LC-37XD1E/RU
2 – 6
13.Remove the 14 lock screws and detach the LCD Angle and LCD panel Ass’y.
14.Remove the 12 lock screws detach the Tuner Unit.
14
15
15
14
16
Tuner Unit
(
with Tuner
)
LV:MAIN-TCON
B to B(to SC2705)
B to B(to SC2707)
16
