Sharp LC-32LE700UN User Manual

6
Attaching the Stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC INPUT terminal.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
QUICK REFERENCE
Supplied Accessories
• Always use the AC cord supplied with the TV.
• The illustrations above are for explanation purposes and may vary slightly from the actual accessories.
• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are available
directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for ordering, or
VISIT www.sharpusa.com/SharpDirect.
Make sure the following accessories are provided with the product.
Remote control unit
(
g
1)
Page 7
“AAA” size battery
(
g
2)
Page 8
AC cord
(
g
1)
Page 7
Stand unit
(
g
1)
Page 6
Cable clamp
(
g
1)
Page 7
Operation manual
(
g
1)
CAUTION
• Attach the stand in the correct direction.
• Do not remove the stand from the TV unless using an optional wall mount bracket to mount it.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
1 Confi rm that there are 12 screws (all the same size)
supplied with the stand unit.
2
1
Set the post for the stand unit onto the box.
2
Attach the base to the post.
3
Insert and tighten the 8 screws into the 8 holes
on the bottom of the base.
• Hold the stand unit securely with one hand, and
then tighten the screws.
FRONT
2
3
1
1
Screws
3
1
Insert the stand into the openings on the bottom
of the TV.
2
Insert and tighten the 4 screws into the 4 holes
on the rear of the TV.
1
1
2
2
Screws
Soft cushion
• To detach the stand, perform the steps in reverse order.
LC-32LE700UNE.indb6LC-32LE700UNE.indb6 2009/06/2312:29:212009/06/2312:29:21
