LC-32PX5M/X/LC-37PX5M/X
iv
In trouble shooting table, "No audio heard (4)" and "No external video screen <INPUT3>" are abolished.
Refer to the PARTS GUIDE for CABINET PARTS, SUPPLIED ACCESORIES, PACKING PARTS and SERVICE JIGS.
R1910 Resistor 1M 1/16W Metal Oxide VRS-CY1JF105JY - - Delete
R1911 Resistor 150k 1/16W Metal Oxide VRS-CY1JF154JY - - Delete
R1912 Resistor 0 1/16W Metal Oxide - VRS-CJ1JF000JY VRS-CJ1JF000JY Add
R2002 Resistor 1k 1/16W Metal Oxide VRS-CY1JF102JY - - Delete
R2003 Resistor 22k 1/16W Metal Oxide VRS-CY1JF223JY - - Delete
R2005 Resistor 22k 1/16W Metal Oxide VRS-CY1JF223JY - - Delete
R2008 Resistor 100k 1/16W Metal Oxide VRS-CY1JF104JY - - Delete
R2034 Resistor 15k 1/16W Metal Oxide VRS-CY1JF153JY - - Delete
R2051 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY VRS-CY1JF102JY VRS-CY1JF102JY Changes
R2075 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY - - Delete
R3465 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY - - Delete
R3466 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY - - Delete
R5008 Resistor 1k 1/16W Metal Oxide VRS-CY1JF102FY - - Delete
R5011 Resistor 47k 1/16W Metal Oxide VRS-CY1JF473JY - - Delete
R5014 Resistor 0 1/16W Metal Oxide VRS-CY1JF000JY - - Delete
OPERATION Unit (DUNTKE097FM04)
All parts are changed.
Ref. No. Description LC-37BX5M LC-37PX5M LC-37PX5X Note
