Sharp LC-37XD1E Service Manual

LC-37XD1E/RU
3 – 9
8/13 [M GAMMA 1-3]
1 M GAMMA R 1 107 W/B adjustment, gradation 1R adjustment value
2 M GAMMA G 1 107 W/B adjustment, gradation 1G adjustment value
3 M GAMMA B 1 107 W/B adjustment, gradation 1B adjustment value
4 275 W/B adjustment, gradation 2R adjustment value
5 275 W/B adjustment, gradation 2G adjustment value
6 275 W/B adjustment, gradation 2B adjustment value
7 446 W/B adjustment, gradation 3R adjustment value
8 446 W/B adjustment, gradation 3G adjustment value
9 446 W/B adjustment, gradation 3B adjustment value
10 off/on EEP writing of adjustment values
9/13 [M GAMMA 4-6]
1 M GAMMA R 4 660 W/B adjustment, gradation 4R adjustment value
2 M GAMMA G 4 660 W/B adjustment, gradation 4G adjustmnet value
3 M GAMMA B 4 660 W/B adjustment, gradation 4B adjustment value
4 835 W/B adjustment, gradation 5R adjustment value
5 835 W/B adjustment, gradation 5G adjustmnet value
6 835 W/B adjustment, gradation 5B adjustment value
7 960 W/B adjustment, gradation 6R adjustment value
8 960 W/B adjustment, gradation 6G adjustment value
9 960 W/B adjustment, gradation 6B adjustment value
10 off/on EEP writing of adjustment values
10/13 [ETC]
1 EEP CLEAR off/on Clear of process㵘adjustment EEP value
2 EEP CLEAR B off/on Clear of process adjustment value㵘of B_mode.
3 STANDBYCAUSE RESET off/on Reset of STANDBY CAUSE
4 0/1 1䋺*** 0䋺***
5 OPTION 0
6 AUTO/EURO/UK Destination setting
7 0 LAMP ERR RESET Initialization of L_ERR
8 0/1 LAMP ERR Inhibit L_ERR detection.
9 DTV CLR off/on Clear of DTV unit.
10 off/on STOP of I2C DATA execution
11/13 [LCD]
1 OSC FREQ50 1279 INVERTER drive frequency setting
2 OSC FREQ60 1279 INVERTER drive frequency setting
3 PWM FREQ50 218 Frequency setting for INVERTER dimmer
4 PWM FREQ60 218 Frequency setting for INVERTER dimmer
5 VCOM ADJ 64 COMMON VIAS adjustment setting
6 QS off/on on/off of Quick Shoot Function
12/13 [LCD TESTPATTERN]
1 PATTERN 0 Display LCD test pattern.
13/13 Service B
1 [HDTV] 0-10 Contrast,Bright and Color Adjustment of HDTV
2 [SERVICE B2] off/on on/off of Auto Sw Adjustment
3 [BASE GAMMA 1] 0-1023 Base Gamma Adjustment 1
4 [BASE GAMMA 2] 0-1023 Base Gamma Adjustment 2
5 [BASE GAMMA 3] 0-1023 Base Gamma Adjustment 3
6 [BASE GAMMA 4] 0-1023 Base Gamma Adjustment 4
7 [BASE GAMMA 5] 0-1023 Base Gamma Adjustment 5
8 [BASE GAMMA 6] 0-1023 Base Gamma Adjustment 6
9 [QUICK SHOOT] 0-255 QS Sreshuhorld Level Adjustment
MGAMMAR5
MGAMMAG5
MGAMMAB5
MGAMMAR6
MGAMMAG6
MGAMMAB6
M GAMMA WRITE
AUTO INSTALLATION SW
COUNTRY
L ERR RESET
L ERR STOP
I2C-OFF
MGAMMAG3
MGAMMAB3
M GAMMA WRITE
MGAMMAR2
MGAMMAG2
MGAMMAB2
MGAMMAR3
