LC-37XD1E/RU
5 – 6
4. IC3503: RH-IXB754WJZZ
128Mb Flash Memory
34,48,
66
VSS - Ground.
49 VREF I SSTL_2 reference voltage.
Pin No. Pin Name I/O Pin Function
I
2-12,
15,
18-26,
54, 31
A0-A22 I 23 Address lnputs.
35,37,3
9,41,44
,46,48,
50
DQ0-DQ7 I/O 8 Data Inputs / Outputs.
35-
42,44-
50
DQ8-DQ14 I/O 7 Data Inputs / Outputs.
51 DQ15A-1 I Data Input/Output or Address Input.
32 CE
I Chip Enable.
34 OS
O Output Enable.
13 WE I Write Enable.
16 Vpp/WP
I Hardware Vpp/ Write Protect
14 RP
I Reset/Block Temporary Unprotect.
17 R/B
O Ready / Busy Output.
53 BYTE
I Byte/Word Organization Select.
43 VCC - Supply Voltage
33.52 VSS - Ground.
27,28,5
5,56
NC - Not Connected Internally.
29 VCCQ - Supply Voltage for Input/Output.
