LC-32PX5M/X/LC-37PX5M/X
iii
LC-37PX5M / LC-37PX5X
Ref. No. Description LC-37BX5M LC-37PX5M LC-37PX5X Note
PRINTED WIRING BOARD ASSEMBLIES (NOT REPLACE ITEM)
OPERATION Unit DUNTKD685FM13 DUNTKE097FM04 DUNTKE097FM04 Changes
MAIN Unit DUNTKD892FM13 DUNTKD892FM52 DUNTKD892FM53 Changes
SUB Unit DUNTKD893FM13 DUNTKD893FM52 DUNTKD893FM53 Changes
LED, R/C Unit DUNTKD897FM13 DUNTKD897FM53 DUNTKD897FM53 Changes
VIDEO-IN3 Unit DUNTKD898FM13 - - Delete
POWER Unit exchange RDENCA182WJQZ RDENCA182WJQZ RDENCA182WJQZ No Changes
LED, R/C UNIT (DUNTKD897FM53)
J101 Jack QJAKJA014WJZZ - - Delete
R111 Resistor 22 1/4W Metal Oxide VRS-TW2ED220JY - - Delete
R112 Resistor 100k 1/16W Metal Oxide VRS-CY1JF104JY - - Delete
R113 Resistor 22 1/4W Metal Oxide VRS-TW2ED220JY - - Delete
R114 Resistor 100k 1/16W Metal Oxide VRS-CY1JF104JY - - Delete
R115 Resistor 1k 1/16W Metal Oxide VRS-CY1JF102JY - - Delete
SUB UNIT (DUNTKD893FM52 / DUNTKD893FM53)
C1319 Capacitor 220 6.3V Electrolytic VCEASX0JN227MY - - Delete
C1320 Capacitor 10 16V Ceramic RC-KZA510WJPZY - - Delete
C1321 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY - - Delete
C1322 Capacitor 220 6.3V Electrolytic VCEASX0JN227MY - - Delete
C1326 Capacitor 1000p 50V Ceramic VCKYCY1HB102KY - - Delete
C1327 Capacitor 1000p 50V Ceramic VCKYCY1HB102KY - - Delete
C1328 Capacitor 1 10V Ceramic VCKYCY1AB105KY - - Delete
C1329 Capacitor 33 10V Electrolytic VCEASX1AN336MY - - Delete
C1330 Capacitor 0.1 25V Ceramic VCKYCY1EF104ZY - - Delete
C1337 Capacitor 1 10V Ceramic VCKYCY1AB105KY - - Delete
C1901 Capacitor 1 10V Ceramic VCKYCY1AB105KY - - Delete
C1902 Capacitor 1 10V Ceramic VCKYCY1AB105KY - - Delete
C3447 Capacitor 1 10V Ceramic VCKYCY1AB105KY - - Delete
C3448 Capacitor 1 10V Ceramic VCKYCY1AB105KY - - Delete
C3449 Capacitor 0.1 16V Ceramic VCKYCY1CB104KY - - Delete
C5002 Capacitor 0.01 50V Ceramic VCKYCY1HB103KY - - Delete
C5003 Capacitor 4700p 50V Ceramic VCKYCY1HB472KY - - Delete
C5004 Capacitor 4700p 50V Ceramic VCKYCY1HB472KY - - Delete
D1901 Diode DA221TL VHDDA221///-1Y - - Delete
FB5001 Ferrite Bead BLN-0051TA RBLN-0051TAZZY - - Delete
FB5002 Ferrite Bead BLN-0051TA RBLN-0051TAZZY - - Delete
FL5001 Filter RFILN0017TAZZY - - Delete
FL5002 Filter RFILN0017TAZZY - - Delete
FL5003 Filter RFILN0017TAZZY - - Delete
IC1302 IC BH3544F-E2 VHIBH3544F+-1Y - - Delete
IC1901 IC TC4W66F (TE12L,F) VHITC4W66F/-1Y - - Delete
IC1902 IC TC4W66F (TE12L,F) VHITC4W66F/-1Y - - Delete
IC2001 IC M30626FHPFPU5C RH-IXA648WJN2Q RH-IXA650WJN1Q RH-IXA650WJN1Q Changes
L1303 Coil Peaking 100uH VPCNN101J7R7NY - - Delete
P5009 Plug 14pin (VD) QPLGNA334WJZZY - - Delete
Q1302 Transistor PDTC144EE VSRDTC144EE-1Y - - Delete
Q1901 Transistor 2SC3928A VS2SC3928AR-1Y - - Delete
Q1902 Transistor UM6K1N TN VSUM6K1NTN+-1Y - - Delete
Q1903 Transistor QS6K1 VSQS6K1++++-1Y - - Delete
Q1904 Transistor PDTA144EK VSRDTA144EK-1Y - - Delete
Q2002 Transistor PDTC144EE VSRDTC144EE-1Y - - Delete
R1309 Resistor 18 1/4W Metal Oxide VRS-TW2ED180JY - - Delete
R1310 Resistor 18 1/4W Metal Oxide VRS-TW2ED180JY - - Delete
R1312 Resistor 100k 1/16W Metal Oxide VRS-CY1JF104JY - - Delete
R1313 Resistor 470 1/16W Metal Oxide VRS-CY1JF471JY - - Delete
R1314 Resistor 470 1/16W Metal Oxide VRS-CY1JF471JY - - Delete
R1901 Resistor 1k 1/16W Metal Oxide VRS-TV1JD102JY - - Delete
R1902 Resistor 1k 1/16W Metal Oxide VRS-TV1JD102JY - - Delete
R1903 Resistor 4.7k 1/16W Metal Oxide VRS-CY1JF472JY - - Delete
R1904 Resistor 150k 1/16W Metal Oxide VRS-CY1JF154JY - - Delete
R1907 Resistor 1M 1/16W Metal Oxide VRS-CY1JF105JY - - Delete
R1908 Resistor 1M 1/16W Metal Oxide VRS-CY1JF105JY - - Delete
R1909 Resistor 1M 1/16W Metal Oxide VRS-CY1JF105JY - - Delete
