LC-37XD1E/RU
5 – 20
AF11 GOUT O Green output G
AF13 BOUT O Blue output B
AF8 COUT O Chroma output COUT
AF9 CVOUT O Composite video output CVBS
AF10 YOUT O Luma output YOUT
AD22 notHSYNC I/O Horizontal sync (5 V tolerant) NC
AE22 EVENnotODD I/O Vertical sync (5 V tolerant) TL4016
