11
Part names
RESET*
INPUT 3
terminals
SYSTEM
RESET**
TV (Rear)
DIGITAL AUDIO
OUTPUT
* Press RESET if the TV cannot return to its original state after performing various operations.
• AV MODE resets to DYNAMIC (Fixed)
• TV channel returns to initial channel setting (Air: 2ch, Cable:1 or 2ch)
• Audio setting initializes
• Surround resets to Off
• Image position initializes
** Press SYSTEM RESET if the TV does not operate after starting up.
NOTE
• Pressing RESET will not work if the TV is in standby mode.
• Pressing RESET will not delete channel preset or secret number. See page 39 for clearing the secret number when you
know it. See page 54 for initializing to the factory preset values when you forget your secret number.
AC INPUT terminal
RS-232C
terminal
INPUT 2 terminals
INPUT 1
terminals
INPUT 4
terminals
MONITOR OUTPUT terminals
Antenna input terminal
(ANALOG)
Antenna input
terminal (DIGITAL)
LC-37DB5U(E)-01-13 05.8.1, 0:34 PM11
