Dir Description
R0X0P 68
R0X0N 67
TMDS Input TMDS input Port 0 data pair for HDMI and MHL.
R0X1P 70
R0X1N 69
R0X2P 72
R0X2N 71
TMDS Input TMDS input Port 0 data pairs for HDMI.
R0XCP 66
R0XCN 65
TMDS Input TMDS input Port 0 clock pair for HDMI and MHL.
R1X0P 4
R1X0N 3
TMDS Input TMDS input Port 1 data pair for HDMI and MHL.
R1X1P 6
R1X1N 5
R1X2P 8
R1X2N 7
TMDS Input TMDS input Port 1 data pairs for HDMI.
R1XCP 2
R1XCN 1
TMDS Input TMDS input Port 1 clock pair for HDMI and MHL.
R2X0P 14
R2X0N 13
TMDS Input TMDS input Port 2 data pair for HDMI and MHL.
R2X1P 16
R2X1N 15
R2X2P 18
R2X2N 17
TMDS Input TMDS input Port 2 data pairs for HDMI.
R2XCP 12
R2XCN 11
TMDS Input TMDS input Port 2 clock pair for HDMI and MHL.
R3X0P 22
R3X0N 21
TMDS Input TMDS input Port 3 data pair for HDMI and MHL.
R3X1P 24
R3X1N 23
R3X2P 26
R3X2N 25
TMDS Input TMDS input Port 3 data pairs for HDMI.
R3XCP 20
R3XCN 19
TMDS Input TMDS input Port 3 clock pair for HDMI and MHL.
HDMI Transmitter Port Pins
Signal Name Pin
Dir
Description
TX0P 60
TX0N 61
TX1P 58
TX1N 59
TX2P 56
TX2N 57
TMDS Output HDMI Output Port Data.
TMDS Low Voltage Differential Signal output data pairs.
TXCP 62
TXCN 63
TMDS Output HDMI Output Port Clock.
TMDS Low Voltage Differential Signal output clock pair.
DSCL0
DSCL1
DSCL2
DSCL3
30
34
40
44
LVTTL
Schmitt
Open drain
5-V tolerant
Input DDC I
2
C Clock for respective port.
These signals are true open drain, and do not pull-down to ground when
power is not applied to the device. These pins require an external pull-up
resistor.
R0PWR5V
R1PWR5V
R2PWR5V
R3PWR5V
32
36
42
46
Power Input 5V Port detection input for respective port.
Connect to 5V signal from HDMI input connector. These signals require a
10 series resistor and at least a 1 F capacitor to ground. A 100 k pull-
down resistor is also required for these signals.
CBUS_HPD0
CBUS_HPD1
CBUS_HPD2
CBUS_HPD3
31
35
41
45
LVTTL
5-V tolerant
Output Hot Plug Detect Output for respective port.
Connect to HOTPLUG of HDMI input connector. In MHL mode, this serves
as the respective port control bus.
R4PWR5V 49 Power Input 5V Standby power or 5V power from 5
th
Receiver port.
If this signal is connected to the VGA cable then it requires a 10 ohm series
resistor and at least a 1 F capacitor to ground. If connected to a local power
supply the resistor is not needed but a capacitor of at least 1 F is
recommended.
DSDA0
DSDA1
DSDA2
DSDA3
29
33
39
43
LVTTL
Schmitt
Open drain
5-V tolerant
Input
Output
DDC I
2
C Data for respective port.
These signals are true open drain, and do not pull-down to ground when
power is not applied to the device. These pins require an external pull-up
resistor.
