48 R0X1+ I TMDS input data pair. HDMI Port 0.
47 R0X1- I TMDS input data pair. HDMI Port 0.
52 R0X2+ I TMDS input data pair. HDMI Port 0.
51 R0X2- I TMDS input data pair. HDMI Port 0.
59 R1XC+ I TMDS input clock pair. HDMI Port 1.
58 R1XC- I TMDS input clock pair. HDMI Port 1.
63 R1X0+ I TMDS input data pair. HDMI Port 1.
62 R1X0- I TMDS input data pair. HDMI Port 1.
67 R1X1+ I TMDS input data pair. HDMI Port 1.
66 R1X1- I TMDS input data pair. HDMI Port 1.
71 R1X2+ I TMDS input data pair. HDMI Port 1.
70 R1X2- I TMDS input data pair. HDMI Port 1.
22,23,35,
74,79,92,
105,114,
128,139
CVCC18 - Digital Logic VCC.
21,24,36,
73,80,91,
106,115,
127,138
CGND - Digital Logic GND.
5,16,26,7
6,89,109,
122,134
IOVCC - Input/Output Pin VCC.
4,15,25,7
5,90,108,
120,135
IOGND - Input/Output Pin GND.
38,42,46,
50,57,61,
65,69
AVCC - TMDS Analog VCC.
41,45,49,
53,60,64,
68,72
AGND - TMDS Analog GND.
37 PVCC0 - TMDS Port 0 PLL VCC.
55 PVCC1 - TMDS Port 1 PLL VCC.
54 TMDSPGND - TMDS PLL GND.
94 AUDPVCC18 - ACR PLL VCC.
95 AUDPGND - ACR PLL GND.
98 XTALVCC - ACR PLL Crystal Input VCC.
99 REGVCC - ACR PLL Regulator VCC.
