Sharp LC-32LE350M User Manual

LC-32LE350M
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
R9622 VRS-CZ1JF822JY Resistor 8.2k 1/16W Metal Oxide
R533 VRS-TQ2EF750JY AA Resistor 75 1/4W Metal Oxide
R547 VRS-TQ2EF750JY AA Resistor 75 1/4W Metal Oxide
R548 VRS-TQ2EF750JY AA Resistor 75 1/4W Metal Oxide
R549 VRS-TQ2EF750JY AA Resistor 75 1/4W Metal Oxide
R582 VRS-TQ2EF750JY AA Resistor 75 1/4W Metal Oxide
R583 VRS-TQ2EF750JY AA Resistor 75 1/4W Metal Oxide
R584 VRS-TQ2EF750JY AA Resistor 75 1/4W Metal Oxide
R526 VRS-TW2ED101JY AA Resistor 100 1/4W Metal Oxide
R528 VRS-TW2ED101JY AA Resistor 100 1/4W Metal Oxide
R9630 VRS-TW2HF1R0JY AA Resistor 1 1/2W Metal Oxide
R9631 VRS-TW2HF1R0JY AA Resistor 1 1/2W Metal Oxide
Q9607 VSKTA1535T+-1Y AC Transistor
Q3302 VSLTC014EEB-1Y Transistor LTC014EEBFS8TL
Q1501 VSLTC044EEB-1Y AB Transistor LTC044EEBFS8TL
Q1502 VSLTC044EEB-1Y AB Transistor LTC044EEBFS8TL
Q1503 VSLTC044EEB-1Y AB Transistor LTC044EEBFS8TL
Q1901 VSLTC044EEB-1Y AB Transistor LTC044EEBFS8TL
Q1902 VSLTC044EEB-1Y AB Transistor LTC044EEBFS8TL
Q9601 VSRT1N141U/-1Y AB Transistor RT1N141U-T111-1
Q3301 VSUPUMD2+++-1Y Transistor
J504 QJAKJ0101SEZZ Jack
J506 QJAKJA024WJZZ Jack
J502 QJAKLA047WJQZ Jack
SC502 QSOCNB037WJQZ Socket
J501 QSOCZA319WJQZ Socket
TU1101 RTUNQA073WJQZ AR Tuner
[4] CABINET AND MECHNICAL PARTS
1 CCABBC190WJ01 REAR CABINET ASSEMBLY (LC-32LE350M)
1-1 GCABBC190WJ4A REAR CABINET (LC-32LE350M)
1-2 JBTN-A960WJ4B CONTROL BUTTON
1-3 LANGKD438WJ4W AD VESA ANGLE (X2)
1-4 XEBS930P08000 AA FOR VESA ANGLE (X2)
1-5 PSPAHC470WJ00 SPACER (X15)
1-6 PSPAHC676WJ00 SPACER (X5)
1-7 PSPAHC677WJ00 SPACER (X10)
2 CANGKD856WJ01 AH FRONT ANGLE LEFT ASSEMBLY
2-1 LANGKD856WJ4W FRONT ANGLE LEFT
2-2 PSPAZC522WJ4Z AB LEG CUSHION
3 CANGKD857WJ01 AH FRONT ANGLE RIGHT ASSEMBLY
3-1 LANGKD857WJ4W FRONT ANGLE RIGHT
3-2 PSPAZC522WJ4Z AB LEG CUSHION
4 GCOVAE341WJ4D AD AC CORD COVER
5 GCOVAE325WJ4B SIDE AV COVER (FOR LC-32LE350/550M ONLY)
6 LANGKD855WJ4W AN BOTTOM ANGLE
7 LHLDWA101WJKZ AC CORD HOOK
9 QACCBA119WJPZ AC CORD (FOR MIDDLE EAST)
9 QACCZA213WJPZ AC CORD (EXCEPT FOR PHILIPINES/THAILAND)
9 QACCZA214WJPZ AN AC CORD (FOR PHILIPINES)
9 QACCZA215WJPZ AC CORD (FOR THAILAND)
10 QCNW-N120WJQZ RA WIRE
11 QCNW-N178WJPZ LVDS WIRE (FOR LC-32LE350M ONLY)
12 QCNW-N179WJQZ PD WIRE
13 QCNW-N180WJQZ L1 WIRE
14 RSP-ZA633WJPZ SPEAKER (L/R)
16 XBPS830P06WS0 SCREW FOR CAB-B (X6)
17 XEBS830P12000 AA SCREW FOR CAB-B (X4)
18 XBPS730P06WS0 AA PWB & ANG SCREW (X14)
[5] LCD PANEL
1 CLCDTA283WE01 LCD PANEL UNIT WITH CAB-A (LC-32LE350M)
2 CANGKD892WJ01 AY BEZEL ANGLE ASSEMBLY
2-1 LANGKD892WJ4W BEZEL ANGLE
2-2 LHLDZC006WJ4Z AD G8 HOLDER L (X2)
2-3 LHLDZC007WJ4Z AD G8 HOLDER T (X2)
2-4 LHLDZC008WJ4Z AD G8 HOLDER R (X2)
2-5 LHLDZC009WJ4Z AD G8 HOLDER BL
2-6 LHLDZC010WJ4Z AD G8 HOLDER BR
2-7 PSPAGC820WJZZ AD SPACER (X2)
2-8 PSPAGB109WJZZ SPACER (X2)
2-9 ZTAPEP079400E TAPE 7x400mm
2-10 ZTAPEP079715E TAPE 7x715mm
3 CCABAC989WJ01 FRONT CABINET ASSEMBLY (LC-32LE350M)
3-1 GCABAC983WJ4A FRONT CABINET (LC-32LE250M)
3-1 GCABAC989WJ4A FRONT CABINET (LC-32LE350M)
3-2 HDECQB802WJ4A AC LED COVER
3-3 HPNLSA443WJ4B SPEAKER SHEET (LC-32LE350M)
3-4 ZSFIM-60T550E AB PROTECT SHEET (X2)
3-5 ZSFIM-60T800E AB PROTECT SHEET (X2)
3-6 PSPAHC675WJ00 HIMELON
4 CCHSMA680WJ01 BA PWB CHASSIS ASSEMBLY
4-1 LCHSMA680WJ4W PWB CHASSIS
4-2 LHLDWA360WJUZ AD S-PWB HOLDER A (X2)
4-3 LHLDWA361WJUZ AD S-PWB HOLDER B (X2)
[3] DKEYMG165FM01(MAIN Unit)
