5. Adjustment process mode menu
The character string in brackets [ ] will appear as a page title in the adjustment process menu header.
Page Line
1/13 [INFO]
1 Main Version
37/42XD1 ver 1.0C1 2006.0915
Main microprocessor version
2 Dev Version ver1.10 DTV version.
3 Dev Loader Version 2.3 DTV Loader Version
4 Center Acutime xxxxH xxM Main operating hours
5 Backlight Acutime xxxxH xxM Backlight operating hours
6 Temp Sensor 080
Temp Sensor setting
7 Normal Standby Cause 1 RC_STANDBY
8 Error Standby Cause [1]
1c POWER ERROR 0000H 00M
Error standby cause Total operating time before error
[2]
1c POWER ERROR 0000H 00M
[3]
1c POWER ERROR 0000H 00M
[4]
0 0000H 00M
[5]
0 0000H 00M
2/13 [INIT]
1 FACTORY INIT
EURO/UK/ITALY/FRANCE/RUSSIA
Initialization to factory settings execution
2 INCH SETTING 37/42 Inch Setting
3 PUBLIC MODE off/on HOTEL MODE㵘flag setting
4 Center Acutime Reset off/on Main operating hours Reset
5 Backlight Acutime Reset off/on Backlight operating hours Reset
6 Picture Read Pos X 670 x-axis setting of picture data
7 Picture Read Pos Y 419 y-axis setting of picture data
8 Picture Read Signal Type PAL/COMP/HDMI/RGB Signal Type Setting
9 Picture Read 0 - 1023 Start/stop of picture data
3/13 [PAL+TUNERMAIN]
1 RF-AGC BG ADJ ENTER RF-AGC BG adjustment execution
2 RF-AGC L ADJ ENTER RF-AGC L adjustment execution
3 PAL+TUNER ADJ ENTER PAL TUNER auto adjustment execution
4PAL㵘ADJ ENTER PAL auto adjustment execution
5 TUNER ADJ ENTER TUNER auto adjustment execution
6PAL㵘DAC 29 PAL DAC adjustment
7 TUNER A DAC 29 Tuner DAC adjustment
8 Tuner AGC BG 5 Tuner AGC BG adjustment
9 Tuner AGC L 8 Tuner AGC L adjustment
10 Tuner AGC int. off 6 Tuner AGC gain adjustment
4/13 [COMP ]
1 COMP ALL ADJ
ENTER
COMP15K auto adjustment execution
2 COMP CONTRAST 32 COMP contrast adjustment execution
3 COMP Cb GAIN 32 COMP Cb gain adjustment execution
4 COMP Cr GAIN 32 COMP Cr gain adjustment execution
5 COMP BRIGHT 0 COMP bright adjustment execution
5/13 [SCART RGB]
1 SCART RGB CONTRAST 40 SCART RGB contrast adjustment execution
2 SCART RGB Cb GAIN 40 SCART RGB Cb gain adjustment execution
3 SCART RGB Cr GAIN 40 SCART RGB Cr gain adjustment execution
4 SCART RGB BRIGHT 0 SCART RGB bright adjustment execution
6/13 [TUNER]
1 TUNER TEST
7/13 [M GAMMA INFO]
1 M GAMMA POS 1
4
W/B adjustment, gradation 1 input setting
2 M GAMMA POS 2
9
W/B adjustment, gradation 2 input setting
3 M GAMMA POS 3
14
W/B adjustment, gradation 3 input setting
4 M GAMMA POS 4
20
W/B adjustment, gradation 4 input setting
5 M GAMMA POS 5
25
W/B adjustment, gradation 5 input setting
6 M GAMMA POS 6
29
W/B adjustment, gradation 6 input setting
7 M GAMMA WRITE off/on EEP writing of adjustment values
8 M GAMMA RESET off/on Initialization of adjustment values
