LC-37XD1E/RU
2 – 2
5. Remove the 4 lock screws and 2 lock screws detach the Center Angle.
6. Remove the 2 lock screws and detach the Center Angle.
7. Remove the 4 lock screws and detach the Top Control Cover Ass’y.
7
8
8
Center Angle
7
8
9
9
Top Control Cover Ass'y
