LISTING
135
