Sharp LC-32LE350M User Manual

LC-32LE350M
6 – 5
16.Calculate the correction value پR
low,
پG
low,
پB
low.
پR
low =
R1
slope X
(717-640)
17.Set the reference value R,G,B of point 1 (R1’)=R1+پR
low
18.Shut down the AC power.
䯲
Initial value at RGB 2 point : 3664
䯲
Initial value at RGB 1 point : 640
[Adjustment value]
侀 Teaching set send by engineering dept is set as reference.
[Reference values for adjustment reference]
Equipment : Luminance meter [Minolta CA-210]
Level
Spec
Data
Adjustment
Spec.
Inspection
Spec.
Point 2
ref.
values
229
x=0.272
y=0.277
0.0010 0.0020
Point 1
ref.
values
40
x=0.272
y=0.277
0.0045 0.0090
Ref. : For inspection, set the LCD TV as below.
AV MODE : [DYNAMIC] (Reset)
Aging Time : Minimum 30 minutes
3. FACTORY SETTING
AC power is plug off after shipment setting is done.
Caution
: Do not plug on again after shipment setting is done. If do, please re-do the shipment setting. Do not
off with remote control.
ITEM ERUDECORPNOITIDNOC
Factory setting AC power off to exit
the factory setting.
1. Setting is done with test remote control.
2. Press the ‘Factory Setting’ key on the remote control continuously.
3. When Green background appears on screen and ‘K’ mark
disappears, setting is completed.
The followings are initialised to factory setting:
1) User setting
2) Channel data (e.g. broadcast frequencies)
3) Manufacturer’s option settings
4) Password data
5) Setting values are set based on model destination
Model Name Factory Setting
Key Name
Remote Control
Code
S-System Setting OSD Language
Setting
A3KLG3VSZ/J/I/Y/B/N/M
M-Setting 100000001010110 B/G ENGLISH
A3KLG3VSP P-Setting 100000001011110 M ENGLISH
**Please do inspection for A3KLG3VSP using NTSC signal.
